A CNC shop does not sell machine time. It sells a repeatable result: a part that fits the assembly, passes inspection and arrives with the paperwork your quality team needs. Two shops can quote the same drawing and both be honest, because they are selling different versions of that result.

The first variable is machine mix. A shop running 27 three-axis machines handles flat plates, brackets and housings with one or two setups. A shop with 16 simultaneous 5-axis centers can reach five faces in a single setup, which removes fixture error from the stack. Neither shop is better in general. They are matched to different part geometry.

The second variable is metrology. A ±0.005 mm callout means nothing if the shop measures with calipers at the bench. It means something when a CMM or optical comparator confirms the feature and the report ships with the parts. Ask how the critical dimension is verified before you ask for the price.

The third variable is documentation. Aerospace and medical buyers need traceable material certs and inspection reports. A job shop that runs general industrial work may treat those as optional extras. That difference shows up in the quote as admin time, not as machining time.

Setup count is the clearest cost signal in machining. Every time a part comes off the table, the operator re-datums it. Each re-datum adds a small error and a real chunk of labor. A part with features on three faces is a different animal from a part with features on one face.

Three-axis work suits prismatic parts: plates, manifolds with drilling on one face, simple pockets. If the drawing has tight true position between holes on the top and a bore on the side, you are now paying for two setups plus a fixture. That is where a 4-axis or 5-axis quote can come in lower than a 3-axis quote, which surprises people who shop by hourly rate.

Five-axis simultaneous cutting also changes tool access. Undercuts, deep curved pockets and impeller-style blades can be reached without special long-reach tooling. Long tools deflect. Deflection shows up as taper in a deep bore and chatter on a thin wall. Short, stiff tools on a trunnion table avoid both problems.

There is a limit. Very large parts do not benefit from 5-axis if the machine envelope cannot hold them. GreatLight runs up to 4,000 mm maximum processing size, with large travels of 4,000 × 400 × 150 mm for long extrusions and rails. If your part is 2 m long and 300 mm tall, that class of machine fits. If it is a 500 mm cube with five-face features, a compact 500 × 500 × 450 mm cell is the better match.

Material choice sets the achievable tolerance as much as the machine does. Aluminium 6061-T6 cuts clean and holds ±0.005 mm on a rigid setup, but thin walls move after clamping is released. Stainless 316L work-hardens, so a light finishing pass with the wrong feed will rub instead of cut and push the bore off size.

Titanium TC4 (Ti-6Al-4V) and Inconel belong to a different group. They need lower surface speed, more coolant and sharper edges. A shop that lists them in its material menu is telling you it has the tooling and the spindle torque. A shop that lists them but quotes a two-day turnaround is telling you something else.

Plastics behave in the opposite direction. POM and PEEK machine fast but expand with heat, so a bore measured right after cutting can be undersize an hour later. ABS and PC are common for prototype enclosures. Carbon fibre needs diamond tooling and dust control, and the finish is usually as-machined rather than fine.

The practical rule: name the alloy and the temper on the drawing, not just the family. 6061 and 7075 differ in strength and in how they hold a thread. 304 and 316L differ in corrosion resistance and in chip behavior. Vague callouts invite the shop to substitute, and substitutions are where tolerance disputes start.

Finish callouts are often over-specified. Ra 0.2–0.8 μm needs a fine finishing pass, sometimes a secondary operation such as polishing. Ra 0.8–1.6 μm is a normal machined finish on aluminium and steel. Ra 1.6–3.2 μm is as-machined and costs the least. If a cosmetic cover sits over the surface, the fine finish is wasted money.

Anodizing, plating and powder coating add thickness. Hardcoat anodizing can add 25–50 μm per surface, which moves a dimension. If a bore must stay within ±0.005 mm after coating, the shop has to mask it or cut it undersize before coating. That is a process decision, not a price decision, and it should be raised at quoting time.

Inspection depth follows the application. For a bracket, a first-article check plus a dimensional spot check is enough. For an implant housing or a fuel system part, you want in-process monitoring and a final report tied to serial numbers. GreatLight inspects 100% of parts before shipment, covering raw material check, in-process monitoring and final inspection, with reports on request.

Ask what happens when a dimension is out. A shop that catches it in-process re-cuts the part. A shop that catches it at final inspection ships late or ships a deviation. The first outcome is cheaper for both sides, and it depends on the shop measuring during the run, not only at the end.

Certificates are a filter, not a badge. ISO 9001:2015 covers a general quality system. IATF 16949:2016 is the automotive standard and brings PPAP-style discipline. ISO 13485:2016 applies to medical devices and adds traceability and process validation. ISO 27001:2022 covers information security, which matters when your drawings are sensitive.

A shop holding all four has built the paperwork to serve regulated buyers. That costs money and shows up in overhead. If you are buying a prototype bracket, you may not need it. If you are buying a production part for a vehicle program, you do need it, and you should verify the certificate scope covers the process you are buying, not just the company name.

Confidentiality runs on the same logic. Uploads should be secure, and an NDA should be available on request before you share CAD. For defense-adjacent or unreleased consumer products, this is a hard gate. Ask early, not after the quote.

One more filter: order size. Some shops in the CNC market will not touch a single prototype because setup cost dominates. Others quote one piece and 10,000 pieces on the same line. GreatLight sets no minimum order quantity, running from one prototype to 10,000+ part runs, which lets you validate a design before committing to tooling.

Quoted lead time is a sum of steps, not a single promise. It starts with DFM review, then material purchase, programming, machining, finishing and inspection. A shop with material in stock can compress the front end. A shop waiting on a mill run of 17-4PH starts the clock late.

Finishing is the most common hidden delay because it is often subcontracted. Anodizing and plating lines run batch schedules. A part that finishes machining on Friday may not enter the anodize tank until Tuesday. If your schedule is tight, ask whether finishing is in-house or outsourced before you accept the date.

Prototype and production runs compete for the same machines. A shop that promises a 3-day prototype while a 10,000-piece order is running has to break setup to honor it. That is possible, but it costs. Knowing the shop's scheduling logic tells you whether the date is realistic.

GreatLight quotes with a free DFM analysis within 12 hours and can start production within 24 hours, with parts shipping in 3–5 days. Historical late-delivery probability is below 2%. Those numbers come from a specific plant and a specific order mix. Treat them as evidence of process, not as a guarantee for your part.
