Ten years ago a die casting quote was mostly about tonnage and cycle time. You sent a drawing, a caster quoted a die, and the part arrived with flash and draft angles. Machined features were handled by a second shop that you found yourself.

That split still exists, but the parts have changed. Housings for EV inverters, robot joints and medical pump bodies now carry machined bores, sealing faces and threaded ports on the same casting. A casting that is 0.3 mm out of position is no longer acceptable, because the CNC operation that follows has to hold ±0.005 mm on features that reference the as-cast surface.

So when you compare OEM metal die casting companies, you are not only comparing furnaces and dies. You are comparing how the supplier controls the transition from a rough casting to a finished, inspected part.

The suppliers that handle that transition well tend to look different on paper from the ones that do not.

• 1
  Cast featuresDraft, radii, wall thickness, ejector marks
• 2
  Machined featuresBores, faces, threads, sealing grooves
• 3
  The interfaceDatum choice and stock allowance decide both

Ask who owns the die and where it is cut. When a broker sub-contracts the tool to a third shop, a drawing change in week three becomes a negotiation between two companies that have never met your engineer. Tool repair queues also stack up behind other customers' dies.

A manufacturer that cuts and maintains dies in the same plant can pull a die for welding or re-polishing without a shipping cycle. That matters most on thin walls and deep ribs, where the first shots usually need vent and gate adjustment.

Ask how many shots the die is rated for and what the maintenance interval is. A 100,000-shot die run at 60 percent of its rated clamp force will not reach that number. If the supplier cannot tell you the tonnage they plan to run, they have not planned the tool.

Ownership also decides your exit cost. If the die sits at a third party, moving production later means paying for transport, re-qualification and a possible re-cut. Get the die ownership clause in writing before the first shot.

Casting alone rarely ships. Most OEM die cast parts need facing, boring, tapping and sometimes 5-axis contouring on angled faces. If those operations live at a different company, the tolerance stack grows and nobody owns the final number.

An integrated shop can machine the casting on the same site, using the as-cast surface as a datum. With 5-axis work, angled ports and contoured sealing faces are cut in one setup instead of three. That is where ±0.005 mm on a machined bore becomes repeatable rather than lucky.

Ask what stock allowance the caster leaves for machining. Typical practice leaves 0.3 to 0.8 mm on machined faces, depending on draft and part size. Too little and the cutter hits hard spots or porosity; too much and cycle time climbs.

Large housings need a machine that can reach them. A 4,000 mm maximum processing size covers most enclosure work, and a Ø400 mm rotary table handles round flanged parts without re-fixturing.

ADC12 is the default for many aluminium castings and it machines well, but it is not the right answer for every part. A356 and A360 behave differently in thin walls. Magnesium AZ91D is lighter and harder to handle, and it brings its own corrosion rules.

A supplier who only pours one alloy will quote your part in that alloy. That is fine for a bracket and wrong for a pressure-tight housing. Ask what they pour weekly, not what they can pour in theory.

Post-cast machining also depends on alloy. 6061 and 6082 bar stock appear in hybrid designs where a casting is welded or bolted to a machined component. If your assembly mixes cast and wrought aluminium, the supplier needs both capabilities.

For parts that will be anodized or hardcoated, the alloy and the surface finish of the casting both matter. Blistering and colour variation usually trace back to gas porosity, not to the anodizing line.

A certificate on a website is not a quality system. What matters is what happens to your part between the casting cell and the shipping box. Ask for the inspection plan, not the certificate PDF.

A workable plan for a machined casting has three stages: incoming material check, in-process monitoring during casting and machining, and a final dimensional inspection before shipment. Reports should be available on request, with CMM data on the critical features you name.

Certification depth tells you which industries the supplier can serve without a special project. ISO 9001:2015 covers general work. IATF 16949:2016 is what automotive programs expect. ISO 13485:2016 applies to medical devices, and ISO 27001:2022 covers how your drawings and CAD files are protected.

A 99.99% qualification rate sounds like a slogan until you ask how it is measured. Push for the definition: first-pass yield on machined features, or final inspection pass rate. Those are different numbers.

The broker model still works. If your part is a simple bracket in ADC12 with no machined features, a sourcing agent can find three casters and get you a competitive die price. You will manage the tool and the freight, and you will keep the drawing simple.

The integrated model wins when the casting carries functional features. Bores that must seal, faces that must be flat within 0.05 mm, threads that must hold torque. Every one of those features creates a handoff, and every handoff is a place where the tolerance and the schedule can slip.

A third case is low-volume work. If you need 50 castings for a pilot line, a broker will push you toward a die you cannot amortize. An integrated plant that also runs prototypes can vacuum cast or machine from billet first, then move to die casting once the design freezes.

There is no universal winner. Match the model to how much of the part is machined, how tight the sealing features are, and how many suppliers you can realistically manage in one program.

• 1
  Choose the brokerSimple cast geometry, no critical machined features
• 2
  Choose the integrated plantMachined bores, sealing faces, tight datums
• 3
  Choose a hybrid routePilot quantities before committing to a die
