A CNC machine does not cut to a drawing. It moves a tool along a path the CAM programmer defined, at a feed and speed the programmer chose. The finished size is that path plus deflection, tool wear and thermal growth. If the drawing calls for ±0.005 mm and the shop only holds ±0.05 mm, the part will be out of print before anyone measures it.

So the first question on any quote is not price. It is which machine, which fixture and which inspection method the shop plans to use. Those three choices set the achievable tolerance, and they are also what you should compare when you look at CNC machining Minneapolis suppliers side by side.

Roughing removes most of the material fast. Finishing passes take the last 0.2–0.5 mm and set the surface. A shop that skips a separate finishing pass, or runs it on a worn tool, will hit the nominal size but miss the Ra callout and the flatness. That shows up later at assembly, not at incoming inspection.

• 1
  Path accuracyBall screw pitch error and thermal drift move the tool off the programmed point.
• 2
  Tool deflectionLong, thin end mills push away from the wall on deep pockets.
• 3
  WorkholdingA weak fixture lets the part move during the finishing pass.
• 4
  Inspection matchA CMM reading at 20 °C is not the same as a caliper on the bench.

Tolerance is a process choice, not a number you pick for free. Standard machining on a 3-axis mill with a good fixture lands around ±0.05 mm. Move to ±0.01 mm and you need a finish pass, a temperature-stable room and more frequent in-process checks. At ±0.005 mm, the shop is measuring during the cut, not after.

Surface finish follows the same pattern. As-machined Ra 1.6–3.2 μm is normal for a roughing-and-finishing cycle. Ra 0.8–1.6 μm needs a smaller stepover and a sharper tool. Ra 0.2–0.8 μm usually means a separate finishing operation or a different process altogether, and the cycle time can double.

Here is the practical rule we use. Put the tight tolerance on the features that touch something else, and leave the rest at general tolerance. A drawing where every dimension is ±0.005 mm costs three times a drawing where two bores are tight and the bolt holes are not. Engineers who do this get better quotes and fewer arguments later.

• 1
  ±0.05 mm3-axis, simple fixture, no special room needed.
• 2
  ±0.01 mmFinish pass, stable temperature, in-process checks.
• 3
  ±0.005 mm5-axis or mill-turn, probing, CMM verification.

Most parts are 3-axis parts. If every machined face is reachable from one direction, or from two or three setups on a vise, a 3-axis machine will do the job at the lowest hourly rate. Splitting the work across setups adds a little setup time but keeps the tool rigid and the cost down.

5-axis becomes necessary when the part has features on many faces, when a single setup matters for position accuracy, or when an undercut cannot be reached any other way. A hydraulic manifold with ports on five sides is a good example. Machining it in three setups means three chances to stack a position error. One 5-axis setup removes that risk.

The trade-off is real. A simultaneous 5-axis cycle is slower to program and slower to prove out. If the part is simple, the extra capability is wasted money. If the part needs position accuracy across many faces, 5-axis is usually cheaper than the fixture you would need to do it on a 3-axis machine.

• 1
  Choose 3-axisPrismatic parts, few faces, loose position tolerance.
• 2
  Choose 4-axisCylindrical parts, slots and flats around a diameter.
• 3
  Choose 5-axisMany faces, undercuts, tight position across features.
• 4
  Choose mill-turnTurned body plus milled features, one setup.

Aluminium 6061 cuts fast and holds tolerance well, which is why it is the default for prototypes and small runs. 7075 is stronger but gummier, so feeds drop and tool wear climbs. Stainless 303 machines cleanly; 316 and 17-4PH work-harden if the tool rubs instead of cuts, and that turns a 20-minute cycle into an hour.

Titanium TC4 (Ti-6Al-4V) and Inconel sit at the hard end. They conduct heat poorly, so the heat stays in the cutting edge. Speeds drop, coolant pressure rises and tool life shortens. A part that looks simple in titanium can cost four to six times the same part in 6061. That is not a markup. It is cycle time and tool consumption.

Plastics behave differently again. POM and PEEK hold size well but move with temperature, so a part measured hot will read oversize when it cools. ABS and PC are fine for fixtures and covers but deflect under light clamping. If a plastic part carries a tight bore, say so at quoting. The shop will plan a stress-relief or a temperature soak.

• 1
  AluminiumFast, stable, best cost per part for most brackets and housings.
• 2
  StainlessWatch work-hardening; keep the tool engaged and the feed up.
• 3
  Titanium and InconelLow speeds, high coolant pressure, short tool life.
• 4
  PlasticsThermal movement dominates; measure after the part stabilizes.

Every job has a fixed part and a variable part. The fixed part is programming, fixturing and first-article inspection. The variable part is the cutting time per piece plus material. At one piece, the fixed part dominates. At 10,000 pieces, cutting time and material dominate and the setup is noise.

That is why the same bracket can cost much more per piece at quantity one than at quantity one thousand. It is also why a shop may suggest a small design change at low volume. Adding a boss that gives the vise something to grab can remove a custom fixture, and the fixture may cost more than the part.

There is no minimum order quantity on our side, from one prototype to 10,000+ part runs. But the honest advice is this: if the design is still moving, order three parts, not three hundred. Confirm the fit, then release the run. Changing a fixture after 300 parts are cut costs more than the discount you got for ordering them early.

• 1
  1–10 pcsPrototype and fit check; setup dominates the price.
• 2
  50–500 pcsSoft tooling and simple fixtures pay back quickly.
• 3
  1,000+ pcsCycle time and material rule; consider a dedicated fixture.

Inspection should match the tolerance, not the habit. A part at ±0.05 mm can be checked with calipers and a micrometer. A part at ±0.005 mm needs a CMM or a height gauge on a granite plate in a temperature-controlled room. If the quote does not mention how the tight features will be verified, ask.

We run raw material checks, in-process monitoring during the cut and a final inspection before shipment. Reports are available on request. The point of in-process monitoring is to catch drift early. A tool that has worn 0.01 mm after 40 parts will keep wearing, and the last 10 parts in the batch are the ones at risk.

The DFM report is where most of the value sits. It flags a wall that is too thin to hold, a corner radius smaller than the smallest tool, or a thread that cannot be cut without a special tap. Getting that report back within 12 hours means you can fix the model before the first chip is cut, not after.

• 1
  Loose toleranceCalipers, micrometers, visual check.
• 2
  Tight toleranceCMM, granite plate, stable temperature.
• 3
  DocumentationMaterial certs and inspection reports on request.
