PA66 is semi-crystalline. The ordered regions give it high stiffness, good fatigue resistance and a useful service temperature range, but they also make the material directionally different from aluminum or steel. Cutting forces push the polymer instead of cleanly shearing it, so the tool has to be very sharp and the chip has to leave the cut immediately. A dull cutter rubs, generates heat, and the surface turns gummy.

The bigger issue is water. Nylon 66 absorbs moisture from the air until it reaches equilibrium with its surroundings. A blank sitting in a humid warehouse is not the same size as the same blank after a week in a dry room. If you machine the wet blank, the finished part shrinks as it dries and your measured dimensions drift undersize. If you machine a very dry blank and the part then takes on moisture in service, it grows.

Thermal conductivity is low. Heat stays at the cutting edge instead of flowing into the chip or the workpiece, which is why PA66 melts locally at spindle speeds that would be unremarkable in aluminum. The practical result: moderate feeds, high spindle speed, generous chip clearance, and a plan for removing heat before it softens the surface.

None of this makes the material a bad choice. It makes the process specification the deciding factor. Two shops can cut the same drawing and deliver parts that behave differently in the field, purely because one controlled moisture and the other did not.

• 1
  HygroscopicDimensions track moisture content, not just temperature.
• 2
  Low thermal conductivityHeat concentrates at the edge and softens the surface.
• 3
  Abrasive fillersGlass or carbon filled grades wear tooling faster than unfilled PA66.

Wall thickness drives everything. A uniform 2–4 mm wall cools and equilibrates at a predictable rate. A part that jumps from 3 mm to 8 mm in one step sets up a moisture gradient, and the thick section moves more than the thin one. If the function allows it, keep walls consistent and add ribs rather than mass.

Flat plates are the hardest geometry to hold. A thin plate in PA66 will bow after machining as moisture redistributes through the section. If the drawing calls for flatness under 0.1 mm across a large face, expect to machine in more than one pass, flip the part, and check it after conditioning. Sometimes the honest answer is to change the geometry or the material.

Tapped holes and press fits need margin. A thread cut into dry PA66 tightens as the part absorbs moisture; a press fit that measures correctly on the bench may loosen in a humid plant. Specify the fit condition in the drawing notes, and say whether the mating part is metal or plastic.

Sharp internal corners are stress risers in a notch-sensitive polymer. Add a radius of at least 0.5 mm wherever the function allows. It costs nothing on the machine and removes a common cracking site.

• 1
  Keep walls uniform2–4 mm nominal, ribs instead of thick bosses.
• 2
  Call out flatness separatelyLarge thin faces need extra passes and conditioning time.
• 3
  State the fit conditionDry, as-machined, or equilibrated at 50% RH.

Conditioning is a controlled drying and re-absorption cycle. Stock is dried to a low moisture level so it is dimensionally stable and machines cleanly, then held in a controlled environment. For tight-tolerance work, some shops machine to a compensated size that anticipates the final equilibrium moisture content. That compensation only works if the target humidity is known.

Coolant is the second decision. Water-based flood coolant puts moisture directly at the cut and into chips that sit on the part. Most plastics jobs run better with compressed air or a light mist, which clears chips and carries heat away without wetting the surface. If a shop insists on flood coolant for PA66, ask how they keep the part dry between operations.

Tooling follows from the same logic. Use sharp, polished carbide or high-speed steel with positive rake angles and wide flutes. Replace or re-hone edges on a schedule rather than waiting for visible wear, because a slightly dull tool still cuts metal acceptably but smears nylon. Glass-filled grades need more frequent changes.

Fixturing deserves attention too. Clamping pressure that is fine on aluminum will distort a nylon part and relax over the cycle. Light, distributed clamping with soft jaws holds the part without squeezing it out of tolerance.

• 1
  Dry, machine, equilibrateInspect after the part stabilizes, not straight off the machine.
• 2
  Air or mistAvoid water-based flood coolant on unfilled PA66.
• 3
  Light clampingSoft jaws and distributed pressure prevent distortion.

GreatLight holds ±0.005 mm on metals where the geometry and setup allow it. That figure is a machine and process capability, not a promise that every PA66 feature will land there. On plastics, the material itself sets the floor. A compact bushing with a 3 mm wall is a very different proposition from a 300 mm plate with a 2 mm wall.

A practical approach is to grade your callouts. Functional diameters, bearing bores and mating surfaces get the tight tolerance. Clearance holes, outer profiles and non-critical depths get a general tolerance that reflects what the material can hold. This reduces cost and, more importantly, reduces the chance that a shop chases an impossible number by over-clamping or over-cutting.

Surface finish is similarly bounded. As-machined PA66 typically lands around Ra 1.6–3.2 μm. Finer finishes, in the Ra 0.8–1.6 μm range, are achievable with sharp tooling and light finishing passes, but a mirror finish on an unfilled nylon part is not a stable target because the surface dulls as the part takes on moisture.

Ask the shop to state the inspection condition. A dimension measured one hour after machining and the same dimension measured after three days of equilibration may differ. Good suppliers record both and tell you which one they are certifying against.

• 1
  Grade the calloutsTight only where the fit demands it.
• 2
  Finish has a ceilingRa 1.6–3.2 μm as-machined; 0.8–1.6 μm with finishing passes.
• 3
  Name the inspection conditionAs-machined or equilibrated — the number is not the same.

A quote that lists only a price and a lead time tells you very little about a plastics job. The useful quote names the grade, the stock condition, the coolant strategy, the inspection condition and the tolerance actually being certified. If any of those are missing, the price is not comparable to another shop's price.

Volume flexibility matters more on plastics than on metals, because prototypes and production parts often come from the same drawing. A supplier who can run one part and 10,000 parts without a tooling change keeps your design iteration fast. GreatLight runs no minimum order quantity, from a single prototype to 10,000+ part runs.

Certification is a filter, not a substitute for process knowledge. ISO 9001:2015 covers quality management. IATF 16949:2016 matters for automotive and EV programs. ISO 13485:2016 applies to medical devices. ISO 27001:2022 covers information security, which is relevant when you are sending CAD files to an overseas supplier.

Timing is part of the decision. A quotation and free DFM analysis within 12 hours, production starting within 24 hours and parts shipping in 3–5 days keeps a design loop moving. Ask for the DFM notes in writing, especially on wall thickness and tolerance grading, so the feedback survives the next design revision.

• 1
  Quote should name the processGrade, conditioning, coolant, inspection condition.
• 2
  No minimum order quantityOne prototype through 10,000+ part runs.
• 3
  Written DFM notesWall thickness and tolerance feedback you can act on.
