Tooling Selection Guide

CNC Milling Cutters: A Complete Selection Guide

Five common CNC milling cutters, what each one is good at, and how to pick the right geometry for your part. Written for engineers and buyers who need to judge a toolpath before the chips fly.

±0.005 mm toleranceRa 0.2–0.8 μm finishNo MOQ16 five-axis centers
CNC milling cutters selection guide for end mills and face mills
Quick answer

Key takeaways

Most parts need three toolsA face mill for flats, an end mill for walls and pockets, a drill or slot drill for holes.
Geometry beats coatingHelix angle, flute count (2–6) and corner radius change chatter and finish more than any coating.
Rough and finish are different jobsRough with a 3- or 4-flute cutter at high feed, then finish with a 6-flute or ball nose.
Tool runout sets your tolerance0.01 mm of runout can add more error than machine positioning ever will.
The machine sets the ceilingA 4,000 mm part needs a machine with matching travel, not a longer cutter.
At a glance

CNC milling cutters compared

Match the cutter to the feature, not the other way around.

CutterBest featureTypical flute countWatch out for
Square end millWalls, pockets, shoulders2–6Long length-to-diameter ratios chatter
Ball nose3D contours, radii, molds2–4Slow on flat floors, leaves cusps
Face millLarge flat top surfacesInsert count variesNeeds rigid setup and enough spindle power
Slot drillBlind holes, keyways2 or 3Feeds straight down, poor for deep pockets
T-slot cutterUndercuts, T-slots, dovetailsVariesNeck strength limits depth of cut
Roughing end millBulk metal removal3–5Leaves scalloped walls, always finish after
Buyer checks

Supplier selection: what to verify

Ask for these before you release a purchase order.

CriterionWhat to askWhy it matters
Tolerance capabilityCan you hold ±0.005 mm on this feature?A general ±0.05 mm shop cannot meet a tight bore
Surface finishWhich Ra band applies to each face?Ra 0.2–0.8 μm costs more than as-machined
InspectionDo you inspect 100% before shipment?Reports on request, not after the fact
CertificationsISO 9001, IATF 16949, ISO 13485, ISO 27001?Automotive, medical and data handling differ
Order quantityAny minimum order quantity?One prototype should be acceptable
Quote turnaroundHow fast is a quote with DFM feedback?Design fixes found early save a rebuild
How they cut

What CNC milling cutters actually do to metal

Every CNC milling cutters removes material by rotating a multi-tooth edge against the workpiece while the table or spindle feeds. Two things decide the result: how many teeth touch the metal at once, and how far each tooth travels per revolution. Feed per tooth, not feed per minute, is the number worth setting.

Aluminum likes high surface speed and generous chip clearance, so a 2- or 3-flute cutter with a 45° helix works well on pockets where chips have to escape fast. Steel and stainless generate more heat at the edge, so a 4- to 6-flute cutter spreads the load and keeps the tooth in cut for a shorter arc.

Flute count is a trade. More flutes means more teeth in contact, a smoother surface and higher feed rate, but less room for chips. On deep pockets in soft material, too many flutes pack the flutes and the cutter rubs instead of cutting.

The corner geometry matters as much as the flute count. A sharp corner concentrates stress and snaps small cutters; a 0.5–1.0 mm corner radius on a finishing tool costs nothing in part function and adds real tool life.

  • 1
    Feed per toothSet this first; 0.02–0.05 mm per tooth is a common starting band for aluminum.
  • 2
    Radial engagementKeep it under 5% of cutter diameter on deep side milling to control deflection.
  • 3
    Axial depthUp to 1× diameter is normal for a rigid 4-flute cutter in steel.
Tool by tool

End mill, face mill, and slot drill: when each one fits

The square end mill is the default. It cuts on the end and the side, so it can ramp into a pocket, walk a contour and square a shoulder in one setup. For a bracket with pockets and bolt holes, a 6 mm or 10 mm 3-flute carbide end mill handles most of the part.

The face mill is built for area, not detail. A body holding several indexable inserts sweeps a wide flat surface in one pass. Use it when flatness and finish on a large face matter more than cycle time on small features. It needs a rigid machine and enough spindle power.

A slot drill cuts straight down and plunges, which makes it the right tool for blind holes and keyways that a twist drill cannot size accurately. It is a poor choice for deep pockets because the center teeth do not clear chips well.

Ball nose cutters finish 3D surfaces. On a mold or a curved housing, a 6 mm ball nose at 0.2 mm stepover gives a predictable cusp height. The trade is time: stepover and surface finish are tied together, so a finer finish always costs cycle time.

Material and machine

Matching cutters to material and machine travel

Material drives coating and geometry. Uncoated or ZrN-coated carbide in 6061 and 7075 aluminum cuts clean at high speed. Stainless 304, 316L and 17-4PH work better with AlTiN-coated tools, lower surface speed and a heavier feed to get under the work-hardened layer.

Titanium TC4 (Ti-6Al-4V) and Inconel punish heat. Use sharp edges, generous coolant or high-pressure through-spindle coolant, and accept lower cutting speeds. Tool life, not cycle time, becomes the controlling cost. Replacing a cutter mid-run is worse than a slower pass.

Machine travel sets what is possible. Our largest travel is 4,000 × 400 × 150 mm, and the medium class runs 750 × 1,150 × 550 mm or 600 × 600 × 600 mm. If a feature sits beyond the travel, no cutter geometry will reach it; the part needs a different setup or a bigger machine.

Five-axis motion changes cutter behavior. Tilting the tool lets a ball nose use its effective radius instead of its tip, which raises surface speed at the contact point and improves finish. It also lets a short, stiff cutter reach a deep wall that a long tool would chatter on.

Process

How we select and run CNC milling cutters

The sequence we follow on a new part, from drawing to first article.

  • 1
    1. Read the feature listSplit the part into flats, walls, pockets, holes and free-form surfaces. Each group gets its own cutter family before any CAM work starts.
  • 2
    2. Check reach and stiffnessCompare feature depth against cutter diameter. Keep the length-to-diameter ratio under 4:1 where possible; above that, plan a tilted five-axis pass or a smaller stepdown.
  • 3
    3. Pick the roughing toolUse a 3- to 5-flute roughing cutter at 0.5–1.0× diameter axial depth, leaving 0.3–0.5 mm of stock for finishing.
  • 4
    4. Pick the finishing toolChoose flute count and corner radius for the finish band. For Ra 0.8–1.6 μm on steel, a 6-flute cutter with a 0.4 mm corner radius is a solid start.
  • 5
    5. Set speed and feed by materialStart from surface speed, convert to rpm, then set feed per tooth. Adjust after the first cut by listening for chatter and reading the chip color.
  • 6
    6. Control runout before cuttingIndicate every tool in the holder. Keep runout under 0.01 mm; a worn collet is a common cause of oversize holes and poor finish.
  • 7
    7. Inspect the first articleMeasure the tightest feature first. If the cutter is pushing or rubbing, the error shows up there before anywhere else.
FAQs

Common questions

How many flutes should I use on aluminum?

Two or three flutes for pockets and slots where chips must clear quickly. Move to four or more when the cut is shallow and you want a higher feed rate and a smoother wall.

The limit is chip evacuation, not the material itself.

Can a ball nose cutter face a flat surface?

It can, but it is inefficient. The tip has almost no surface speed, so the center of the tool rubs and the finish is dull.

Use a square or bull nose cutter for flats, and keep the ball nose for curves and radii.

When is a slot drill better than an end mill?

For blind holes and keyways where the depth and diameter both matter. A slot drill plunges straight and cuts to size.

For deep pockets, a standard end mill with a helix clears chips better.

What tolerance can milling hold without grinding?

We hold ±0.005 mm on features that suit the process, and ±0.0002 in in imperial terms. That depends on feature geometry and material, not on the cutter alone.

Tight bores and thin walls are where the limit shows first.

Do I need to specify coatings on the drawing?

No. Tell us the material and the finish band you need. Coating choice follows from those two, and it is our call as the shop.

Specifying a coating by name can lock out a better option.

What is the smallest order you accept?

No minimum order quantity. We run from one prototype to production runs above 10,000 parts.

The cutter selection process is the same either way.
