A CNC cutting machine removes material by moving a controlled tool along a path that a program defines. The controller reads G-code, converts each line into axis motion, and closes a position loop on the servo motor. Cutting itself is only one part of the loop. Position feedback, spindle load and thermal growth all decide whether the finished wall lands where your drawing says it should.

Two families cover most work. Subtractive machines cut with a rotating tool, a laser beam, a plasma arc or a water jet. Thermal and abrasive methods separate material without touching it, so they leave a heat-affected zone or a tapered edge. That difference matters later, when you inspect the part.

The useful split is not machine brand or price. It is whether the process pushes a hard edge through the material or burns and melts it away. Push methods hold a tight wall thickness. Burn methods are fast on plate but move the metallurgy near the cut.

• 1
  Contact cuttingEnd mills, drills, taps and turning tools cut by shear and chip formation.
• 2
  Thermal cuttingLaser, plasma and oxy-fuel melt or oxidize metal along a path.
• 3
  Abrasive cuttingWater jet and abrasive sawing erode material with no heat input.

Milling with a carbide end mill is the default for pockets, slots and profiles. A 3-axis machine handles prismatic work; a 4-axis or 5-axis machine reaches undercuts and angled faces in one setup. On our 5-axis centers we hold ±0.005 mm on critical bores, with a floor finish around Ra 0.8–1.6 μm before any polishing step.

Turning cuts round parts with a single-point tool. A mill-turn center combines both motions, so a shaft with flats and cross-holes comes off one machine. Fewer setups means fewer datum shifts, and datum shifts are where most tolerance stacks go wrong.

Laser cutting separates sheet up to roughly 20 mm in mild steel, faster than milling and with a narrow kerf. The cut edge carries a heat-affected zone of a few tenths of a millimeter, and the corner radii cannot go below the beam width. If the edge will be welded or painted, that is fine. If it is a sealing face, plan a finishing pass.

Water jet cuts almost any material with no heat, which suits titanium, thick aluminium plate and composites. It is slower, the kerf tapers slightly through the thickness, and abrasive cost scales with part perimeter. Plasma sits between laser and water jet on cost and edge quality, and it leaves a rougher, oxidized face that usually needs secondary machining.

• 1
  Best edge qualityMilling and turning, followed by grinding or polishing when needed.
• 2
  Best on thin sheetLaser, with a kerf narrow enough for fine features.
• 3
  Best on thick or heat-sensitive stockWater jet, because the part stays cold and flat.

The base and column set the stiffness. Cast iron dampens vibration better than welded steel, and vibration shows up as chatter marks on the wall. A machine that rings during a heavy cut will not hold tolerance on a thin web, no matter how the program is written.

Linear guides and ball screws turn motor rotation into straight motion. Preload removes backlash, so reversing direction does not lose position. On older machines backlash appears as a step on a bored face after a tool change, which is why we check backlash during setup rather than after the first part is scrapped.

The spindle is the cutting interface. Its runout, taper condition and thermal drift all transfer into the part. A spindle that grows 20 μm over a long roughing cycle will pull a bore off size, so we warm up spindles and keep roughing and finishing in separate passes.

Feedback closes the loop. Glass scales read the axis directly, while encoders read the motor. Scales cost more and catch screw wear, which is why precision work tends to use them. Our tolerance floor of ±0.005 mm only holds when the machine, the fixture and the tool are all in good condition at the same time.

Tolerance describes how far a dimension may drift. A ±0.005 mm callout on a 200 mm aluminium part is achievable but expensive, because it requires a stable machine, a light finishing pass and temperature control. The same measurement on a 4,000 mm part is a different problem: thermal expansion alone can move the number more than the tolerance band.

Surface finish is measured as Ra, the average roughness. As-machined faces sit around Ra 1.6–3.2 μm. A finishing pass with a sharp tool and light feed gets into Ra 0.8–1.6 μm, and fine finishing with a small stepover reaches Ra 0.2–0.8 μm. Finish is not decoration; it controls friction, fatigue life and how well a seal holds.

The tool edge sets the floor. A worn insert rubs instead of cutting, raising heat and pushing material sideways. That shows up as a burr on an otherwise clean edge. We track tool life by material and feature, and change inserts before the finish drifts out of the print.

Sharp internal corners need care. A milling cutter leaves the radius of its own corner, so a true square corner requires a broach, EDM or a relief cut. Drawing a zero-radius corner on a milled pocket is the most common note we send back during DFM review.

Milling a 0.5 mm wide slot 20 mm deep is possible in theory and painful in practice. The tool is thin, it deflects, and it breaks. The usual fix is a wider slot, a shallower depth, or a different process such as wire EDM or laser.

Laser cutting loses accuracy as thickness grows. On 20 mm steel the kerf widens and the edge squares up less, so a part that must fit a tight assembly may need the cut faces milled after cutting. Deep, narrow slots also trap the beam, and the assist gas cannot clear the kerf.

Water jet cannot hold a sharp corner as tightly as milling, and it tapers. On a 50 mm section the taper may reach a few tenths of a millimeter top to bottom. For a bracket that is fine. For a matched pair that must seal, it is not.

Long, thin parts bend. A 1,000 mm shaft with a small diameter will flex under cutting force and relax after the clamps come off. Support it along its length, take light passes, and rough then finish. Titanium and Inconel add another limit: they work-harden, so a dull tool rubs instead of cutting and the next pass gets harder.
