Door hardware looks simple from the hallway side. Take the hinge leaf off and you find a set of features that reference each other across two or three parts: the hinge cup depth in the door, the screw hole pattern in the frame, the lock case position, the closer arm pivot. Each one carries its own tolerance. Stack them and a 0.2 mm error at the cup becomes a door that rubs at the strike jamb.

That is why a CNC door machine is judged on positional accuracy, not just on surface quality. A machining center that holds ±0.005 mm on a single bore but drifts 0.05 mm between two setups will still produce a hinge that binds. The machine is only half the story. Fixturing, datum choice and in-process probing carry the other half.

Three-axis work still covers flat plates, strike plates and simple brackets, and it does so cheaply. The moment a part has an angled face, a deep undercut or a pocket that must blend into a curved surface, the setup count climbs. Every extra setup adds a re-clamp, and every re-clamp adds stack-up. Five-axis machines remove setups, which is why they matter here.

Wall thickness is the quiet constraint. A die-cast or billet hinge leaf might be 2.5 mm thick at the knuckle. Cutting a screw boss into that wall leaves little material for thread engagement. Below about 1.5 mm of remaining wall, deflection during clamping starts to move the part, and no amount of machine accuracy recovers it.

• 1
  Positional accuracy beats peak accuracyFeature-to-feature location is what the assembly feels.
• 2
  Every setup costs toleranceRe-clamping re-introduces error that no probe can fully remove.
• 3
  Thin walls deflectBelow roughly 1.5 mm remaining wall, clamping force becomes a variable.
• 4
  Draw the stack firstDecide which feature absorbs the slack before choosing a process.

A datum is the face or feature you trust. On door hardware, the trusted face is almost always the mounting face that touches the door or the frame, because that is the surface the installer references. Everything else, bores, slots, pilot holes, is measured from it. Choose it once and keep it through every operation.

The common mistake is to datum from the finished cosmetic surface because it is easy to clamp. Cosmetic faces get polished, coated and sometimes reworked. Their position moves. A datum that moves is not a datum. Clamp on a machined face that will not be touched again, even if the fixture gets more complicated.

For a mortise lock case, we usually machine the mounting face and two adjacent edges in the first operation, then use those three features as the reference for the rest. That gives a repeatable origin for the cylinder bore, the latch slot and the screw holes. On a five-axis center, the part can stay in the same fixture for the remaining features, which keeps the origin intact.

When a part cannot be held on its mounting face, a sacrificial tab or a soft-jaw pocket works. Both add material removal later. Both are cheaper than a scrapped run. The decision usually comes down to part count: one prototype justifies a soft jaw, a 10,000-piece run justifies a dedicated fixture with hardened locators.

• 1
  Datum from the mounting faceIt is the surface the installer will reference.
• 2
  Never datum from cosmetic surfacesPolishing and coating move them.
• 3
  Three features in the first operationOne face plus two edges gives a stable origin.
• 4
  Sacrificial tabs for awkward shapesExtra material removal, but a repeatable hold.

Aluminium 6061-T6 is the default for hinge leaves and closer arms. It machines fast, holds a thread, and anodizes cleanly. Hardcoat anodizing adds a wear surface on sliding contact, though it also adds roughly half the coating thickness in each direction, so bores that must stay tight should be masked or left oversize.

Stainless 304 and 316 show up on exterior and marine doors. They work-harden, so light passes with sharp tooling beat heavy passes with dull tooling. A dwell in the cut is what kills the tool and the finish. 17-4PH is common on high-load pivots and closer arms because it takes heat treatment after machining without losing dimensional stability.

Zinc die-cast ADC12 covers high-volume lock cases and handles. It machines easily but the skin is harder than the core, and thin walls flex under clamping. Leave 0.3–0.5 mm of stock for the finishing pass and take it in one light cut. Brass C36000 remains the choice for cylinder bodies and decorative trim because it machines freely and takes a fine polish.

Titanium TC4 and Inconel appear on fire-rated and security-rated assemblies. Both are slow, both cost more, and both are usually limited to small high-stress components such as pivots or pins. If a standard stainless part passes the load case, that is the better answer. Use the exotic alloy only where the specification demands it.

• 1
  6061-T6Default for hinge leaves and arms; anodizes cleanly.
• 2
  304 / 316 stainlessWork-hardens; keep passes light and tools sharp.
• 3
  ADC12 zincLeave 0.3–0.5 mm for the finishing cut.
• 4
  C36000 brassFree-machining, takes a fine polish.

Three-axis machines cut from one direction. A hinge knuckle, a cylinder bore that meets a latch slot at 90°, or a blended pocket on a closer arm cannot be reached that way without multiple fixtures. Each fixture adds a re-clamp. On a part with a 0.05 mm positional budget, three setups will eat the whole budget before the first chip is cut.

A five-axis machine tilts the tool or the table, so the same part can be finished from several directions in one hold. The gain is not speed, it is positional consistency. The origin never moves. On a 16-machine five-axis fleet, we typically see hinge and lock parts finished in one or two setups where three-axis routing needed four or five.

There is a limit. Deep, narrow cavities still need long, thin tools, and those tools deflect. A 6 mm deep slot that is 3 mm wide will chatter regardless of how many axes you have. In that case the fix is a design change, not a machine change. Widen the slot or open the corner radius.

Long parts change the calculus again. A 4,000 mm door rail cannot be rotated on a standard trunnion table. It runs on an extended-travel three-axis machine with a long-bed fixture. The geometry is simple, so the extra axes would add nothing.

• 1
  Under 0.05 mm positional budgetFewer setups beat more accurate setups.
• 2
  Angled faces and undercutsFive-axis reaches these without a second fixture.
• 3
  Deep narrow slotsTool deflection is the limit; redesign the slot.
• 4
  Parts over 1,500 mmExtended three-axis travel is usually the right call.

Finish numbers on a door hardware drawing are usually about wear and feel, not appearance. A closer arm pivot running in a bore needs Ra 0.8–1.6 μm to keep the oil film stable. A decorative face needs Ra 0.2–0.8 μm so the anodized color reads evenly. A hidden bracket needs nothing beyond Ra 1.6–3.2 μm.

Coating changes dimensions. Hardcoat anodizing builds 25–50 μm per surface, so a bore called out at Ø10.00 mm H7 must be machined undersize or masked. Electroless nickel adds 10–25 μm per surface. Powder coating is far thicker and should never be applied to a tolerance-critical bore. Put the coating callout on the drawing next to the tolerance, not in a general note.

Inspection follows the stack. We check the datum features first, then the features that reference them, then the assembly fit. A bore that measures perfectly but sits 0.08 mm off the datum will still fail a go/no-go gauge on the assembled hinge. Reports are available on request, and every part is inspected before shipment.

The final check is a fit test on a gauge or a mating part. For lock cases, that means a cylinder drop-in. For hinges, that means a knuckle pin through both leaves. If the pin binds, the bore positions are wrong even if each bore measures in tolerance.

• 1
  Ra 0.8–1.6 μmBearing and pivot surfaces.
• 2
  Ra 0.2–0.8 μmDecorative faces before anodizing.
• 3
  Hardcoat adds 25–50 μm per surfaceAdjust the bore or mask it.
• 4
  Fit test beats a CMM reportA pin through the knuckle proves the stack.
