Depth drift is the most common complaint on engraving and milling machines. The mark starts at the correct depth and slowly rises or sinks along the path. In most cases the Z-axis itself is fine and the real cause sits between the spindle nose and the workpiece. A collet that was tightened by hand, a holder that picked up a chip on the taper, or a workpiece that moved 0.02 mm in the vise all show up as depth variation.

Start with the tool. Measure tool runout at the flute with a dial indicator. On a finishing engraving cutter, runout above 0.01 mm will produce visible width change. On aluminium at 6061, a light finishing pass of 0.1-0.2 mm depth removes the witness mark without loading the cutter. If runout is within spec, check the tool length offset. A wrong offset of 0.05 mm is enough to change a fine engraving line into a scratch.

Then check the workpiece. Thin plates clamped only at two corners will spring during the cut. Support the plate under the engraving area or use a vacuum fixture. For plastics such as PMMA, cutting heat softens the surface and the cutter sinks. Drop spindle speed to 8,000-12,000 rpm and add air blast to keep the chip clear.

Finally, verify backlash. Command a 0.05 mm Z move and measure the actual displacement. If the table does not move until 0.03-0.04 mm is commanded, backlash compensation is needed. On machines with a rotary table, backlash in the A or B axis shows as a taper across a circular engraving. Warm the machine for 20-30 minutes before measuring, because thermal growth alone can shift Z by 0.01-0.02 mm on a cold morning.

• 1
  Runout firstMeasure at the flute, not the shank. Keep below 0.01 mm for fine engraving.
• 2
  Workpiece supportThin plates need support under the cut area, not just at the edges.
• 3
  Backlash testCommand 0.05 mm and compare actual movement before compensating.

Chipping on aluminium and brass is usually a feed and speed problem, not a machine problem. When the chip is thin and blue, the cutter is rubbing instead of cutting. Increase feed per tooth to 0.03-0.05 mm for a 3 mm cutter in 6061 and keep the chip load constant. If the edge still chips, the cutter geometry is wrong for the material. Aluminium needs a 2-flute cutter with a polished flute and high helix. Brass prefers a neutral or slightly negative rake so the tool does not dig in.

On stainless steel such as 304 or 17-4PH, work hardening is the main enemy. A dull cutter rubs the surface, hardens it, and the next pass breaks the edge. Keep the cutter engaged and never let it dwell. Use a feed per tooth of at least 0.02 mm and a depth of cut below 0.5 mm for a 3 mm cutter. Flood coolant or high-pressure air keeps the cutting zone below the hardening temperature.

Burrs on the exit edge tell you the material is being pushed rather than sheared. Reduce the exit angle, add a chamfer, or run a light finishing pass at 0.05-0.1 mm. For plastics, a sharp cutter with a 0-5° rake and a spindle speed of 12,000-18,000 rpm leaves a clean edge on POM and PC.

Tool wear is not linear. A cutter that has run 30 minutes in 6061 may still cut clean, then fail suddenly. Track cutting time per tool and replace at 80% of expected life. On a 3 mm carbide cutter in aluminium, 4-6 hours of cutting is a reasonable change point. On stainless, cut that to 1-2 hours.

• 1
  Chip loadThin blue chips mean rubbing. Aim for 0.03-0.05 mm per tooth in aluminium.
• 2
  Stainless ruleNever dwell. Keep the cutter moving to avoid work hardening.
• 3
  Tool life trackingLog cutting time per tool. Replace before sudden failure, not after.

Spindle noise that rises with load points to bearings or belt tension. Run the spindle at 6,000 rpm unloaded and listen. A growl that disappears above 10,000 rpm is usually a bearing preload issue. A squeal at all speeds is a belt slipping or a worn pulley. Check belt tension by pressing the midpoint. It should deflect 5-8 mm with moderate thumb pressure.

Vibration during engraving shows as a wavy pattern on the surface. The source is often the tool holder or the workpiece, not the spindle. A holder with 0.02 mm runout will vibrate at high speed. Balance the holder and keep the tool overhang below 4× the tool diameter. On a 3 mm cutter, keep overhang under 12 mm. Long overhang amplifies every small error.

Axis positioning faults appear as a slow drift in one direction. The servo may fail to return to origin or overshoot. Check the encoder coupling first. A loose coupling slips under load and the axis loses position. Then check the limit switch. A switch that triggers 0.1 mm early will shift the origin every cycle. Re-home the axis and compare the machine coordinate with a known reference.

Thermal growth is the quiet cause of positioning drift. A machine that has run for two hours will have a warmer ballscrew than a cold one. On a 4,000 mm travel machine, a 5 °C rise can move the table 0.02-0.04 mm. Warm up for 20-30 minutes before critical work and use the same warm-up routine every shift.

• 1
  Belt check5-8 mm deflection at midpoint with thumb pressure.
• 2
  Overhang limitKeep tool overhang under 4× diameter to reduce vibration.
• 3
  Warm-up routine20-30 minutes before critical engraving on long-travel machines.

A tool magazine that will not index is usually a mechanical jam, not a control fault. Chips or coolant sludge in the pocket stop the cam from rotating. Clean the pocket with air and check the cam follower for flat spots. If the magazine indexes but the tool does not clamp, check the drawbar spring. A weak spring holds the tool loosely and the cutter pulls out during a heavy cut.

Pressure loss in the hydraulic circuit shows as weak clamping, slow tool change, or a spindle that will not release. Check the filter first. A clogged return filter raises back pressure and the pump cannot hold the set value. Replace the filter and check the relief valve setting. If pressure still drops, look for a leaking seal on the cylinder. A seal that leaks 1-2 drops per minute will drain the accumulator over a shift.

Cooling problems are easy to miss because the machine keeps running. Low coolant flow raises cutting temperature, which changes the cut depth on plastics and work-hardens stainless. Check the nozzle for blockage and the tank level. On a machine cutting aluminium, keep the concentration at 6-8% and top up with the same mix. Mixing brands causes the coolant to separate and clog the lines.

Electrical faults in the cooling or hydraulic system often show as intermittent alarms. A loose terminal on the pump contactor will trip the overload under load and reset when cool. Check terminal torque every 2,000 hours. On machines running 24 hours, that is roughly every three months.

• 1
  Magazine jamClean pocket and inspect cam follower for flat spots.
• 2
  Hydraulic filterReplace before adjusting pressure. A clogged filter mimics a weak pump.
• 3
  Coolant mixKeep aluminium at 6-8% concentration. Do not mix brands.

Some defects look like machine faults but come from the material. Aluminium 7075 machines clean but can leave a smeared edge if the cutter is too sharp and the feed too low. Increase feed per tooth to 0.04-0.06 mm and use a light air blast. Aluminium 6061 is more forgiving and runs well at 0.03-0.05 mm per tooth.

Titanium Ti-6Al-4V and Inconel generate heat fast and do not conduct it away. The cutter edge softens and the surface tears. Keep cutting speed low, 30-50 m/min for carbide in titanium, and use high-pressure coolant. If the surface has a rainbow tint, the cutting zone is too hot. Reduce speed by 20% and check coolant aim.

Plastics such as PEEK and carbon fibre need sharp cutters and controlled chip evacuation. PEEK melts at the edge if the spindle speed is too high. Run at 8,000-12,000 rpm with a 2-flute cutter and a feed of 0.05-0.1 mm per tooth. Carbon fibre dust is abrasive and wears the cutter fast. Replace the cutter after 30-45 minutes of cutting to avoid delamination.

Brass C36000 cuts freely but grabs if the rake angle is too positive. Use a neutral rake and a feed per tooth of 0.03-0.05 mm. If the part shows a torn edge, the cutter is digging in. Reduce depth of cut to 0.2-0.3 mm and check the tool holder for runout.

• 1
  7075 smearingRaise feed per tooth to 0.04-0.06 mm and add air blast.
• 2
  Titanium heatRainbow tint means too hot. Drop speed 20% and check coolant.
• 3
  Carbon fibreReplace cutter every 30-45 minutes to avoid delamination.
