Molding pays off at volume. Below a few thousand parts, tooling cost dominates the piece price, and any design change means cutting steel again. That is the gap CNC fills: prototypes, bridge tooling, legacy spares for machines still in the field, and pilot runs where the mold decision has not been made.

There is a second reason. Some geometries simply do not mold well. Deep ribs, undercuts, thick-to-thin transitions, and parts with molded-in inserts can be cut from stock faster than they can be tooled. For a plastics company, this turns a quote you would have declined into work you can deliver.

Material choice drives the decision too. PEEK for implant contact surfaces, PEI for flame retardancy, PTFE for chemical inertness, and carbon-filled grades for stiffness. These resins are expensive and hard to mold in low volume, but they machine cleanly in the right hands.

The parts also tend to be functional, not cosmetic. A manifold, a fixture plate, an insulating spacer. Tolerances matter, surface finish matters less, and a supplier who understands that will not gold-plate the process.

• 1
  Prototypes and pilot buildsReal resin, real properties, no tooling commitment.
• 2
  Legacy and obsolete partsNo mold exists and no one wants to pay for one.
• 3
  Complex geometryUndercuts, deep pockets, and thin walls that fight molding.
• 4
  Bridge productionCovers demand while the mold is being cut.

Plastic conducts heat roughly a thousand times worse than aluminium. Friction at the cutting edge has nowhere to go, so it collects in the chip and at the tool tip. The visible result is a gummy edge or a melted burr. The hidden result is subsurface stress that pulls the part out of tolerance days later.

The usual fix is higher spindle speed, lower feed per tooth, and shallower depth of cut. Removing material in light passes keeps the heat in the chip, which carries it away. Roughing at 2–3 mm radial engagement and finishing at 0.2–0.5 mm is a workable starting range for unfilled grades.

Tooling matters as much. Two-flute and single-flute end mills give the chip room to clear. Sharp geometry with a high rake angle shears rather than rubs. For glass- or carbon-filled stock, diamond-coated carbide holds an edge long enough to finish a batch without changing tools mid-cut.

Cooling is a trade-off. Flood coolant controls temperature well but some resins absorb moisture. Air blast or a mist works for hygroscopic grades like PA and POM. A supplier who asks which resin you are using before quoting cutting data is the one you want.

• 1
  Unfilled resinsLight passes, air blast, sharp single or two-flute cutters.
• 2
  Filled resinsDiamond-coated tooling and more frequent edge checks.
• 3
  Hygroscopic gradesDry stock before machining; avoid flood coolant.

Plastic moves. Thermal expansion is five to ten times that of steel, so a part measured at 20 °C can read differently in a warm inspection room. ±0.005 mm is achievable on a 50 mm feature in a stable grade, but it is not realistic across a 500 mm part in unfilled PP.

Warpage comes from two sources: residual stress in the stock and heat added during cutting. The first is handled by specifying cast or annealed stock and by roughing, annealing, then finishing. The second is handled by the cutting strategy above.

On the drawing, put tolerances only where they matter. Calling out a general ±0.05 mm over the whole part raises cost without improving function. Datum a few critical features and let the rest run free. This is the single biggest lever a plastics company has on the quote.

Wall thickness deserves a callout too. Thin sections flex under clamping pressure, so a shop that clamps hard will flatten them. Vacuum fixturing or soft jaws solve it, but only if the supplier knows to ask.

• 1
  Tolerance selectively±0.005 mm on critical features, general tolerance elsewhere.
• 2
  Specify stock formCast or annealed bar machines more stably than extruded.
• 3
  Expect a settling windowMeasure after the part has rested, not straight off the machine.

Molded parts have a hard floor on order size because the tool has to be paid for. Machined parts do not. A supplier set up for one-off work can take a single prototype and the same supplier can run 10,000 pieces without retooling. If the MOQ is high, the shop is pricing setup, not capability.

Certifications are not decoration. If your customer is a medical OEM, ISO 13485 is the entry ticket. Automotive work expects IATF 16949. Aerospace and defense buyers often want ISO 27001 for data handling. Ask which certificate applies to the process you are buying, not just which ones hang in the lobby.

On confidentiality, uploads should be encrypted and an NDA available before you send drawings. For a plastics company quoting a customer's unreleased product, that is not optional. It is the difference between a working relationship and a legal problem.

Finally, look at the quote itself. A useful one lists material, stock form, machine, tolerance class, finish, inspection level, and lead time as separate lines. A single number with no breakdown tells you nothing about what happens when the part does not measure up.

• 1
  No MOQOne prototype through 10,000+ piece runs.
• 2
  Certification fitMatch the certificate to the industry, not the marketing page.
• 3
  ConfidentialitySecure uploads and an NDA available on request.
