A three-axis mill moves the tool in X, Y and Z. The work stays still. A five-axis machine adds two rotary axes, so the part or the spindle tilts while the cutter is in the material. The tool tip can then approach a face from an angle instead of straight down the Z column.

The two extra axes are usually a trunnion table (two rotary axes under the work) or a swivel head (two axes in the spindle). Trunnion machines hold the part on a Ø400 mm rotary table and are stronger for heavy cuts. Swivel-head machines reach deep into tall parts because the work does not have to swing.

The practical result is that the cutter can stay tangent to a curved surface instead of stepping across it in Z passes. Tool wear spreads along the flute, chip evacuation improves, and the surface left behind is closer to the model. That is why 5axis machining is often chosen for impellers, turbine blades, and mold cavities with steep walls.

There is a cost. The controller has to solve more kinematics per block, so feed rates drop on tight corners. Programming takes longer. A part that runs fine on three axes in 40 minutes may need an hour of CAM work on five axes before the first chip is cut.

Most tolerance loss on a machined part does not come from the cutter. It comes from re-fixturing. Every time a part is unclamped and turned, the datum shifts by a few microns, and those microns stack. A housing that needs four faces machined on a three-axis mill may need four setups and three datum transfers.

On a trunnion machine, the same housing can be cut on five faces after one clamp. Datum error is set once at the start. The positional relationship between a bore and a mounting face is held by the machine geometry, not by how well an operator tapped the part against a stop.

That is the real argument for 5axis machining on complex parts. It is not that the spindle is faster. It is that the part never moves relative to its own datum. On a bracket with six tapped holes and two dowel bores on different faces, this alone can hold ±0.005 mm where a four-setup route drifts past it.

There is a limit. If a part has only one machined face, extra axes add nothing but cost. Single-face plates, simple bushings, and flat covers are cheaper on three-axis machines, and we quote them that way.

A three-axis cutter has one approach direction. Any feature that faces sideways, or hides behind a wall, has to be reached with a long tool or a second operation. Long tools deflect. A 6 mm end mill hanging 60 mm out of the holder will chatter long before it wears out.

Tilting the part lets a short, stiff tool reach the same feature. Instead of a 6 mm tool at 60 mm gauge length, the machine presents the work at 45° and uses the same 6 mm tool at 25 mm gauge length. Deflection drops by roughly the cube of the length ratio, so the cut is far more stable.

This is where 5axis machining earns its place on parts with undercuts, angled ports, and pockets deeper than three times the tool diameter. The tool axis can also be tilted a few degrees away from the surface normal so the tip of a ball nose is not running at zero surface speed. Finish improves without changing the cutter.

Some shapes still cannot be reached. A closed internal cavity with no opening, or a thread on the inside of a bottle-shaped bore, needs a different process. Five axes move the tool, not the laws of geometry.

A five-axis machine is only as good as the block holding the part. On a trunnion table the work rotates, so the fixture has to be stiff in every orientation and must not throw the part off balance. A 20 kg block spinning at 50 rpm with an offset fixture will show up as vibration in the finish.

For thin-walled parts, soft jaws or a dedicated nest machined in place are common. Cutting the jaws on the machine itself means the clamping surface matches the actual spindle, so runout is near zero. For prismatic parts, a self-centering vise on a pallet is faster to load and repeatable across a run.

Zero-point clamping pays back on production. A pallet is loaded outside the machine while the spindle keeps cutting. On a 10,000-part run this is worth more than any feed-rate tweak, because spindle uptime is what the customer pays for.

We design fixtures alongside the CAM program, not after it. If the setup cannot hold the part, the toolpath does not matter.

Machine geometry sets the floor. On a well-maintained five-axis center, positional tolerance of ±0.005 mm is routine on features cut in one setup. That number assumes a stable fixture, a sharp tool, and a temperature-controlled shop. It is not a blanket guarantee for every feature on a drawing.

Roundness and concentricity between features on the same setup hold tighter than between features cut in separate operations. If a drawing calls for 0.01 mm true position between a bore and a face, put both in the same setup. If they are cut in two setups, expect the stack to double.

Surface finish follows the same logic. Ra 0.8–1.6 μm comes off the machine on most aluminum and stainless parts with a clean toolpath. Ra 0.2–0.8 μm needs a finer stepover, a fresh cutter, and sometimes a separate finishing pass. It is a process choice, not a default.

Thermal drift matters on long runs. A spindle that has been cutting for six hours is not the same machine it was at 8 a.m. In-process probing catches the shift before it becomes scrap.

Aluminum 6061 and 7075 cut cleanly on five axes. Chips clear well, and the tilted toolpath keeps the cutter out of recut chips in deep pockets. 7075 is less forgiving on thin walls because it work-hardens, so we reduce radial engagement and keep the tool moving.

Stainless 304 and 17-4PH need lower surface speed and more coolant. On a tilted toolpath the coolant actually reaches the cut zone, which is an advantage over a deep vertical pocket where the stream bounces off the wall. Titanium TC4 (Ti-6Al-4V) is run slow with high-pressure coolant, and the tilt helps keep heat out of the part.

Inconel and other nickel alloys are the hardest case. Tool life drops fast, so we plan shorter toolpaths, more frequent tool changes, and rougher stock removal before the finishing pass. Plastics like PEEK and POM cut easily but move with temperature, so we keep the coolant off and manage chip evacuation instead.

The material list we run includes 6061, 2024, 5052, 6082, 7075, 303, 304, 316L, 17-4PH, 4140, 4340, TC4, Inconel, and magnesium AZ31B. Each has its own feed and speed window, and the CAM strategy changes with it.
