Bar inventory is the stock of round, hexagonal, or square bar kept in the shop. CNC turn processing of bar inventory is the work of taking that stock and reducing it to a finished diameter, length, thread, bore, or profile on a lathe. The bar is the input. The sorted, inspected part is the output.

The lathe rotates the bar while a single-point tool feeds along it. Each pass removes a set depth of material. A roughing pass might take 2–4 mm of radial stock on aluminum, 1–2 mm on stainless. A finishing pass takes 0.1–0.3 mm to set the final diameter and surface finish.

Two things separate bar-fed turning from other machining. First, the bar must be gripped on its outside diameter, usually by a collet, so the grip diameter must match the bar diameter within a few hundredths of a millimeter. Second, the bar must be fed forward as each part is cut off, which means the bar must be straight and consistent along its length.

That second point is where sorting enters the process. Bar that falls outside the diameter, straightness, or hardness window does not just make a bad part. It stops the machine, wastes a collet, or breaks a tool. Sorting is what keeps the bar feed running.

Bar stock is not one diameter. A cold-drawn 303 stainless bar purchased as Ø12 mm might measure Ø11.95 mm at one end and Ø12.02 mm at the other. Hot-rolled or extruded bar varies more. That spread is normal, and it sets the practical limit on how the collet can hold the bar.

A collet has roughly 0.5–1.0 mm of elastic travel. If the bar is undersized, the collet closes further and the grip becomes uneven. If the bar is oversized, the collet will not close at all. In both cases, the part can slip or be pushed back into the spindle during the cut-off. That is why bar sorting is a dimensional task, not a visual one.

In a bar-fed cell, the magazine holds bars of one nominal diameter. If the bar diameter drifts more than about ±0.05 mm from nominal, the feed mechanism may not push the bar through the guide bushing or the collet. The operator then has to stop the machine, pull the bar, and re-sort the rack. Each stop costs cycle time and risks a scrap part.

Sorting before loading is cheaper than sorting after. Bars are checked for diameter at three points along the length, for straightness, and for visible seams or laps. Bar that passes goes into the magazine. Bar that fails goes back to the supplier or gets set aside for a chucked job where grip length matters less.

• 1
  Diameter checkMeasure at three points along the bar, not just one.
• 2
  Straightness checkRoll the bar on a flat plate; a gap over 0.5 mm per meter is a flag.
• 3
  Surface checkSeams, laps, and scale mark bar that will not clean up.
• 4
  Hardness checkA hard spot at the bar end can break a cut-off tool.

On a fixed-head lathe, the bar is held by a collet and the tool moves in Z. The collet must close on the bar with enough force to resist the cutting load without crushing the bar. For aluminum bar, a spring collet works. For hardened or thin-walled bar, a boring-out collet or a split bushing may be needed.

On a sliding-head (Swiss-type) machine, the bar is held by a guide bushing and the bar moves forward while the tool stays near the bushing. The guide bushing clearance is tight, often 0.01–0.02 mm on the diameter. That is the reason a Swiss machine wants ground, sorted bar. A bar that varies by 0.03 mm will not pass the bushing cleanly.

The guide bushing sets the diameter window. If the bar is at the high end of the window, the bar may seize in the bushing as it warms up. If it is at the low end, the bar can chatter and the part will show a lobed or faceted surface. Sorting to a narrower band around nominal is the fix.

For parts with a long unsupported length, the bar can whip. The bar diameter and the spindle speed set the whip limit. A Ø12 mm bar at 4,000 rpm is near the limit for a 1 m bar without a bar support. Fitting a bar support or reducing the max spindle speed is the usual answer.

The practical rule: match the bar diameter to the machine's collet or bushing, not to the part. The part diameter can be smaller than the bar. The bar diameter has to fit the grip.

Stock allowance is the radial material left on the bar for the turning passes. Too little and the bar will not clean up to the finished diameter. Too much and the roughing pass takes too long, uses more insert edges, and can push the bar in the collet.

For a finished Ø10 mm part from Ø12 mm bar, the radial allowance is 1 mm. A roughing pass at 0.8 mm depth and a finishing pass at 0.2 mm depth will clean up the bar and set the final size. The finishing pass determines the surface finish and the diameter tolerance.

For stainless and titanium, the allowance has to account for work hardening. A light finishing pass on 17-4PH or Ti-6Al-4V can harden the surface and dull the insert. A deeper finishing pass, around 0.3–0.5 mm, gets under the hardened layer. On aluminum, a 0.1–0.2 mm finishing pass is enough.

Bar straightness sets the minimum allowance. If the bar is bowed, the bar will not clean up on one side even if the nominal allowance looks fine. A bar that is 1 mm out of straight over 1 m can need an extra 0.5 mm of radial allowance to clean up. Straightening the bar or buying ground bar is often cheaper than adding a pass.

The usable bar length also matters. A 3 m bar gives more parts per load, but a long bar needs more support and has more whip. A 1 m bar is easier to handle and sort. The trade is between load frequency and bar stability.

Turning parameters are set by the bar material, the insert grade, and the rigidity of the setup. For 6061-T6 aluminum, a surface speed of 300–600 m/min with a 0.15–0.3 mm/rev feed is a common starting point. For 303 stainless, 120–200 m/min and 0.1–0.2 mm/rev. For Ti-6Al-4V, 40–80 m/min and 0.08–0.15 mm/rev.

Chip control is the practical limit on feed rate. A stringy chip wraps around the bar and the tool, and it can pull the part out of the collet. A chipbreaker insert and a feed rate high enough to break the chip are the first fixes. On gummy materials like 304 stainless, a higher feed per revolution and a positive rake insert help.

Coolant does two jobs on bar work. It removes heat from the cutting zone and it flushes chips away from the collet and the guide bushing. High-pressure coolant through the tool is common on Swiss machines because the cutting zone is enclosed and chips have nowhere to go.

Vibration is the other limit. If the bar is long and unsupported, chatter shows up as a patterned surface on the part. Reducing the spindle speed, shortening the unsupported length, or adding a bar support are the usual fixes. Adding a finishing pass at a lower feed can hide chatter marks, but it does not remove the cause.

After turning, the part is cut off, faced, and often deburred. The cut-off operation is the last chance to hold the length tolerance. A worn cut-off insert will leave a burr and a length that drifts. Changing the insert on a schedule, not on failure, keeps the length in tolerance.

Surface finish is set by the finishing pass and the insert nose radius. A 0.4 mm nose radius at a 0.1 mm/rev feed gives a finer finish than a 0.8 mm radius at the same feed. For a Ra 0.8–1.6 μm finish, a 0.4 mm radius and a 0.05–0.1 mm/rev finishing feed is a workable starting point. For Ra 0.2–0.8 μm, a wiper insert or a lower feed is needed.

Sorting the finished part is a separate operation from sorting the bar. Parts are checked for diameter, length, thread gauge, and visual defects. On a bar-fed job, the first part off after a new bar load is checked before the run continues. That first-part check catches a bar that was out of spec before a full batch is made.

For high-volume work, a gauge or a vision system can check every part. For lower volumes, sampling at a set interval is normal. Either way, the check is against the drawing, not against the previous part. Drift is the risk on a long bar run.
