CNC Tool Grinding: How Geometry, Wheels and Runout Decide Precision
CNC tool grinding restores a cutting edge to a known geometry instead of an approximate one. This page covers what changes on the wheel, what the machine can and cannot hold, and how to decide between regrinding and replacing a tool.
In this article
- 1
- 2
- 3
- 4
- 5
- 6
- 7
What CNC tool grinding actually changes
A worn cutting edge is not a smaller version of a sharp one. Flank wear grows into a wear land, the edge radius widens, and cutting force climbs. On a Ø12 mm carbide end mill in 4140 steel, an edge radius that grows from about 5 μm to 20 μm can raise spindle load enough to change chatter behavior. CNC tool grinding removes that worn zone and re-establishes a defined edge.
The machine does not simply sharpen. It recreates the primary relief, the secondary relief, the helix, the rake face and the corner radius to a programmed path. On a five-axis grinder the tool is held in a collet and moved against a rotating wheel while the wheel head tilts and rotates. Each pass takes off 0.01–0.05 mm, so a 0.3 mm worn zone may need ten or more passes.
That difference matters to the shop floor. A hand-ground tool follows the operator's wrist. A CNC-ground tool follows the same path in March as it did in January, so offsets in the machine stay valid and the first part off the machine matches the tenth.
One limit deserves stating early. Grinding moves material off the diameter. Every regrind makes the tool smaller, so the geometry you program and the geometry you get drift apart after several cycles.
Wheel choice sets the edge, not just the shape
Most carbide tool grinding uses diamond wheels in a resin or vitrified bond. Grit size controls the edge condition more than any other single variable. A 400 grit wheel leaves a rougher edge than an 800 grit wheel, and the finer edge usually cuts cleaner but loads faster and needs more frequent dressing.
Bond hardness decides how the wheel behaves under pressure. A softer bond releases dull grit sooner and runs cooler. A harder bond holds form longer but can burn the carbide, and a burnt edge shows up as micro-cracking that only appears after the tool goes into cut. For finishing passes on small-diameter tools, a softer resin bond with 600–800 grit is the safer starting point.
Concentration, meaning the diamond content per unit volume, affects both stock removal and heat. High concentration removes stock faster and carries heat away better, but it costs more and needs a stiffer machine. For roughing out a worn edge, 100 concentration is common. For finishing, 75 works and holds a sharper edge.
Coolant is not optional. Oil-based grinding fluid for carbide keeps the wheel face clean and controls heat at the contact zone, which is where thermal damage starts. Water-based fluid runs cleaner but can promote cobalt leaching in some carbide grades. Match the fluid to the binder and the carbide, not to house habit.
Relief, rake and runout: where precision is lost
Relief angle is the clearance behind the cutting edge. Too little relief and the tool rubs, generating heat and a poor finish. Too much and the edge loses support, chips under load, and fails early. For general steel and stainless work, a primary relief of 7–10° with a secondary relief of 12–15° is a workable split. Aluminium tools usually run higher rake and more relief.
Rake angle controls how the chip forms. A positive rake of 10–15° lowers cutting force and suits soft, gummy materials. Near-zero or negative rake puts more strength behind the edge and suits hard materials or interrupted cuts. Changing rake during a regrind without telling the machinist changes the cutting force the tool was chosen for.
Runout is the quiet killer. A tool with 0.02 mm of runout on one flute does most of the cutting on that flute, so it wears out first while the others stay sharp. On a finishing pass that shows up as a rough patch that repeats every revolution. Grinding runout down to 0.005 mm or less keeps the load shared across flutes, and a dial indicator on the flutes after grinding takes about thirty seconds to check.
Helix angle and corner radius come along with the regrind. Grinding a corner radius slightly smaller than nominal is normal as the tool shrinks, but the programmer needs to know the actual value, not the drawing value.
When regrinding stops being worth it
Every regrind shifts the diameter down. A Ø10 mm end mill with a 3 mm corner radius has little room before the radius is gone. Once the diameter drops enough that the programmed radial engagement no longer matches the toolpath, the tool is a compromise, not a tool. For finishing work holding ±0.005 mm, that point arrives quickly.
Coating is a one-way street. A TiAlN or AlCrN layer is consumed at the edge with each regrind, and re-coating after grinding adds cost plus turnaround. On a standard carbide end mill, regrinding twice and re-coating once is often the break-even point against buying new. On a large form tool or a step drill, even three or four cycles can pay off.
Form tools and special profiles change the math. A custom step drill or a form reamer can cost many times a standard cutter, so regrinding to a defined profile is usually cheaper than a replacement order. The catch is that the profile has to be measured after grinding, not assumed.
Cracked, chipped or heat-damaged tools are not candidates. Grinding a chipped edge just moves the chip deeper, and a thermally cracked tool will fail in the cut no matter how sharp the edge looks under a loupe.
Doing it in-house versus sending it out
A five-axis tool grinder is a capable machine, but it needs a controlled room, a dressing routine and someone who understands wheel selection. If a shop regrinds ten tools a month, outsourcing usually wins. If it regrinds hundreds, the machine pays for itself in tool cost, and the bigger gain is turnaround: a tool ground overnight is back in a spindle the next morning.
Outsourcing works when the supplier measures what they grind. Ask for the post-grind diameter, runout and corner radius on the tool tag. A supplier who returns tools without numbers is asking you to trust the grinder's wrist, which is the problem you were trying to solve.
For shops that machine difficult alloys, the tool and the part should be planned together. Tool life on Inconel or titanium depends on edge preparation and geometry as much as on the machine. Grinding to a specified edge radius, not just a specified shape, is often the difference between a stable process and one that drifts.
GreatLight runs 127 high-precision CNC machines across three plants, including 16 simultaneous 5-axis centers, and holds ±0.005 mm on machined features. Tool condition is checked as part of in-process monitoring, because a worn cutter shows up in the part long before it shows up on an inspection report.
Step by step: from incoming tool to verified edge
- 1Inspect and logMeasure diameter and flute runout with a micrometer and dial indicator. Photograph the wear land. Record the number of previous regrinds.
- 2Clean and de-coatRemove chips and coolant residue. If the coating must come off for a full re-profile, strip it before grinding, not after.
- 3Set the collet and datumClamp on the shank, not the flutes. Establish the tool axis to within 0.005 mm. A worn collet shows up as runout later.
- 4Rough the wear landUse 320–400 grit at 0.03–0.05 mm per pass. Remove all visible wear, then stop. Grinding past the wear zone wastes tool life.
- 5Cut primary and secondary reliefHold 7–10° primary and 12–15° secondary. Check the angle with a toolmaker's microscope on the first article.
- 6Finish the rake face600–800 grit, 0.005–0.015 mm per pass. A light pass keeps the edge sharp without dropping the rake angle.
- 7Re-coat if neededDecide before the finishing pass. Re-coating adds cost, so only do it when the tool has enough diameter left for another cycle.
- 8Verify and labelRecord actual diameter, runout and corner radius on the tool tag. The machinist programs to the measured value, not the catalog value.
Wheel and parameter starting points
Values are starting ranges for carbide tools on a five-axis grinder. Adjust for binder, diameter and machine stiffness.
| Operation | Grit / bond | Depth per pass | Edge result |
|---|---|---|---|
| Rough out wear land | 320–400, resin, 100 conc. | 0.03–0.05 mm | Removes damage fast, rougher edge |
| Semi-finish relief | 500–600, resin, 100 conc. | 0.015–0.025 mm | Defines primary relief angle |
| Finish rake face | 600–800, resin, 75 conc. | 0.005–0.015 mm | Lower cutting force, cleaner chip flow |
| Corner radius finish | 800, vitrified, 75 conc. | 0.003–0.01 mm | Stable radius, fewer chips at corner |
| HSS tool touch-up | Aluminium oxide, 60–120 grit | 0.02–0.04 mm | Sharp edge, lower heat tolerance |
| Coated tool refresh | 800, resin, 75 conc. | 0.005–0.01 mm | Removes coating at edge only |
The trade-off, stated plainly
Regrind standard carbide tools twice and re-coat once if diameter and coating budget allow; send form tools and special profiles to a grinder that returns measured geometry, and replace anything cracked or chipped rather than grinding it.
Questions engineers ask next
How often should a tool be reground?
It depends on the material, the cutting parameters and the finish target, not on a calendar. Abrasive or high-speed work wears an edge faster. The practical rule is to inspect edges on a schedule tied to spindle hours and regrind when the wear land becomes visible under a loupe, before the edge starts to chip.
Grinding early costs less than grinding late. A small wear land comes off in a few passes, while a chipped edge may need enough stock removal to shorten the tool's remaining life.
Which tools can be ground on a CNC tool grinder?
End mills, drills, reamers, taps, step drills, countersinks and many form tools are routine work. The limits come from the machine's axes and the wheel profiles available, not from the tool type itself.
Tools with very complex or undercut profiles may need a specially dressed wheel. In that case the profile has to be verified after grinding, because the wheel form wears as it cuts.
Does regrinding change the tool diameter?
Yes. Grinding removes material from the periphery, so the diameter shrinks with each cycle. The machinist needs the measured diameter to keep the toolpath and the offsets correct.
Tools used for finishing to tight tolerances may become unusable after one or two cycles, while roughing tools can tolerate more. Tag every reground tool with its actual diameter.
What runout should a reground tool hold?
For most milling and drilling work, 0.005 mm or less on the flutes is a reasonable target, checked with a dial indicator on the shank-held tool. Higher runout concentrates the cut on one flute and shortens life.
Runout also depends on the holder. Checking the tool in a worn collet tells you about the collet, not the grind. Verify in a known-good holder.
Can a coated tool be reground and reused?
Yes, but the coating at the edge is gone after grinding. The tool still cuts, with less wear resistance at the cutting zone. Re-coating restores performance, and the decision to re-coat should be made before the finishing pass, not after.
For general steel work, an uncoated reground edge is often acceptable for roughing. For stainless, titanium or hard materials, re-coating usually pays for itself.
What tolerance can tool grinding hold?
On a properly set up five-axis grinder, diameter and profile can be held in the 0.005–0.01 mm range, with runout below 0.005 mm. The practical limit is often the collet and the measurement method, not the machine.
At GreatLight, machined features are held to ±0.005 mm and inspected before shipment, with reports available on request.
