CNC Machining Local Service Provider Guide: What to Check Before You Order

• 1
  Key takeaways
• 2
  Which provider type fits your part
• 3
  Tolerance: read the drawing before the price
• 4
  Material and finish: where hidden cost sits
• 5
  Lead time: ask for two dates
• 6
  Order size: no MOQ and what it means for you
• 7
  Certifications and data handling
• 8
  Quoting: what a useful quote contains
• 9
  Inspection and what ships with the parts
• 10
  How to vet a local CNC provider in 6 steps

Most RFQ arguments trace back to one line on the drawing. If the title block says general tolerance ±0.1 mm and two bores say ±0.005 mm, those two bores set the price, the machine choice and the inspection plan. Send the full drawing with the GD&T frame, not a stripped STEP file.

A ±0.005 mm callout on a 20 mm bore is normal work on a temperature-stable machine. The same callout across a 900 mm aluminum frame is a different problem. Thermal growth in aluminum runs near 23 μm per meter per degree Celsius, so a 5 °C shop swing moves the part more than the tolerance. That is why large tight parts need either a controlled room or an in-process probing cycle.

Ask how the shop verifies the tight features. A CMM report on the first article is the baseline. If the shop cannot name the instrument, they are not measuring the feature you specified.

• 1
  Do thisFlag the tight features in red on the drawing and list them in the RFQ email.
• 2
  Avoid thisBlanket ±0.005 mm on every dimension. It triples cost with no functional gain.
• 3
  Ask thisWhich machine will run this feature, and what is its stated positioning accuracy?

Material availability drives lead time more often than machining does. 6061-T6 and 304 stainless are stocked in most service centers. 7075, 17-4PH and Ti-6Al-4V often are not, and a two-week mill order lands in the middle of your schedule. Ask the shop to confirm stock before they confirm the date.

Machinability varies widely inside one alloy family. Free-machining 303 stainless cuts three to four times faster than 316L and gives a better as-machined finish. If the part sees no corrosive service, 303 is the cheaper correct answer. If it is a medical or marine component, 316L is not optional and the quote should reflect the slower speeds.

Finish specs cause as many rejections as dimensions. Anodize builds 5–25 μm per surface depending on the process, which moves a press-fit bore. Specify whether the tolerance applies before or after coating, and call out masked areas. For cosmetic parts, order a finish sample on the same alloy before the production run.

• 1
  As-machinedRa 1.6–3.2 μm. Fine for brackets, housings and internal parts.
• 2
  Standard fineRa 0.8–1.6 μm. Sealing faces, bearing seats, sliding surfaces.
• 3
  High finishRa 0.2–0.8 μm. Optical, vacuum and low-friction contact surfaces.
• 4
  Coating buildHardcoat anodize grows more than clear. State pre- or post-plate tolerance.

A single lead-time number is a marketing figure. Split it. First-article date covers programming, fixturing and the first cut. Shipment date covers the full run plus finishing and inspection. A shop that quotes 5 days for both is either very fast or has not checked its own queue.

Production does not start when the PO is signed. It starts when the drawing is frozen, the material is on the floor and the fixture is proven. On a clean repeat job with stock material, a shop can be cutting within 24 hours of PO release. On a new 5-axis part with a 40-hour cycle and a custom fixture, the first cut may be three days out.

Late delivery has a measurable cause in most shops: material slips, first-article rework, or finishing outsourced to a vendor with its own backlog. Ask which of the three is the shop's usual risk. The honest answer tells you more than the quoted date.

A no-minimum-order policy is a real signal, not a courtesy. It means the shop can absorb the setup cost of a single part without spreading it over a batch. For you, it removes the pressure to order 500 pieces of a design you have not tested.

The same floor should handle both ends. If a shop runs one prototype on a 5-axis center and a 10,000 part run on a mill-turn cell, the process plan carries from prototype to production with the same fixturing logic. If the prototype goes to a different vendor than the production run, expect a second first-article cycle.

Bridge tooling is where small runs get expensive. A soft jaw set for 50 parts is cheap. A dedicated fixture designed for 10,000 parts is not, and it should be quoted as a separate line so you can see what you are buying.

Certificates matter when your customer audits you. ISO 9001:2015 is the floor for any serious shop. IATF 16949:2016 is what automotive and EV programs require. ISO 13485:2016 applies to medical device components. ISO 27001:2022 covers information security, which is the one to check when your files are proprietary.

Ask for the certificate scope, not just the logo. A certificate that covers machining at one plant does not automatically cover a partner site. If the shop subcontracts finishing or heat treatment, the scope question applies to those vendors too.

Confidentiality is a process, not a promise. A signed NDA, encrypted upload, and named file access are the three things to confirm. If drawings are sent as email attachments to a personal address, the NDA is the only control in place.

• 1
  ISO 9001:2015Baseline quality management. Ask for the current certificate number.
• 2
  IATF 16949:2016Automotive and EV parts. Requires PPAP-level documentation.
• 3
  ISO 13485:2016Medical devices. Traceability and process validation expected.
• 4
  ISO 27001:2022Information security. Relevant for proprietary CAD and IP.

A price with no breakdown is not a quote, it is a number. A useful quote lists material, machining time, setup or fixturing, finishing, and inspection. When one of those lines is missing, it is usually folded into another and marked up.

Quoting speed matters at the front of a project. A shop that returns a quotation and a free DFM analysis within 12 hours is telling you its engineering capacity is not the bottleneck. Slow quoting often means slow problem-solving later.

Read the DFM notes carefully. The most valuable quote is the one that tells you a wall is too thin for the alloy or a tolerance is unreachable without a second setup. If the quote has no comments, either the part is trivial or nobody looked at it.

Inspection is the last place cost gets cut, and the first place you feel it. A shop running 100% inspection before shipment checks raw material on receipt, monitors in-process, and performs a final dimensional review. Reports are available on request, and you should request them on any regulated part.

Ask what happens to a nonconforming part. A shop that reworks and re-inspects is different from one that ships and waits for your incoming inspection to catch it. The rework loop should be documented.

For first articles, ask for a full dimensional report against the drawing, not a sample of dimensions. For production runs, agree on the sampling plan in writing before the PO. The gap between the two is where most disputes live.
