TPU stands for thermoplastic polyurethane. It is a block copolymer built from two alternating segments: a hard segment that behaves like a rigid urethane, and a soft segment that behaves like a rubbery polyol. The hard segments cluster into domains and act as physical crosslinks. The soft segments stretch between them.

That structure is why TPU springs back instead of flowing like a wax. Heat the polymer above its softening range and the hard domains loosen enough for the material to flow. Cool it and they re-form. No chemical cure is involved, which is why scrap can be remelted and why the same spool prints the same way next week.

The ratio of hard to soft segment sets everything you care about on the shop floor: Shore hardness, tensile strength, rebound, compression set, and how much the filament resists buckling. Printers do not change chemistry. They only change how well that chemistry is laid down.

Additives shift the picture further. UV stabilizers extend outdoor life, flame retardants change the electrical rating, and colorants can slightly change melt flow. If your part sits in sunlight or near a motor, ask for the grade data sheet rather than assuming all TPU behaves alike.

• 1
  Hard domainsPhysical crosslinks that recover shape after stretch
• 2
  Soft domainsRubbery chains that set elongation and rebound
• 3
  No cure stepRemeltable, so scrap and purge can be reprocessed

The problem is stiffness, not temperature. A Bowden tube printer pushes filament through a meter of PTFE before it reaches the melt zone. Rigid PLA transmits that push. TPU at Shore 85A bends sideways in the tube and folds into a buckle. Once it buckles, the extruder keeps turning and the nozzle stops receiving material.

Direct drive extruders fix most of this by putting the drive gears centimeters from the melt zone. The unsupported length drops, so the filament cannot bow out. Short reverse-Bowden setups help too, but a long tube plus soft TPU is a combination that fails on tall parts.

Retraction is the second trap. Every retraction pulls a rubbery strand back through a hot zone, and TPU tends to string or clog on the return. Many flexible parts print fine with 0.5–1.5 mm retraction at 15–25 mm/s, or with retraction disabled entirely when the tool path avoids long travels.

Temperature sits in a narrow band. Most 85A–95A grades print between 220 and 240 °C with a heated bed at 40–60 °C. Go too cool and layers delaminate; go too hot and the filament drools and the part loses dimensional control.

• 1
  Direct driveCuts unsupported filament length to a few centimeters
• 2
  Low retraction0.5–1.5 mm at 15–25 mm/s, or off entirely
• 3
  Narrow window220–240 °C nozzle, 40–60 °C bed for 85A–95A

Shore hardness is measured on a durometer and reported on the A or D scale. Flexible printing grades cluster between 85A and 95A. A 95A filament feels like a stiff rubber sole. An 85A filament feels like a rubber band and will stretch visibly under hand pressure.

Lower numbers print worse. At 85A the filament is soft enough to ovalize inside the extruder and to stretch between the drive gear and the nozzle. Expect speeds of 15–25 mm/s and a lot of tuning. At 95A you can often run 30–40 mm/s on a direct drive machine and still get clean walls.

Above 98A, TPU behaves more like a semi-rigid plastic. It prints almost like PETG, machines acceptably, and holds a thread better. Below 85A you are in territory where pellet printers or cast urethane make more sense than filament.

For most brackets, grommets, seals, and grips, 95A is the practical compromise: enough flex to absorb impact, enough stiffness to feed reliably and hold a bolt torque without creeping.

• 1
  95AGeneral-purpose flex, prints at 30–40 mm/s on direct drive
• 2
  90ASofter seals and pads, slow speeds, tight tuning
• 3
  85AMaximum stretch, 15–25 mm/s, high failure risk on Bowden

Wall thickness drives stiffness more than infill does. A 1.2 mm wall in 95A TPU bends easily; a 2.4 mm wall of the same material feels rigid. If a part is too floppy, add a wall before you change material. If it is too stiff, thin the wall or drop to 90A.

Infill below 25 percent rarely helps. The shell resists bending, and a sparse lattice inside mostly adds print time and traps flexing stress at the shell-to-infill joint. For cushions and pads, use a gyroid or honeycomb pattern at 10–20 percent so the cell walls compress evenly instead of collapsing in one direction.

Avoid long unsupported bridges and steep overhangs. Soft filament sags before it cools, so anything past about 45 degrees from vertical will droop. Split the part so overhangs face down, or add a chamfer that lets the next layer sit on solid material.

Threads printed in TPU strip easily. Molded-in brass inserts or a captured nut hold far better, and a through-bolt with a washer spreads load across the flexible face instead of tearing it. If the joint needs real torque, that is a signal to machine the mating part rather than print it.

Layer height and nozzle size matter less than most people expect. A 0.4 mm nozzle at 0.2 mm layers is the safe default. Larger nozzles speed up soft grades but reduce the resolution of thin walls, which is where flexibility is controlled.

• 1
  Walls over infill1.2–2.4 mm shell sets stiffness; infill adds little
• 2
  Keep overhangs shallowPast roughly 45 degrees, soft filament sags
• 3
  No printed threadsUse inserts, captured nuts, or bolt through with washers

Filament grinding at the extruder with no extrusion usually means back pressure, not a bad spool. Check for a partial nozzle clog, then check whether the drive gear tension is crushing the filament. Soft TPU deforms under too much idler pressure and loses grip.

Stringing between towers points at retraction and travel. Lower retraction distance, raise travel speed, and enable coasting so the nozzle stops extruding slightly before the end of a path. If strings persist, drop nozzle temperature by 5 °C at a time until layer bonding starts to suffer.

Delamination between layers is almost always temperature or speed. TPU needs enough heat to bond to the layer below, and running fast with a 0.6 mm nozzle chills the bond before it forms. Slow down, raise nozzle temperature by 5 °C, and increase extrusion width slightly.

Wet filament shows up as popping sounds, a rough surface, and inconsistent extrusion. TPU absorbs moisture faster than PLA. Dry it at 45–50 °C for 4–6 hours, print from a dry box, and keep desiccant in the storage container between jobs.

• 1
  GrindingBack pressure or excessive idler tension, not a bad spool
• 2
  StringingReduce retraction, add coasting, drop 5 °C at a time
• 3
  PoppingMoisture, dry 4–6 hours at 45–50 °C

TPU is not a precision material. Thermal shrink, soft walls, and nozzle pressure variation push realistic tolerances to around ±0.3 mm on a well-tuned printer. A bore that must hold a bearing, a face that must seal against a machined flange, or a thread that must take torque all belong on a mill.

Long-term compression is another limit. Under constant load, TPU creeps and takes a set. A gasket that seals perfectly on day one may leak after six months of squeeze. Cast or molded urethane handles compression set far better because the chemistry and the cure are controlled.

Chemical exposure matters too. TPU resists oils and many solvents, but strong acids, ketones, and hot water degrade it. Check the grade data sheet against the actual fluid, temperature, and dwell time before you commit a production run.

For prototypes, flexible printing is fast and cheap. For a hundred units that must fit a machined housing, the smarter path is often to print the flexible part for fit checks, then machine the rigid mating parts to ±0.005 mm on our mills and confirm the assembly before tooling.

We run both processes. Send a model and we will tell you which one holds the tolerance your drawing calls for, with a DFM note back within 12 hours.

• 1
  Tolerance floorRoughly ±0.3 mm, not a substitute for a bored fit
• 2
  Compression setConstant load causes creep; molded urethane holds better
• 3
  Fluid checkVerify acids, ketones, and hot water against the data sheet
