A composite is two materials doing two jobs. Carbon, glass or aramid fiber carries the load. The polymer matrix holds the fibers in place and spreads stress between them. When a cutter enters, it is not cutting one homogeneous solid. It is cutting stiff, abrasive fiber and soft, heat-sensitive resin in the same revolution of the edge.

That split explains most of what you see at the machine. Metals deform plastically and push a chip ahead of the edge. Fiber does not. It fractures, and if the support behind it is weak, it fractures below the cut line. The resin around it either shears cleanly or smears, depending on how hot the edge gets.

Heat is the quiet problem. Carbon fiber conducts heat away from the cut slowly compared with aluminum, so the edge keeps its temperature and the matrix around it softens. Soft matrix means poor support for the next fiber, and poor support means frayed edges and pulled fibers rather than clean shear.

Abrasion is the loud problem. Cured carbon fiber sits around 60 to 70 on the Rockwell C scale in the fiber direction, harder than many tool steels. A high-speed steel cutter will lose its edge in minutes. That is why polycrystalline diamond and diamond-coated carbide dominate this work.

So the process is not simply milling a soft plastic. It is a sequence of small fractures in a brittle reinforcement, held together by a matrix that must stay cool and well supported. Every parameter choice either helps that or fights it.

• 1
  Fiber carries loadCarbon, glass or aramid, oriented in plies.
• 2
  Matrix transfers stressEpoxy, phenolic, PEEK or BMI holds plies together.
• 3
  Two failure modesFiber fracture and matrix smearing happen together.

Tool material comes first. Polycrystalline diamond (PCD) or diamond-coated carbide holds an edge long enough to be economical on carbon fiber. Solid carbide with a diamond coating is the usual compromise for mixed work. Uncoated carbide is acceptable on glass fiber and on aramid if you accept shorter tool life.

Geometry matters as much as coating. A sharp positive rake angle shears fiber instead of pushing it. Two-flute and three-flute end mills give chip clearance in a dusty cut. Compression routers, with up-cut flutes at the tip and down-cut flutes above, pull the top and bottom plies inward at the same time and are the standard answer for visible edges.

Cutting speed for carbon fiber laminate typically runs 100 to 200 m/min with PCD, and lower, around 60 to 120 m/min, with coated carbide. Feed per tooth sits between 0.05 and 0.15 mm. These are starting windows, not recipes. The right value depends on fiber volume, ply orientation and how rigid the part is when clamped.

Axial depth of cut should stay shallow, often 0.5 to 2 mm per pass, so the radial engagement and the cutting force stay modest. A light, fast pass generates less heat in the matrix than a heavy, slow one. Climb milling is the default for laminate edges.

Cooling is a decision, not a default. Flood coolant removes heat and dust but can wick into exposed fiber ends and contaminate a bonded assembly. Many shops run dry with high-velocity air extraction instead. If the part will be bonded later, dry cutting with extraction is usually the safer choice.

• 1
  PCD or diamond-coated carbideHolds an edge against abrasive fiber.
• 2
  Compression routerProtects top and bottom plies on visible edges.
• 3
  Shallow axial passes0.5–2 mm per pass keeps matrix cool.
• 4
  Dry plus extractionAvoids coolant wicking into bond surfaces.

A laminate is often thin and springy. Clamp it at two points and the middle lifts under tool pressure. The cutter then takes a deeper bite than programmed, and the ply below the cut line blows out. Support is not a detail here; it is the main variable behind delamination.

The common fix is a sacrificial backing plate. The laminate sits on a flat substrate, usually a cheap composite offcut or a machined polymer block, and the tool is allowed to cut 0.1 to 0.2 mm into the backing. The backing carries the fiber at the exit side, so the last plies shear instead of tear.

Vacuum fixturing works well on flat panels, especially when you cut a nested set from one sheet. It distributes load across the whole face and leaves no clamp marks. For curved or three-dimensional parts, custom soft jaws machined to the part contour give the same effect in a vise.

Thin-wall tubes and shells need internal support. Expanding mandrels, low-melt fixture alloys or poured resin supports hold the bore while the outside is profiled. Removing the support afterwards must be planned before the first cut, not after.

Clamping pressure is a trade too. Too little and the part vibrates. Too much and you crush the core or print a clamp mark into the surface ply. On honeycomb cores, point loads are especially damaging, so spread pressure over a plate rather than a jaw tip.

• 1
  Sacrificial backingCut 0.1–0.2 mm into the plate, not the part.
• 2
  Vacuum tableBest for flat nested panels, no clamp marks.
• 3
  Contour soft jawsMatch the part curve for 3D shapes.
• 4
  Internal supportMandrels or low-melt alloy for tubes.

Machining earns its place when the geometry cannot come out of a mold. Bolt holes, counterbores, pockets, chamfers, trim lines and tight tolerances on an interface are all typical. A molded panel with 40 drilled holes and a machined perimeter is a normal composite job.

It also fits low volume. A mold for a 300 mm bracket can cost more than the brackets themselves when you only need twenty. Cutting them from a cured laminate plate skips the tooling and keeps the design changeable between runs. No minimum order helps here; one prototype is a valid quantity.

Repair and rework are another fit. Aerospace and wind structures often need a damaged section trimmed back and a new insert fitted. That is a machining operation on a cured, in-place part, and it has to match an existing surface within a tight tolerance.

Large envelopes matter for long parts. With 4,000 mm of travel in one direction, rails, spars, ribs and long trim tools can be cut in a single setup, which removes the alignment error that comes from repositioning a flexible laminate.

What does not belong on a mill: thick, complex, three-dimensional shapes that would waste most of the plate as chips. If 70 percent of the stock becomes dust, the part should be molded, filament-wound or laid up near-net and only finished by machining.

• 1
  Holes and interfacesDrilling, counterboring and chamfering cured laminate.
• 2
  Low volumeTwenty brackets rarely justify a mold.
• 3
  Trim and repairCut back damage, fit an insert, match the surface.
• 4
  Long parts4,000 mm travel keeps a spar in one setup.

Delamination is the defect most people name, but it is a symptom. It comes from insufficient backing, too much feed, a dull edge or a ply orientation the cutter pushes apart instead of shearing. Change the support or the edge before you change the feed by half.

Fiber pullout and fuzzing show up on aramid especially, because the fiber is tough and stretches before it breaks. It resists clean shear. Sharp tools, high speed and a backing plate reduce it, but aramid edges rarely look as crisp as carbon edges. Design the part so its critical edge is not aramid.

Heat damage is harder to see. A scorched matrix may still pass a visual check while its interlaminar strength has dropped. If the cut smells burnt or the resin looks glossy and smeared, the edge is running too hot. Reduce speed, increase feed per tooth or improve extraction.

Inspection follows the risk. A drilled hole can be checked with a pin gauge. A structural edge needs a closer look. We inspect 100 percent of parts before shipment and can supply raw material checks, in-process monitoring and final reports on request.

The honest limit is that machining cannot fix a bad laminate. Voids, resin-starved areas and weak interlaminar bonds come from the layup and cure. A cutter will simply expose them. If the incoming plate is not sound, no toolpath will make the finished part sound.

• 1
  DelaminationFix support and edge first, feeds second.
• 2
  Aramid fuzzingTough fiber resists shear; keep it off critical edges.
• 3
  Heat damageSmeared, glossy resin means the edge is too hot.
• 4
  Incoming laminateMachining exposes voids, it does not remove them.

Carbon fiber reinforced polymer is the most common request. It is stiff, light and abrasive. It machines to a clean edge with PCD tooling and good backing, and it drills well with diamond-coated bits and a backing plate. Dust is conductive, so extraction and machine protection matter.

Glass fiber reinforced polymer is softer and cheaper but more abrasive per unit of strength in some grades. It cuts with carbide more readily than carbon does. Edges tend to show white fuzz, and the dust is a respiratory hazard that needs proper capture, not just a shop vacuum.

Aramid, sold as Kevlar and similar trade names, is tough rather than stiff. It absorbs impact well and resists cutting. Expect fuzzing, and plan for shearing, waterjet or laser trimming on visible edges where appearance matters. Machining is still fine for holes and internal features.

Thermoplastic composites with PEEK, PEKK or polyphenylene sulfide matrices behave differently from epoxy. They are tougher, tolerate more heat, and can be re-melted at the edge if the tool gets too hot. Keep the temperature below the matrix melting point and the cut stays clean.

We also machine carbon fibre plate and filled engineering plastics alongside the metal work, so a bracket can be cut from composite and its mating hardware from aluminum or titanium in the same shop. That keeps the interface tolerance under one roof.

• 1
  Carbon fiberAbrasive and stiff; PCD tooling, dry extraction.
• 2
  Glass fiberSofter, still abrasive; capture the dust.
• 3
  AramidTough, fuzzes; consider shear or waterjet on edges.
• 4
  PEEK / PPS matrixWatch matrix melting point, not just the fiber.
