CNC machining of electronic components is subtractive. A rotating cutter follows a programmed path and removes material from a solid block, plate, or extrusion until the shape matches the CAD model. There is no mold, no tooling insert, and no draft angle unless the drawing asks for one. That single fact drives most of the design decisions on this page.

The cut is mechanical, not thermal. A 6 mm carbide end mill turning at 8,000–12,000 rpm in aluminum 6061 will hold a wall thickness of 0.8 mm without distorting it, provided the wall is supported and the tool does not chatter. In plastics such as POM or ABS, the same wall is easier to cut but harder to clamp: soft material deflects under the vise and springs back after the cut.

Most electronic parts we machine fall into four families: enclosures and chassis, heat sinks and cold plates, RF and waveguide bodies, and connector or sensor housings. Each family has a different critical dimension. For an enclosure it is often the mating face flatness. For a heat sink it is fin thickness and base flatness. For RF, it is cavity depth and surface roughness inside the waveguide.

The machining process itself does not care about the electronics. The engineering work is deciding which surfaces must be tight, which can be loose, and which features should be moved to a secondary operation such as anodizing, plating, or laser marking.

A general machining tolerance of ±0.005 mm is achievable on a 5-axis center with the right setup, but not on every feature of every part. The tighter the tolerance, the more the geometry matters. A bore that can be finished in one setup holds ±0.005 mm far more reliably than a bore that has to be reached from a second side after the part is flipped.

Flatness and parallelism are usually the dimensions that decide whether a board seats correctly. A chassis base that is 0.05 mm out of flat will rock under a PCB, and the mounting screws will pull the board into a curve. We normally hold base flatness at 0.02–0.05 mm over a 200 mm length unless the drawing calls for more.

Surface finish works the same way. Ra 0.8–1.6 μm is a normal machined finish on aluminum. Ra 0.2–0.8 μm requires a finishing pass with a smaller stepover, and it costs time. For most enclosures, Ra 1.6–3.2 μm is enough. The exception is an RF cavity or a sliding contact face, where roughness changes electrical behavior or wear rate.

Position tolerance for connector holes is often tighter than the hole diameter tolerance. A 0.1 mm shift in a USB or SMA cutout is visible and can stop a mating part from seating. Put the position callout on the drawing and keep the datum consistent with how the part is inspected.

• 1
  One setup, one toleranceFeatures cut in the same setup hold the tightest numbers.
• 2
  Flatness over sizeA 0.02 mm flatness limit on a large base is realistic; 0.02 mm on a thin floor is not.
• 3
  Finish drives cycle timeRa 0.2–0.8 μm adds a finishing pass and inspection time.

Aluminum 6061-T6 is the default for electronic housings. It machines fast, anodizes cleanly, and conducts heat at roughly 167 W/m·K. For a part that must also shield, the anodized layer is an insulator, so we mask the grounding pads or switch to a conductive anodize or electroless nickel on the contact areas.

Copper and beryllium copper show up where heat flux is high or where spring contact is needed. C101 and C110 machine well but are gummy; cutters need sharp edges and generous coolant. Beryllium copper is harder to source and must be machined with dust control because the dust is toxic. We machine it only when the design truly requires the spring properties.

Plastics cover the other half of the list. ABS and PC are common for low-cost enclosures and prototypes. POM machines to a clean finish and is often used for insulators and fixtures. PEEK holds dimension at high temperature and is common in medical and RF parts, but it is expensive and abrasive on tooling.

Stainless 304 and 316 appear in sensor bodies and food-facing electronics. They hold tolerance well but cut slowly. Titanium and Inconel are reserved for aerospace electronics and high-temperature sensor housings, where the material cost and cycle time are justified by the environment.

Deep pockets with vertical walls are the most common problem in electronic housings. A pocket 30 mm deep with a 3 mm corner radius needs a long, thin cutter. It will deflect. The result is a tapered wall and a corner that is not square. If the pocket is decorative, open the corners to 6 mm. If it is functional, expect to pay for a slower cut and a finishing pass.

Thin floors are the second problem. A 0.5 mm floor on a 100 mm × 100 mm aluminum plate will vibrate during the cut and may bow after clamping is released. We usually leave 1.0–1.5 mm for a floor that size, then relieve the back side if weight matters. In plastics, the floor can be thinner, but the clamping pressure must be reduced.

Threads are straightforward. M2 and M2.5 threads in aluminum are common for board mounting, but a 2 mm thread engagement is marginal. We recommend at least 3 mm of engagement in aluminum and 2.5 mm in steel. Helical inserts are a better choice if the screw will be removed more than a few times.

Text and logos should be engraved with a minimum character height of 1.5 mm if the part will be laser marked. Anything smaller fills in or becomes hard to read after anodizing. Put the mark in a flat area, not across a curved surface or a break edge.

CNC machining of electronic components makes sense when the quantity is low to medium, the geometry is complex, or the tolerance is tight. A single prototype housing can be machined and shipped in 3–5 days. A 10,000-part run of the same housing is usually cheaper as a die casting or injection molding, with machining only on the critical faces.

The crossover point depends on geometry, not just volume. A simple rectangular enclosure with loose tolerances can move to molding at a few thousand parts. A housing with a waveguide cavity, a thin fin array, or a ±0.005 mm bore stays on the CNC longer because the mold would need slides and inserts that cost more than the machining.

There is also the question of change. If the design is still moving, CNC is the only process that lets you change a wall thickness or a hole position without cutting a new tool. We see this most often in electronics, where the board revision and the housing revision do not always arrive together.

CNC is not always the answer. Very thin, large panels and parts with thousands of identical small holes are better on a punch or a laser. Parts with internal channels that cannot be reached by a cutter are better cast or printed. The judgment is whether the feature can be reached by a rotating tool from a realistic setup.

Anodizing is the standard finish for aluminum electronic housings. Clear anodize gives corrosion protection and a uniform appearance. Hardcoat anodize adds wear resistance on sliding surfaces. Conductive anodize is used where the housing must also ground the board, but the conductivity is lower than bare metal, so the grounding path should be verified.

Electroless nickel, zinc, silver, and gold plating serve different purposes. Electroless nickel gives a hard, uniform coating on complex shapes and is common on RF parts. Silver and gold plating are used on contacts and waveguide surfaces where surface resistance matters. These platings add thickness, so a plated thread or bore must be dimensioned with the coating in mind.

Bead blasting and tumbling change the surface texture without adding material. They are often used before anodizing to hide tool marks. Brushing gives a directional grain that can look good on a front panel but will show scratches more easily than a blasted surface.

Laser marking is the last step and the one most likely to be specified too small. A 1.5 mm minimum character height is a practical floor for a readable mark. If the mark is on a curved surface, the height should be larger, because the focus changes across the curve.
