On a CNC horizontal axis rotary table surface grinder the spindle sits parallel to the floor and the grinding wheel turns in a vertical plane. The work is clamped to a round table that rotates about a vertical axis. As the table turns, the wheel edge sweeps a ring across the face of the part instead of travelling in a straight line.

That single change in geometry drives most of the machine's behavior. The wheel contacts the work along an arc whose length depends on depth of cut and wheel diameter. A 350 mm wheel taking 0.02 mm passes roughly 8 mm of arc contact. A reciprocating grinder with the same wheel sees the same arc, but only at the reversal points of the stroke, and it spends most of the cycle accelerating and decelerating a heavy table.

The rotary design keeps table speed constant through the whole revolution. Acceleration only happens at the start and end of the cycle, not at every stroke reversal. On small parts this is a minor difference. On a 300 mm diameter ring it is the difference between a stable spark-out and a chatter pattern that shows up on a profilometer.

There is a trade-off. Rotary grinding cannot produce a flat rectangular face across the full table in a single setup the way a long reciprocating machine can. The useful work zone is an annulus, not a rectangle. If your part is a 600 × 200 mm plate, a rotary grinder is the wrong machine.

• 1
  Contact arcSet by wheel diameter and depth of cut, typically 5–12 mm on finishing passes.
• 2
  Constant table speedNo stroke reversal, so no reversal-induced load spikes.
• 3
  Annular work zoneRound and ring-shaped parts only; long rectangles belong on reciprocating machines.

The rotary table is a precision bearing assembly. Most machines use a crossed-roller or hydrostatic bearing under a hardened steel faceplate. Axial runout, radial runout and tilt all matter, but tilt is the one that ruins flatness. A 0.005 mm tilt across a 400 mm table face becomes a 0.005 mm taper across any part ground on it, no matter how good the wheel is.

Table speed is set in surface meters per minute at the grinding zone, not in rpm. For a 200 mm diameter part, 20 m/min means about 32 rpm. For a 400 mm part, the same 20 m/min means 16 rpm. The controller has to compensate if you want the same specific removal rate at the outer edge as at the inner edge. Most CNC controls do this automatically once you enter the part diameter.

Thermal growth is the other error source. The table bearing and the spindle both heat up during a long run. A machine that holds ±0.005 mm cold can drift to ±0.015 mm after two hours of continuous grinding if the coolant temperature is not controlled. On our machines we run coolant through a chiller and hold it within ±1 °C, which keeps the table face stable enough for the tolerance to hold across a full shift.

Dressing is not optional. A glazed wheel rubs instead of cutting, and the heat goes into the part. On a rotary table the wheel edge does most of the work, so a diamond dresser mounted on the table can true the wheel in place without breaking the setup.

• 1
  Tilt errorThe dominant flatness error; check with a precision level or electronic level on the table face.
• 2
  Speed compensationEnter part diameter so the control holds constant surface speed.
• 3
  Thermal controlChilled coolant within ±1 °C keeps the table face stable over long runs.

Aluminum oxide wheels in the 46 to 60 grit range cover most steel and cast iron work on a rotary table. For stainless and tool steel, a slightly softer grade (H to J) keeps the wheel self-sharpening and reduces burn. For aluminum, silicon carbide or a coarse aluminum oxide wheel with a wax or oil lubricant prevents loading. Cubic boron nitride is worth the cost when you are grinding hardened steel above 55 HRC and want to hold form on the wheel edge.

Depth of cut on a rotary grinder is usually lighter than on a reciprocating machine because the contact arc is continuous. Roughing passes of 0.02 to 0.04 mm are common. Finishing passes drop to 0.005 to 0.01 mm, followed by two or three spark-out revolutions with no infeed. Spark-out is where the surface finish is actually made. Skipping it leaves a finish that looks fine under shop light but measures Ra 1.6 μm instead of Ra 0.4 μm.

Table speed and wheel speed work together. Wheel surface speed stays in the 30 to 35 m/s range for aluminum oxide. Table speed is set by the finish you need. Faster table speed improves cycle time but raises the specific removal rate per grit, which increases wheel wear and roughness. For a Ra 0.2–0.8 μm finish, a table speed of 15 to 25 m/min at the grinding zone is a practical starting point.

Coolant matters more than most operators expect. Straight oil gives the best finish and the least burn on tool steel. Water-based coolant with a high concentration of rust inhibitor is fine for aluminum and most stainless, but it evaporates faster and needs a higher flow rate to flood the contact zone.

• 1
  Aluminum oxide 46–60 gritDefault for steel and cast iron; softer grades for stainless.
• 2
  CBN for hardened steelHolds form above 55 HRC and lasts longer between dresses.
• 3
  Spark-outTwo or three no-infeed revolutions turn a rough surface into a fine one.

The process can hold ±0.005 mm on parallel faces of a ring or disc when three conditions are met: the part is rigid enough to clamp without distortion, the table is within its thermal window, and the wheel is freshly dressed. Miss any one of those and you are in the ±0.015 to ±0.025 mm range, which is still fine for many parts but not for a seal face or a bearing spacer.

Thin rings are the hard case. A 200 mm diameter, 3 mm thick washer will deflect under the magnetic chuck unless you use a segmented pole or a fixture that supports the bore and the outer edge. Once clamped, the part springs back when you release it, and the flatness you measured on the machine is gone. We check flatness after release, never on the chuck.

Taper is the second common error. It shows up as a difference in thickness between the inner and outer edge of a ring. The cause is almost always table tilt or wheel head alignment, not the grinding parameters. A 0.01 mm tilt across a 400 mm table produces 0.01 mm of taper on a part that spans the full table.

Surface finish and flatness are not the same thing. A part can measure Ra 0.4 μm and still be 0.01 mm out of flat because the wheel followed the part's existing curvature. Fine finish comes from a dressed wheel and a spark-out. Flatness comes from machine geometry, clamping and thermal stability.

• 1
  Rigid partsRings and discs over 8 mm thick hold ±0.005 mm reliably.
• 2
  Thin partsUnder 5 mm thick, expect to fight deflection; use segmented chucks.
• 3
  Taper sourceAlmost always table tilt, not feed or speed.
