3D printing STL format explained

STL stands for stereolithography, named after the process that made it useful in the late 1980s. The format is a list of triangles. Each triangle is defined by three vertices and a normal vector that points outward. That is the whole data model. There is no feature tree, no sketch, no dimension, no material assignment, and no build direction.

Because the file describes a boundary rather than a volume, the slicer has to guess what is inside. It reads the triangle soup, checks that the surface is closed, and then decides which regions are solid. A gap of 0.02 mm between two triangles is enough to break that decision. The part may still look correct on screen while the slicer reports zero shells.

The format also stores no units. A value of 10 in an STL file could mean 10 mm, 10 cm or 10 inches. Most software assumes millimeters, and most exporters write millimeters, but nothing in the file enforces it. When a quote comes back with a part 25.4 times larger than expected, a unit mismatch is usually the cause.

Two encodings exist. ASCII STL is human-readable text, roughly five to ten times larger than the same model in binary. Binary STL packs each triangle into 50 bytes and is the standard for anything beyond a few hundred triangles. Both carry the same geometry, so the choice is about file size, not accuracy.

• 1
  Vertices and normalsEach triangle carries three points plus one outward normal.
• 2
  No units fieldScale is an assumption, not data. Confirm mm before export.
• 3
  No color or materialMulti-material jobs need 3MF or separate bodies.
• 4
  No build orientationSupport and layer direction are set in the slicer.

The slicer cuts the mesh into horizontal planes. At each layer height it intersects every triangle with a plane and connects the resulting segments into closed contours. Those contours become the perimeter paths. The interior is filled with a hatch pattern at a chosen density.

Layer height drives the trade-off between surface finish and time. A 0.1 mm layer gives a smoother side wall than 0.3 mm, but it roughly triples the number of layers and the print time. For an FDM part that only needs to fit a bracket, 0.2 mm is usually enough. For a visible enclosure, drop to 0.1 mm and accept the longer run.

Triangle density matters here. A coarse mesh with large flat triangles produces contours that look faceted on curved surfaces. A dense mesh improves the curve, but only up to the point where the chord error falls below the layer resolution. Adding triangles beyond that point increases file size and slice time without changing the printed shape.

Thin features are the other limit. A wall thinner than two extrusion widths may be skipped or printed as a single weak line. In resin printing, a wall under 0.4 mm often warps during post-cure. If a design has a 0.3 mm rib, the printer will tell you about it in the preview, not in the CAD model.

• 1
  Layer height0.1 mm for visible surfaces, 0.2–0.3 mm for fit checks.
• 2
  Chord errorExtra triangles help only until faceting drops below layer height.
• 3
  Minimum wallKeep walls above two extrusion widths where strength matters.

Send STL when the part will be printed as a single material and the geometry is already final. It is the most widely accepted format across FDM, SLA and metal binder jetting workflows. Print shops read it without conversion, and the slicer output is predictable.

Send STEP when the part needs machining, when a critical dimension must hold to ±0.005 mm, or when the receiving shop has to inspect the model. A mesh cannot carry a tolerance callout. A triangle approximation of a Ø20 mm bore is not a Ø20 mm bore, and no amount of triangle density changes that for a CNC programmer.

If the print is multi-color or needs embedded material data, use 3MF. It stores units and material assignments in the file, which removes the scale guesswork. STL has no field for either.

Scanned or topology-optimized parts often arrive as STL because that is what the software exports. Those meshes usually need repair first: flipped normals, self-intersections, open edges. A repair pass in the slicer or a mesh tool takes minutes and prevents a failed print.

For a prototype that will later be machined, the cleanest route is to keep the native CAD and export both. Print from the STL, machine from the STEP. The two files stay in sync because they come from the same source.

• 1
  Print-only partSTL is fine and universally accepted.
• 2
  Machined partSend STEP. Mesh files lose dimensional intent.
• 3
  Multi-materialUse 3MF so units and materials travel with the file.
• 4
  Scanned meshRepair normals and open edges before slicing.

Check that the mesh is watertight. Most slicers flag this automatically, but the check is easy to miss when the model is complex. Look for open edges, non-manifold edges and flipped normals. A single flipped triangle can make the slicer treat solid material as empty space.

Confirm the scale. Measure a known feature in the slicer and compare it against the CAD model. If the part should be 120 mm long and the slicer reports 4.72 mm, the export used inches. Fix the export setting rather than scaling the mesh, because scaling a mesh introduces its own rounding.

Set a sensible triangle budget. A printable mechanical part rarely needs more than 200,000 triangles. Files above a few million triangles slow slicing and add nothing to the printed surface. Export with a chord tolerance around 0.01 mm and an angle tolerance near 15 degrees for most parts.

State the print process and material in the request. The same STL prints differently in PLA, nylon, resin and metal. Wall thickness, draft angles and minimum feature size all shift with the process. A file that prints cleanly in resin may fail in FDM because the overhangs were never designed for support.

For parts heading to CNC afterward, include the STEP file and the critical dimensions. The mesh shows shape. The STEP and the drawing show what must be measured. Both are useful, and the shop can work from whichever fits the operation.

• 1
  Watertight checkNo open edges, no flipped normals, no self-intersections.
• 2
  Scale checkMeasure one known dimension in the slicer before uploading.
• 3
  Triangle budgetChord tolerance 0.01 mm, angle tolerance about 15 degrees.
• 4
  Process statedName the printer type and material with the file.
