The first decision is not which shop, it is how many axes the part actually needs. A bracket with flat faces and open pockets runs faster on a 3-axis mill. A part with features on four sides may only need one 4-axis setup. The axis count changes setup count, fixture cost, and how many times the part is touched.

Reach matters as much as axis count. A deep cavity with a 6:1 depth-to-diameter ratio needs a long, thin tool, which deflects under load. A 3-axis machine can cut it, but you may lose tolerance on the walls. A 5-axis head tilts the tool to keep the flute engaged, which holds size and improves surface finish.

When a part has undercuts, blended surfaces, or a port that points at an angle, fewer axes means more setups. Each extra setup adds a re-fixturing error of roughly 0.01–0.03 mm. That error can eat most of a ±0.005 mm tolerance before the cutter touches metal.

There is a real limit. If the part is a simple plate with two faces and a few holes, five axes add cost and no value. Use the cheapest machine that reaches every feature in one or two setups.

General machining holds ±0.1 mm without effort. Tightening to ±0.05 mm changes tool paths, coolant, and inspection. At ±0.005 mm the shop needs temperature control, sharp tooling, and a CMM check on the critical features. The number should come from the fit and function, not from habit.

A common mistake is a title block that says ±0.005 mm while the mating part has ±0.1 mm clearance. That mismatch adds cost on both sides. Put tight tolerance only on the datum, the bearing bore, the sealing face, and the pin hole.

Surface finish and tolerance travel together. A Ra 0.8–1.6 μm finish is normal for a machined sealing face. Ra 0.2–0.8 μm needs a finer step-over, a fresh insert, and sometimes a second finishing pass. Ra 1.6–3.2 μm is fine for brackets and covers.

If the drawing calls for both a tight tolerance and a rough finish, ask whether the finish is decorative. If it is, bead blasting or tumbling can get there faster than a precision cut.

Aluminum 6061 and 7075 cut fast and hold tolerance well, which makes them the default for prototypes and small runs. 7075 is stronger but more prone to distortion on thin walls. Stainless 304 and 316 work-harden, so the cutter has to keep moving; dwelling on the surface kills the edge and the finish.

Titanium Ti-6Al-4V and Inconel 718 need low cutting speeds, high coolant pressure, and rigid setups. Cycle time can be three to five times that of aluminum for the same shape. If the part does not need the heat resistance, switching to 17-4PH stainless often cuts cost without losing strength.

Plastics behave differently. POM and PEEK machine cleanly but move with temperature. ABS and PC can gum up if the feed is too low. A shop that runs plastics regularly will use sharp, polished tools and air blast instead of flood coolant.

Material availability affects lead time. Grades like 4340, beryllium copper, and magnesium AZ31B are not always on the shelf. Confirm stock before promising a ship date, or the schedule slips at the material stage.

Anodizing adds 5–25 μm per surface, depending on the type. Hardcoat can add more. That growth matters on threads and press fits. Masking threads and bores is normal, but it has to appear on the drawing before the parts are cut, not after.

Electroless nickel gives a uniform coat on complex shapes and tight bores, which is why it shows up on hydraulic and aerospace parts. Zinc plating is cheaper but less uniform. Silver and gold plating are used for conductivity, not corrosion.

Bead blasting and tumbling remove tool marks and edge burrs. They also round sharp corners slightly, which can matter on a sealing edge. Brushing leaves a directional grain. Polishing reaches a mirror finish but hides scratches rather than removing them.

Laser marking needs a minimum character height of 1.5 mm to stay legible. If the drawing calls for a 0.8 mm serial number, plan for a different marking method or a larger area.

Start with the quote. A useful quote lists material grade, machine type, tolerance on critical features, finish, inspection method, and lead time. A single number with no process notes tells you little about whether the shop read the drawing.

Ask for the DFM notes. A shop that flags a thin wall, an unreachable corner, or a tolerance that is tighter than the function needs is doing the work. Those notes save a revision cycle later.

Confirm the inspection plan. 100% inspection before shipment, with raw material check, in-process monitoring, and final inspection, is a reasonable baseline. Reports on request are normal. If the supplier cannot say what instrument measures your critical feature, that is a gap.

Check the certifications against the industry. ISO 9001:2015 covers general quality systems. IATF 16949:2016 applies to automotive. ISO 13485:2016 applies to medical devices. ISO 27001:2022 covers information security, which matters when your drawings are confidential.

Finally, look at capacity. A shop with 16 simultaneous 5-axis centers, 12 four-axis mills, 27 three-axis machines, and 16 mill-turn centers can route a job to the right machine instead of forcing it onto whatever is free.
