Mobile Power Supply Design: What CNC Machining Decides
A power bank is a battery, a board and a case. The case is where most field failures start. This page explains how mobile power supply design turns into machined parts: heat paths, wall thickness, sealing, drop loads and the tolerances that hold a connector in place. Written for hardware engineers and sourcing teams who need to judge a design before tooling.
Why mobile power supply enclosures are usually aluminum
A 20,000 mAh pack pushing 65 W loses roughly 8 to 12 percent of that energy as heat inside the enclosure. In a sealed plastic shell the heat has one path out: radiation and slow convection through the walls. An aluminum body spreads that heat across the whole surface. The cells and the switching stage stay cooler, and the pack can hold full output longer before it derates.
The gain is not automatic. Aluminum only helps if the heat-generating parts actually touch it. A board floating 3 mm above the floor of a machined pocket still heats trapped air. We machine a raised boss under the MOSFET pair and under the inductor, then lap that boss flat so the thermal pad makes full contact. Contact area matters more than total metal mass.
Wall thickness is the second lever. Below 0.8 mm, a 6061 wall dents under thumb pressure and the anodized skin can crack at the corner radius. Between 1.0 and 1.5 mm the wall stays stiff and still sheds heat well. Going thicker than 2 mm adds weight and cost without a measurable temperature drop.
One caveat: aluminum is conductive. Any pack with an exposed aluminum face needs an insulating layer, a non-conductive anodize, or a plastic carrier inside. This is a safety boundary, not a finish preference.
How sealing, ports and buttons drive the tolerance stack
A USB-C port that sits 0.15 mm proud of the shell looks fine on a drawing. In the hand it feels sharp, and repeated cable insertion wears the plating. The port face should sit flush within ±0.1 mm of the outer wall. That number comes from the connector height, the PCB thickness and the machined pocket depth together, not from any single part.
We hold ±0.005 mm on critical features such as connector pockets and screw bosses. General cosmetic surfaces can run at ±0.1 mm. Mixing the two in one drawing is normal, but each callout needs a reason. Tightening a decorative edge does nothing except raise the price.
Buttons are the usual source of rattle. A 0.2 mm gap around a plastic button is audible. Machined aluminum buttons with a 0.05 to 0.08 mm clearance and a silicone return feel solid and still move freely. Test the stack with the finish applied, because anodize adds 10 to 25 μm per surface.
Gaskets set the ingress rating. A 1.0 mm silicone cord in a 0.7 mm machined groove compresses about 30 percent, which is the range where it seals without taking a set. A groove that is too shallow leaks; one that is too deep lets the gasket roll out during assembly.
Drop loads, stiffness and where the case fails first
Most power bank returns are not electrical. The shell cracks at a corner, a boss shears off, or the two halves separate after a fall. A 200 g pack dropped from 1 m lands with a peak force several times its own weight, and that load travels through the screw bosses and the corner radii.
Sharp internal corners concentrate stress. We keep internal radii at 1.0 mm or larger, and at 1.5 mm on any wall above 1.5 mm thick. External corners get 2 to 3 mm so the anodize does not thin out. These are cheap changes at the drawing stage and expensive ones after tooling.
Screw bosses need wall thickness around twice the screw diameter. An M2 screw in a 6061 boss wants roughly 4 mm of surrounding material and at least 3 mm of thread engagement. Thin bosses strip on the second teardown, which matters for any pack that is meant to be serviced.
If the pack is potted or glued shut, the joint becomes the weak point. A machined tongue-and-groove joint with 0.1 mm clearance and structural adhesive spreads the load far better than two flat faces pressed together.
Material and process choices for mobile power supply cases
| Option | Best for | Watch out for |
|---|---|---|
| 6061-T6 aluminum | High-wattage packs, fast charging | Needs internal insulation from cells |
| 5052 aluminum sheet | Thin, light housings | Lower stiffness, more flex in the hand |
| ABS injection molding | High volume above 10,000 units | Tooling cost and long lead time |
| PC or PC/ABS | Impact-resistant consumer shells | Poor heat spreading at 45 W and above |
| Zinc die casting | Complex thin ribs in one shot | Heavier than aluminum, porous surfaces |
| Machined POM or PEEK | Prototype internals, insulators | Not for structural outer shells |
When to machine and when to mold
Choose CNC machining for prototypes, low volume, or any pack above 45 W where the shell is also the heatsink. Choose injection molding only when the annual volume passes roughly 10,000 units and the design no longer changes.
Questions engineers ask before release
How tight should the connector pocket tolerance be?
Hold the pocket to ±0.05 mm and the port face flush within ±0.1 mm of the outer wall. That range keeps cable insertion smooth and stops the connector from standing proud. Looser than ±0.15 mm and buttons or ports start to rattle in the hand.
Does anodizing change the fit of machined parts?
Yes. Anodize adds 10 to 25 μm per surface depending on the type. On a Ø8 mm bore that is enough to close a slip fit. Specify the finish on the drawing and measure after coating, not before.
What wall thickness works for a machined aluminum power bank?
1.0 to 1.5 mm is the practical band for 6061. Under 0.8 mm the wall dents easily and the anodized layer can crack at corners. Over 2 mm you add weight and machining time with little thermal benefit.
Can a machined case reach an IP rating?
Yes, with a proper gasket groove. A 1.0 mm silicone cord in a 0.7 mm groove compresses about 30 percent, which is the sealing range. The rating also depends on the port doors and the joint between the two halves, not the gasket alone.
Which materials suit a pack that also acts as a heatsink?
6061-T6 and 5052 aluminum are the usual picks. 6061-T6 holds stiffness at 1.2 mm walls and spreads heat well. Copper spreads better but is heavy and costly. Plastics remove the thermal path entirely, so the board needs its own heatsink.
How do we keep the internals confidential during quoting?
Uploads are handled as confidential and an NDA is available on request. Send STEP files and a short description of the function; we return a DFM analysis and a quotation, typically within 12 hours.
