Milling and turning cut with a defined edge. Grinding cuts with thousands of abrasive grains held in a bonded wheel. Each grain takes a very small chip. That is why the process can hold ±0.005 mm on a hardened 60 HRC shaft while a carbide end mill would simply rub and wear.

The practical consequence is stock allowance. A good grinding setup removes 0.1–0.3 mm per side on a cylindrical part and 0.2–0.5 mm on a surface. If the upstream milling leaves 1.5 mm, the grinder spends its time removing material instead of controlling size. Cycle time and cost both climb.

Grinding also corrects what heat treat distorts. Quenching moves a shaft by 0.05–0.15 mm, and no amount of care in the mill prevents that. The grinding pass is where the distortion is taken out and the final geometry is set.

So the question is not whether grinding is better than milling. It is whether your part needs the last 30 μm of accuracy and the surface finish that comes with it. If it does, this is the operation that decides whether the part passes incoming inspection.

• 1
  Use grinding whenHardness above 45 HRC, tolerance tighter than ±0.01 mm, or Ra under 0.8 μm
• 2
  Skip grinding whenTolerance is ±0.05 mm, finish is Ra 1.6–3.2 μm, and the part is soft aluminum
• 3
  Leave the right stock0.1–0.3 mm per side for OD and ID, 0.2–0.5 mm for flat surfaces

Aluminum grinds poorly. It loads the wheel, smears, and burns easily because the chips do not clear. If your part is 6061 or 7075 and the tolerance is ±0.01 mm, a good mill with a fine finish pass is usually the cheaper answer. Grinding aluminum is possible but rarely worth it.

Hardened steel is the opposite case. 4140 at 28–32 HRC can still be milled with carbide. Past 45 HRC, tool life collapses and the cost curve flips. Through-hardened 440C, 17-4PH after aging, and tool steel at 58–62 HRC belong on a grinder.

Stainless grades behave differently. 304 and 316 work-harden at the cut, so light passes with a free-cutting wheel are needed. 17-4PH (SUS630) is common in both aerospace and medical work and grinds cleanly when it is aged first, then finished.

Titanium TC4 (Ti-6Al-4V) and Inconel generate heat fast. They need slow wheel speed, plenty of coolant, and a dressing schedule that keeps the wheel open. Shops that quote these materials without asking about coolant pressure are usually guessing.

• 1
  Grind after heat treatNot before. Distortion is removed in the grinding pass.
• 2
  Free-cutting wheels for stainlessReduces work hardening and wheel loading on 304 and 316
• 3
  Coolant matters on titaniumHigh-pressure delivery prevents burn and subsurface cracks

A tolerance on a drawing is a promise. What matters is how it is verified. For ±0.005 mm on a diameter, a micrometer is enough if the operator is careful. For roundness, concentricity, or flatness at the same level, you need a roundness tester or a CMM, and the report should say which one was used.

Surface finish is the same story. Ra 0.8–1.6 μm is a standard as-machined grinding finish and easy to hit. Ra 0.2–0.8 μm is a fine finish and requires a dressed wheel, a light spark-out pass, and a clean machine. If a quote claims Ra 0.2 μm on a 500 mm long shaft without mentioning the setup, ask how.

Ask for the inspection plan before the order, not after. A reasonable plan covers raw material verification, in-process checks at each grinding stage, and a final dimensional report. 100% inspection before shipment is the baseline, not an upgrade.

If the part is going into a regulated product, the report is part of the deliverable. Aerospace and medical buyers should expect to see the gauge ID, the calibration date, and the operator stamp on the report.

• 1
  State the gaugeMicrometer, roundness tester, or CMM. Each proves a different thing.
• 2
  Separate size from formA diameter can be in tolerance while roundness is out.
• 3
  Request reports up frontMaterial certs, in-process data, final dimensional report

A grinding quote should list the process, the stock allowance assumed, the wheel type, and the inspection level. If it only says 'grind to drawing', you have no way to compare it against another supplier. Two quotes can differ by 40% simply because one assumes 0.1 mm stock and the other assumes 0.5 mm.

Lead time matters as much as price. A shop that quotes a grinding-only operation still needs the part on site, so shipping adds days. Ask whether the shop does the upstream turning or milling in house. If it does, the part never leaves the building and the schedule is shorter.

MOQ is another filter. Many grinding houses will not touch a single prototype because the setup cost is high. A supplier that runs from one prototype up to 10,000 part runs is more useful for product development, where the geometry changes between builds.

Finally, ask about data handling. If you are sending CAD files for a confidential program, the supplier should be able to sign an NDA and should have a documented process for storing customer data. ISO 27001 is the certificate that covers this.

• 1
  Stock allowance statedTells you how much the upstream operation must leave
• 2
  In-house upstream opsShorter schedule, fewer handling marks, one point of accountability
• 3
  MOQ and NDAPrototype-friendly suppliers and signed confidentiality both matter
