A milled logo is a three-dimensional feature cut into a solid surface. Three variables decide how it looks: the shape of the cutter, the path it follows, and how far it sinks into the workpiece. Everything else is secondary. CNC logo mastery means holding those three in a range the material and the viewer can tolerate.

Tool geometry comes first. A flat end mill leaves a square-bottom groove. A ball nose leaves a rounded trough. A V-bit leaves a chamfered wall whose width depends on depth. Two cutters of the same diameter can produce completely different edges, so the drawing has to name the intended profile, not just the letter height.

Depth-to-width ratio is the next constraint. A groove 1.0 mm wide and 0.3 mm deep reads as a scratch under raking light and holds polishing compound. Push the same groove to 0.8 mm deep and the shadow line becomes stable. Most legible marks sit between 0.5:1 and 1.5:1 depth-to-width.

Cutting force matters more than most people expect. Small tools deflect. A Ø1.0 mm end mill hanging 10 mm out of the holder will bend under load and leave tapered walls. Rough the pocket with a larger tool, then finish with the small one at shallow depth. That sequence keeps the wall straight and the floor flat.

• 1
  Cutter profileFlat, ball or V determines the wall and floor geometry.
• 2
  Depth-to-widthBelow 0.4:1 the mark reads flat under most lighting.
• 3
  Tool stick-outKeep it under 5× diameter to limit deflection.

Aluminium 6061 and 6082 cut cleanly at high spindle speed. Chips clear well and the wall finish usually lands near Ra 0.8–1.6 μm straight off the tool. Anodizing then adds a hard, uniform oxide layer that resists abrasion, which suits nameplates handled daily. Clear anodize keeps the metal look; color anodize gives contrast without paint.

Stainless 304 and 316 work-harden at the cut. Light passes with a dull tool raise the surface hardness and the next pass cuts worse. Feed per tooth has to stay above the work-hardening threshold, and coolant has to reach the bottom of the groove. The reward is a mark that keeps its edges after years of wiping and weather.

Brass C36000 machines fast and holds fine detail. A 0.3 mm wall is realistic in brass and risky in 6061. The trade-off is cost and tarnish. Lacquer or a thin electroless nickel layer solves the tarnish but adds 5–15 μm, which closes small gaps between letters.

Plastics behave differently again. PMMA and PC cut cleanly but scratch easily and hold static charge that attracts dust. POM and PEEK resist wear better but show tool marks. For these, a shallower groove with a wider chamfer often reads better than a deep, narrow cut.

• 1
  6061 / 6082Fast cutting, good as-machined finish, anodizes cleanly.
• 2
  304 / 316Watch work hardening; keep feed per tooth up.
• 3
  C36000 brassFine detail possible; plan for tarnish control.
• 4
  PMMA / PCClean cut, low scratch resistance, static dust.

Artwork rarely arrives as machinable geometry. Vector paths need closed contours, consistent stroke width and no self-intersections. Text has to be converted to outlines. A hairline stroke in a design file has no width, so the CAM programmer has to assign one, and that number is a manufacturing decision, not a design one.

Setup decides repeatability. Engraving one logo on one plate is easy. Engraving the same logo on five hundred plates needs a fixture that locates each blank the same way and a tool-length offset checked between batches. Zero-point clamping systems and pre-set tool holders cut the variance.

Cutting parameters follow a simple rule: shallow passes, moderate feed, high spindle speed. For a Ø1.0 mm two-flute carbide cutter in 6061, a common starting point is 15,000–20,000 rpm, 0.05 mm depth per pass and 400–600 mm/min feed. Adjust from there based on chip shape and sound.

Finishing runs last and changes dimensions. Bead blasting softens edges and lowers gloss. Laser marking after anodizing gives a high-contrast black mark but adds no depth. Plan the sequence so a surface treatment never lands between two machining operations that must stay aligned.

• 1
  Outline all textLive text will not post-process reliably.
• 2
  Close every contourOpen paths break pocketing toolpaths.
• 3
  Fixture before volumeLocate blanks identically for batch repeatability.
• 4
  Order the finishing stepsDo not split aligned operations across a coating.

There is a floor on feature size. A Ø0.5 mm cutter is about the smallest practical tool for production work in aluminium, and it needs a spindle that can spin fast enough to keep chip load sane. Below that, tool breakage rate rises and cost per part climbs faster than the visual gain.

Inside corners cannot be sharper than the cutter radius. A drawing with a true 90° internal corner is asking for a tool that does not exist. Adding a radius equal to the tool radius costs nothing and removes a hand-deburring step later. Tell the programmer the radius is a manufacturing allowance, not an aesthetic choice.

Deep, narrow grooves are the other ceiling. As depth-to-width climbs past 2:1, chip evacuation fails and the tool rubs. In stainless that means work hardening and a rough floor. If the design needs a deep slot, widen the top with a chamfer or cut it in two passes with a larger tool first.

High-contrast multi-color logos usually need a second process. Machining alone gives one material color plus shadows. Anodizing, plating, powder coating or pad printing fills the second color, and each adds its own tolerance and lead time. Count that in before promising a date.

• 1
  Tool floorØ0.5 mm is the practical lower limit in production.
• 2
  Corner radiusInternal corners cannot be sharper than the cutter.
• 3
  Aspect ratio capKeep depth-to-width under 2:1 for clean chips.
• 4
  Second colorExpect a separate coating or printing step.
