Foam is a cellular solid. Most of its volume is gas, so the cutter is not really shearing dense material; it is separating cell walls. That changes everything about the cutting window. A sharp two-flute end mill at high spindle speed and high feed will slice cells cleanly. A dull tool at low feed rubs the cells, melts the binder, and leaves a fuzzy edge that no amount of sanding fully recovers.

Chip evacuation matters more than in aluminum. Foam chips are light and bulky, and they pack into the flute before they pack into the chip tray. If the chips stay in the cut, they get re-cut, which polishes the wall and heats the surface. A single-flute or two-flute upcut tool with a strong air blast solves most of this. Compressed air, not flood coolant, is the normal choice because most foams absorb liquid and swell.

Rigidity is the other half of the story. Foam is soft, but it is not stiff. A 600 mm long unsupported foam wall will deflect away from the cutter under very light load. The fix is not more horsepower; it is better workholding and a lighter finishing pass. Vacuum tables, double-sided tape, and sacrificial backing boards work better than vise jaws, which crush the cells on contact.

One more mechanic worth understanding: foam has almost no thermal mass. Heat generated at the tool tip has nowhere to go, so it stays at the surface. That is why spindle speed and feed rate must be matched to the foam density, not set by habit. Run too slow and the foam smears; run too fast and the binder burns and discolors the cut.

• 1
  Sharp tools, high speedA dull edge rubs and melts instead of cutting.
• 2
  Air, not coolantMost foam absorbs liquid and changes dimension.
• 3
  Support the partSoft material deflects under cutting load.

Density drives behavior more than chemistry does. Below roughly 30 kg/m³, EPS and similar bead foams crumble rather than cut; you can shape them, but the surface is a field of loose beads. Between 30 and 80 kg/m³, PU tooling board and XPS start to hold a crisp edge, which is the range most prototype work lives in. Above 200 kg/m³, PVC structural foam behaves almost like a soft plastic and machines with normal carbide tooling.

Bead foam is the awkward case. Expanded polystyrene is cheap, light, and available in large blocks, but individual beads pull out at the cut line. That is acceptable for a lost-foam casting pattern or a sand casting plug where the surface is going to be coated anyway. It is not acceptable for a display model or an aerodynamic buck where surface continuity matters.

Cross-linked PVC and polyurethane tooling boards are the workhorses. They hold sharp internal corners, accept a fine stepover, and can be sanded and primed to a smooth finish. They also hold screw threads well enough for temporary fixturing. The trade-off is price and weight; a large tooling board block costs considerably more than the same volume of EPS.

Closed-cell foams resist moisture and machine with a slightly gummy chip. Open-cell foams cut more freely but tear at the edges and absorb dust. Neither is a problem if you pick the right one for the job. The problem starts when a designer specifies a foam by name without specifying density, and the shop receives whatever grade the supplier had in stock.

• 1
  EPS bead foamCheap and light; loose beads at the cut line.
• 2
  PU and PVC tooling boardHolds edges and finish; the standard prototype choice.
• 3
  EVA and PE foamTough and flexible; gummy chips, harder to finish.

Foam routing lives and dies by the toolpath, not the spindle. A light roughing pass at 2–4 mm depth of cut removes the bulk without loading the flute. A finishing pass at 0.2–0.5 mm stepover produces the surface. Skip the finishing pass and you will spend the same time sanding, with worse geometry control. On large 3D shapes, a ball nose tool at 8–12 mm diameter with a 6–10 percent stepover is a reasonable starting point.

Spindle speed depends on density. Soft foams run fast, often 12,000–18,000 rpm, because the material offers little resistance and the high surface speed shears cells. Dense PVC foam runs slower, closer to 6,000–10,000 rpm, because the tool needs time to clear the gummy chip. Feed rates follow the same logic: 3,000–8,000 mm/min for light foams, 1,000–3,000 mm/min for dense ones.

Workholding deserves a separate paragraph because it is where most foam jobs fail. A vacuum table with a dedicated spoilboard is the cleanest option for flat panels. For 3D blocks, double-sided carpet tape plus a low-profile toe clamp at the corners gets you through a light finishing pass. Never clamp a foam block in a steel vise and expect the geometry to survive; the jaws indent the surface and the part springs back unevenly.

Dust control is not optional in production. Foam dust is light, travels far, and in the case of some grades is a respiratory irritant. A downdraft table, a brush skirt around the tool, and a proper filtration unit keep the shop clean and the cut clear. The same airflow that removes dust also cools the tool, so dust extraction and cut quality are the same problem.

• 1
  Rough light, finish light2–4 mm depth of cut, then 0.2–0.5 mm stepover.
• 2
  Match speed to density12,000–18,000 rpm soft, 6,000–10,000 rpm dense.
• 3
  Vacuum or tapeVise jaws crush cells and distort the part.

Foam is not a precision material, and treating it like one wastes money. On a stable PU tooling board, a well-supported part can hold roughly ±0.1 mm on a critical profile. On soft bead foam, ±0.5 mm is realistic and sometimes optimistic, because the surface compresses under the probe. If your drawing calls for ±0.005 mm, foam is the wrong process regardless of how good the machine is.

Surface finish follows the same rule. As-machined foam typically sits around Ra 3.2–6.3 μm, and sanding brings it to a visually smooth surface without a meaningful Ra figure, because the material is porous. If you need Ra 0.8–1.6 μm, the foam part is usually a pattern for a cast or composite layup, not the final surface. The finish comes from the tooling that foam produces, not from the foam itself.

Size is where foam wins outright. Large-format routing handles blocks far beyond typical metal envelopes; our own 5-axis centers reach 4,000 × 400 × 150 mm of travel, and larger blocks can be indexed. A one-piece 2 m aerodynamic buck or a full-size architectural massing model is normal foam work and very unusual metal work.

The real limit is load bearing. Foam has low stiffness and low strength, so it cannot be a structural part. It can be a master, a pattern, a plug, a check fixture, or a display model. If the part must carry load in service, the foam is a step in the route toward a metal or composite component, not the component itself.

• 1
  Practical toleranceAbout ±0.1 mm on tooling board, ±0.5 mm on bead foam.
• 2
  Finish is a pattern finishPorous surface; fine Ra comes from the cast part.
• 3
  Size is the strengthLarge single-piece shapes are routine.

Most foam parts are not the deliverable. They are the shape that makes the deliverable possible. A common route is foam master, then surface sealing and sanding, then a composite layup or a silicone mold, then a cast urethane or resin part. The foam is chosen for how easily it can be shaped and removed, not for how it performs in service.

Sealing is the step that decides how good the downstream surface will be. Bare foam absorbs resin and releases it unevenly. A primer or epoxy sealer coats the cells and gives a consistent release surface. Two thin coats work better than one thick coat, because a thick coat sags and fills the detail you just machined.

For lost-foam casting, the pattern is buried in sand and vaporized by the molten metal. That route tolerates a rougher surface and lower dimensional accuracy, which is why low-density EPS is acceptable there. For a composite tool or a vacuum-formed buck, the surface has to be better, so a denser tooling board with a sealed finish is the right call.

Tooling foam also shows up as check fixtures and assembly aids. A fixture that holds a part during measurement does not need to survive years of use; it needs to be accurate once and cheap to replace. Foam fits that brief well, provided the contact points are protected with a hard insert.

• 1
  Seal before releaseTwo thin primer coats beat one thick coat.
• 2
  Lost foam tolerates roughLow-density EPS is fine for casting patterns.
• 3
  Fixtures need insertsProtect contact points against wear.
