CNC Part Machining Service: What to Check Before You Order
This guide is for engineers and procurement staff comparing CNC part machining service suppliers. Read it and you will know which tolerances, certifications, lead times and quote details actually decide whether your parts arrive right the first time.
In this article
- 1
- 2
- 3
- 4
- 5
- 6
Key takeaways
How to compare CNC part machining service suppliers
Score each row against your own part drawing. A single weak row can cost more than a lower hourly rate saves.
| Criterion | What to ask | Strong answer | Weak signal |
|---|---|---|---|
| Tolerance | Which tolerance applies across the whole part? | ±0.005 mm held on stated travels | "Depends on the feature" with no numbers |
| Size range | Largest part you machine in one setup? | Up to 4,000 mm | Only small brackets and plates |
| Quote turnaround | When do I get price and DFM notes? | Within 12 hours, with DFM feedback | Several days, no manufacturability notes |
| Start time | How fast after PO approval? | Production starts within 24 hours | "Depends on the schedule" |
| MOQ | Can you run a single prototype? | No MOQ, 1 piece to 10,000+ | Setup fee that forces a batch |
| Certifications | Which quality systems are in place? | ISO 9001, IATF 16949, ISO 13485, ISO 27001 | ISO 9001 only, no industry-specific audit |
| Inspection | What do I receive with the parts? | 100% inspection, reports on request | Sample check only, no documentation |
| Confidentiality | Can you sign an NDA before I upload files? | NDA available on request, secure uploads | Files shared over open email only |
The verdict
Choose a supplier that answers the tolerance question per feature, returns price and DFM notes within 12 hours, runs no MOQ, and hands you inspection reports without being asked. Everything else is a price argument.
Tolerance, geometry and the limits of a CNC part machining service
Tolerance is the first number engineers compare, and the most often misread. A shop quoting ±0.005 mm is describing what its best machines hold on a favorable part, not a blanket guarantee on every feature you draw. A 25 mm aluminum lever and a 1,200 mm steel weldment sit at different ends of the thermal and stiffness range. Ask which machine will run your part and how the datum scheme is set. That answer tells you more than the tolerance line in a brochure.
Geometry drives cost more than material does. Deep pockets, thin walls, tight corner radii and features that need five sides all push the part toward more setups or a 5-axis machine. If a pocket is 4× deeper than the cutter diameter, expect a longer cycle and higher risk of chatter. A corner radius of 1 mm in a 30 mm deep pocket is machinable, but it is slow. Widening that radius to 3 mm can cut cycle time noticeably without changing function.
Feature accessibility decides which machine class you need. Three-axis work handles prismatic parts with features open to one direction. Four-axis adds rotation for parts with features on multiple faces around a single axis. Five-axis reaches compound angles and contoured surfaces in one setup, which protects position tolerance between faces. If your drawing calls out position between two angled bores at ±0.01 mm, a single-setup 5-axis process is usually the safer route.
Surface finish is a separate spec from tolerance. A part can hold ±0.005 mm and still show tool marks. Ra 0.8–1.6 μm is a normal machined finish for most functional surfaces. Ra 0.2–0.8 μm needs slower passes, finer tooling or a finishing operation. Ra 1.6–3.2 μm is fine for brackets and covers. State the finish on the drawing by surface, not as one global note, so the shop does not over-machine surfaces that do not need it.
Materials, setups and where a job goes wrong
Material choice changes the machining plan, not just the price. Aluminum 6061 and 7075 cut fast and hold tight tolerances well. Stainless 304 and 316 work-harden, so light passes and sharp tooling matter. Titanium Ti-6Al-4V and Inconel generate heat at the cutting edge and need lower speeds, more coolant and longer cycle times. If your design is still open, 6061-T6 covers most functional prototypes at the lowest risk.
Thin walls are the classic failure point. A 0.8 mm wall on a 100 mm tall aluminum housing will deflect under normal clamping and cutting forces. Two fixes work: leave the wall thicker until the last operation, or design a temporary rib that gets removed. If neither is possible, tell the shop before quoting. A supplier who spots this and flags it in the DFM notes is worth more than one who quotes it silently and ships a bowed part.
Setup count is the hidden cost driver. Every additional setup adds fixture time, re-datum error and inspection. Parts with features on four or five faces often cost less on a 5-axis machine than on a 3-axis machine run four times. For long parts, the 4,000 × 400 × 150 mm travel range lets a shop machine a full-length rail without repositioning, which removes a joint error source. Ask how many setups your part needs.
Heat treatment, plating and anodizing happen after machining and can move dimensions. Hardcoat anodizing builds a layer that changes a press fit. Electroless nickel adds a thin, fairly uniform layer. If a bore is tolerance-critical and will be coated, specify the pre-coat dimension and let the shop confirm the build allowance. Leaving this to the finisher is a common source of parts that pass incoming inspection and fail at assembly.
Lead time, MOQ, certifications and quote details
Lead time has three parts: quote, start and ship. A supplier that returns a quotation and free DFM analysis within 12 hours, starts production within 24 hours of approval and ships in 3–5 days is running a tight front end. That matters most for prototypes and line-down situations. Ask for the three numbers separately. A single "two weeks" answer hides where the time actually goes, and it hides it until you are late.
MOQ is where small engineering teams get squeezed. Some shops will not open a machine for fewer than fifty pieces, so a single prototype becomes expensive or impossible. A shop with no minimum order quantity can run one piece and later scale the same part to 10,000+ without requalifying the process. For a design not yet frozen, that flexibility is worth more than a few percent on unit price.
Certifications tell you which quality system is running the floor. ISO 9001:2015 is the baseline. IATF 16949:2016 applies to automotive and EV work, ISO 13485:2016 to medical devices, and ISO 27001:2022 to information security when you send proprietary drawings. Match the certificate to your industry. A general-purpose shop with only ISO 9001 is not automatically wrong, but you should know what is not covered.
Quote detail separates a real price from a placeholder. A usable quote lists material grade, machining operations, finishing, inspection level, quantity breaks and any excluded items. If the quote says "machining only, finishing not included," price the finishing before you compare totals. Also confirm what happens to your files. Uploads should be secure and confidential, and an NDA should be available on request before you send the drawing package.
Step by step: how to place a CNC part order that goes right
Follow these steps in order. Skipping step 3 or step 6 is where most rejected batches come from.
- 11. Fix the drawing before you send itState tolerance by feature, not one global block. Mark datums A, B and C. Give surface finish per surface. Note material grade and temper, for example 6061-T6 or 17-4PH. A clean drawing removes assumption from the quote.
- 22. Send STEP plus 2D PDFThe STEP file defines geometry; the 2D PDF carries tolerances, finish and notes. Send both. A 3D model alone cannot express a ±0.005 mm bore or an Ra 0.8 μm face.
- 33. Ask for DFM feedback with the priceA good supplier returns manufacturability notes in the same reply as the quote. Look for flagged thin walls, deep pockets and impossible corner radii. Within 12 hours is a realistic target.
- 44. Confirm quantity breaks and finishingGet unit price for 1, 10, 100 and 1,000 pieces if your volume is uncertain. Confirm whether anodizing, plating or heat treatment is inside the price. Unclear scope is the most common quote dispute.
- 55. Agree the inspection packageDecide what you need: first article inspection, in-process checks, final dimensional report, material certificates. 100% inspection before shipment should be the default. Ask for reports on request if your quality system requires them.
- 66. Sign the NDA before uploadingIf the design is proprietary, put an NDA in place first and use a secure upload channel. Do not email a native CAD file to a general inbox and sort out the paperwork later.
- 77. Approve the first article, then release the runFor new or tight-tolerance parts, hold the batch until the first article is measured and approved. For ±0.005 mm features, review the CMM report against the drawing before the balance of the order ships.
Frequently asked questions
What tolerance can a CNC part machining service realistically hold?
On well-supported features in aluminum or brass, ±0.005 mm is achievable on a capable machine with a stable setup. On long parts, thin walls or hardened steel, the practical limit widens.
Give the shop the feature, material and size, and ask for the tolerance it will commit to on that specific feature. A blanket number across the whole drawing is not a useful answer.
How fast can parts ship after I approve the order?
For a typical machined part, production can start within 24 hours of approval and parts ship in 3–5 days. That assumes the drawing is frozen and the material is in stock.
Parts that need anodizing, plating or heat treatment take longer because those steps run outside the machine shop. Ask for the finishing lead time separately so you are not surprised.
Is there a minimum order quantity?
At GreatLight there is no minimum order quantity. The same process runs from one prototype to 10,000+ part runs.
This matters when a design is not frozen. You can validate fit and function on a single piece, change the model, and re-run without paying a batch minimum each time.
Which certifications should I look for?
ISO 9001:2015 is the baseline for any machine shop. Add IATF 16949:2016 for automotive and EV parts, ISO 13485:2016 for medical devices, and ISO 27001:2022 if your drawings are confidential.
Ask for the certificate scope, not just the logo. A certificate that does not cover your part family or process does not help your audit trail.
What should a quote include so I can compare fairly?
Material grade, machining operations, finishing, inspection level, quantity breaks and exclusions. If finishing is excluded, price it before comparing.
Also check the quote turnaround itself. A shop that returns price and DFM notes within 12 hours is usually the same shop that communicates well once the order is running.
How do you handle confidential drawings?
Uploads are secure and confidential, and an NDA is available on request before you send files. For regulated programs, the information security system is certified to ISO 27001:2022.
Agree the channel first. Sending a native CAD file to an open inbox and sorting out the agreement afterward is the wrong order.
Send your drawing, get a quote and DFM notes
Upload your STEP and 2D PDF. We return price and manufacturability feedback within 12 hours, and parts ship in 3–5 days.
12-hour quoteNo MOQ100% inspectionNDA on request
