The magnet does not care how good your surface finish is. It cares whether your part is ferromagnetic. Anything that sits inside the bore, on the patient table, or within the fringe field has to be non-magnetic, and that rules out most carbon and alloy steels no matter how cheap they are.

For structural brackets and housings, 316L and 316 stainless are the usual starting point. They machine well, resist corrosion, and stay non-magnetic after cold working in most geometries. 304 is a lower-cost alternative when the part is thin and the field is weak. If weight is the constraint, 6061-T6 and 7075 aluminium are common, and Ti-6Al-4V shows up in fixtures and implants that must also be biocompatible.

There is a trap with austenitic stainless. Cold working, deep drawing, or aggressive milling can push a small amount of martensite into the surface, and the part becomes weakly magnetic. If your geometry involves heavy deformation near the field, ask for a permeability check on the finished part, not only on the raw bar.

Copper and brass are non-magnetic but they are conductive. In a switching gradient coil environment, eddy currents can cause heating or image artefact. That is a system-level question, so flag any copper part in your RFQ so the supplier knows it is not a simple bracket.

• 1
  Safe default316L for structure, 6061-T6 for light brackets
• 2
  Watch cold workHeavy milling can make 304 slightly magnetic
• 3
  Conductive metalsCopper and brass need an eddy-current review
• 4
  Document the gradeAlloy and temper must appear on the drawing

A tolerance of ±0.005 mm is achievable on a good 5-axis machine, but it is not free and it is not needed everywhere. The features that locate a gradient coil, a shim tray, or a receive-only coil former usually carry the tight tolerance. The rest of the part can sit at ±0.05 mm and nobody will notice.

Ask the supplier to mark which features will be held tight and which will be general. A quote that puts ±0.005 mm on the whole drawing is either padding the price or hiding that it cannot hold it. Both are bad signs.

Geometry matters as much as the numbers. Thin walls under 1 mm deflect during milling, and that deflection is not visible on a CMM report taken after the part has sprung back. If your design has thin ribs, say so, and ask about support strategy and light finishing passes.

For long parts, thermal drift is the quiet failure mode. Aluminium grows about 23 μm per metre per degree Celsius. A 400 mm aluminium bracket machined in a warm shop and measured in a cold inspection room can move more than the tolerance band. The fix is simple: let the part soak at inspection temperature before measuring.

For MRI hardware, the inspection file is part of the product. A dimensional report with the actual measured values, not just pass or fail, tells you whether the process was in control or barely scraped through.

GreatLight inspects 100% of parts before shipment: raw material check, in-process monitoring, and final inspection, with reports on request. That is the baseline. Ask what gauge was used, when it was last calibrated, and whether the report is signed.

If the part carries a permeability requirement, a dimensional report is not enough. You need a permeability or magnetic susceptibility reading, and it should come from the finished part. Raw material certificates do not cover the effect of machining.

Keep the traceability chain intact. Material certificate, heat number, machining lot, inspection record. If a hospital later asks why a component behaved a certain way, a supplier that cannot produce that chain is not a medical-grade supplier.

Four certificates come up again and again in MRI and medical sourcing: ISO 9001:2015 for the quality system, ISO 13485:2016 for medical devices, IATF 16949:2016 for automotive, and ISO 27001:2022 for information security. Each one answers a different question.

ISO 9001 tells you the shop has a controlled process. ISO 13485 tells you it understands medical device documentation, traceability and risk. IATF 16949 tells you it can run disciplined production at volume, which matters if the program will scale. ISO 27001 covers how your drawings and patient-adjacent designs are protected.

Ask for certificate numbers and the scope statement. A certificate that does not cover the plant doing your work is not much use. This is a common gap when a supplier has multiple sites.

• 1
  ISO 9001:2015Baseline quality management system
• 2
  ISO 13485:2016Medical device documentation and traceability
• 3
  IATF 16949:2016Disciplined volume production
• 4
  ISO 27001:2022Information security for your files

MRI programs often start as one prototype and grow into a small production run. A supplier with a high minimum order quantity forces you to buy parts you cannot use yet. No minimum order quantity, from one prototype to 10,000+ part runs, removes that friction.

On speed, a realistic benchmark is quotation and free DFM analysis within 12 hours, production start within 24 hours, and parts shipping in 3–5 days. Treat any quote that promises much faster without explaining how as a warning.

The cheapest quote usually moves cost somewhere else. It shows up as a hand-finished critical bore, a missing inspection file, or a rework cycle that eats the savings. Compare total landed cost, including the engineering time you spend chasing the supplier.

Ask about capacity before you commit. A shop running 127 high-precision CNC machines, including 16 simultaneous 5-axis centers and 16 mill-turn centers, can absorb a schedule change. A two-machine shop cannot.
