An OEM supplier takes your released drawing and returns a part that bolts into your assembly without rework. That sounds obvious, but the phrase covers a wide range of shops. Some only cut simple prismatic housings. Others hold the mating faces on a robot joint within ±0.005 mm and deliver the inspection data with the box.

The difference shows up in setup count. A 3-axis machine needs one fixture per face, so a part with five functional directions might see six setups. Every setup adds a datum shift. On a 5-axis center the same part comes off in one or two setups, which is why position tolerance across faces stays tight.

Buyers often ask for 5-axis because they think it is faster. Sometimes it is not. On a flat bracket with two holes, a 3-axis mill with a good fixture wins on cost per part. Five-axis earns its place when the part has compound angles, deep pockets with drafted walls, thin ribs, or a surface that has to blend continuously into another.

So the first question is not which supplier is cheapest. It is whether the geometry needs simultaneous motion at all.

• 1
  Fits 5-axis wellImpellers, turbine housings, medical bone plates, robot joint housings, complex manifolds.
• 2
  Better on 3- or 4-axisFlat plates, simple shafts, parts that can be turned in one setup plus one milled face.
• 3
  Watch the datum stackEach extra setup moves the reference. Fewer setups usually means tighter true position.

A machining center is defined by its work envelope, spindle and rotary table, not by the word five-axis. Ask for the travel figure in millimeters. A 4,000 × 400 × 150 mm envelope suits long extrusion-like parts such as rails and beams. A 600 × 600 × 600 mm machine handles boxy housings. A Ø400 mm rotary table sets the practical limit for a part that has to spin.

The rotary table matters most for parts with features all around the circumference. If the part plus fixture exceeds the table diameter or its swing clearance, the machine cannot reach the back side, and you are back to extra setups.

Spindle speed and torque decide which materials run well. Aluminum 6061 and 7075 cut fast at high rpm. Titanium TC4 (Ti-6Al-4V) and Inconel want lower rpm and more torque, plus a rigid setup to control chatter. A shop that lists Inconel in its material range should be able to explain its toolpath strategy for it.

One more number worth asking about: how many machines are actually running the shift you need. Sixteen five-axis centers means little if only four are free next week.

• 1
  Long parts4,000 × 400 × 150 mm covers rails, beams and long housings.
• 2
  Boxy housings750 × 1,150 × 550 mm and 600 × 600 × 600 mm envelopes.
• 3
  Compact precision500 × 500 × 450 mm and 500 × 310 × 200 mm envelopes for small tight parts.
• 4
  Rotary workØ400 mm rotary table sets the swing limit for circumferential features.

±0.005 mm is a shop floor number, not a marketing number. It depends on machine geometry, fixture rigidity, coolant stability and the temperature of the room. On a part with a 200 mm span, a 3 °C swing in the shop can eat a meaningful share of that band. Ask how the shop handles thermal drift on long cuts.

Surface finish and tolerance are linked. A tight bore with a rough wall will not seal, and a sealing face with chatter marks will leak. Typical as-machined finish sits at Ra 1.6–3.2 μm. For mating faces, Ra 0.8–1.6 μm is a common target. Sealing and bearing surfaces often call for Ra 0.2–0.8 μm, which usually means a finishing pass or a separate operation.

Inspection is where most RFQs get vague. A credible OEM 5 axis cnc machining manufacturer inspects 100% of parts before shipment: raw material check, in-process monitoring while cutting, and final inspection against the drawing. Reports come on request, not automatically, so ask for them in the PO if you need them for your own quality file.

First article inspection is the cheapest insurance you can buy. It catches a misread GD&T callout before 500 parts are cut.

• 1
  As-machinedRa 1.6–3.2 μm, suitable for non-critical surfaces.
• 2
  Standard precisionRa 0.8–1.6 μm for mating faces and locating surfaces.
• 3
  Fine finishRa 0.2–0.8 μm for seals, bearings and optical seats.

Certifications tell you which risk management system is in place. ISO 9001:2015 covers general quality process control. IATF 16949:2016 is the automotive and EV requirement, and it forces traceability and change control. ISO 13485:2016 applies to medical devices, where process validation and records matter more than throughput. ISO 27001:2022 covers information security, which is relevant when you send CAD files and drawings.

Material range is the next filter. A shop that stocks 6061, 7075 and 304 stainless but has never run 17-4PH or Inconel will quote those grades anyway. Ask what it has actually machined. Titanium and nickel alloys behave differently: they work-harden, they hold heat at the cutting edge, and they punish a light finishing pass.

Secondary operations decide whether you receive a finished component or a machined blank. Anodizing in clear, color, hardcoat or conductive form, electroless nickel, zinc, silver and gold plating, powder coating and black oxide are common. Bead blasting, tumbling, brushing and polishing change both appearance and surface finish value.

Laser marking is worth planning early. Minimum character height is 1.5 mm, so a serial number or a UDI string needs enough flat real estate on the drawing.

• 1
  Automotive and EVIATF 16949 plus traceability from melt lot to finished part.
• 2
  MedicalISO 13485, validated processes and retained inspection records.
• 3
  Aerospace and roboticsTitanium and aluminum grades with tight position tolerance.
• 4
  Data-sensitive programsISO 27001 and an NDA before files leave your network.

Lead time has three parts: quoting, production start and shipping. Ask for each separately. A supplier that returns a quote and DFM analysis within 12 hours and can start production within 24 hours is usually organized around fast turns rather than batch batching. Parts shipping in 3–5 days is normal for prototype quantities, not for 10,000-piece runs.

No minimum order quantity is a real advantage during development. It lets you order one piece to test fit, then five, then the full run. Be careful with a supplier that advertises no MOQ but quietly adds a setup charge that only makes sense at volume.

The classic cheap-quote traps are predictable. A low piece price with an expensive one-time setup. A quote that excludes finishing, which doubles the landed cost. A tolerance callout that was quietly loosened. A finish spec that was ignored because it appeared only in a note.

Compare landed cost, not unit price. Include finishing, inspection reports, packaging and freight.

• 1
  Setup chargesAsk whether fixture and programming cost is one-time or repeated per order.
• 2
  Finishing exclusionsAnodizing and plating often sit outside the machining quote.
• 3
  Tolerance driftCheck that the quoted tolerance matches the drawing, not a looser default.
