Additive manufacturing changed what an implant can look like. A porous lattice that mimics trabecular bone, a channel that follows a patient's own anatomy, a stiffness gradient that softer bone can live with — powder-bed fusion handles all three. What it does not handle well is a precise mating surface. As-built laser powder-bed parts typically land around Ra 8–20 μm with form deviation that grows with part height.

That gap matters wherever the implant connects to something else. A stem press-fits into a reamed canal. A locking taper seats against a mating cone. A screw thread takes torque every time the part is serviced. Those features are cut after printing, on a CNC, from a printed near-net blank that already carries the porous structure.

The practical framing is simple. Printing buys geometry freedom. Machining buys fit. Programs that treat the two as competing routes usually end up reprinting parts; programs that treat them as sequential steps hit tolerance on the first pass.

For a typical titanium acetabular shell, the printed blank arrives with the lattice intact and the rim left with 0.4–0.6 mm of stock. A 5-axis cycle then cuts the rim flat, opens the taper bore and drills the screw holes. Cutting a printed blank is not the same as cutting bar stock — the part is light, springy and full of internal porosity, so fixturing and light radial passes matter more than spindle speed.

• 1
  Print near-net, leave stock0.3–0.8 mm on any surface that will be cut later.
• 2
  Machine only the interfacesTapers, bores, threads, sealing faces and datum surfaces.
• 3
  Keep the lattice untouchedCutting into a porous region destroys its designed pore size.

Patient-matched plates start from a CT or MRI scan, get segmented into a 3D model, and are printed in TC4 (Ti-6Al-4V) with a contoured underside that follows the bone surface. The printed side faces the bone. The side facing the soft tissue is usually machined flat or given a defined radius so it does not irritate anything.

The critical machined features are the screw holes, the plate thickness and the screw-hole countersinks. Hole position tolerance of ±0.1 mm is normal; hole diameter usually runs at ±0.05 mm so the screw seats without play. Countersink angle and depth control how the screw head sits, which affects load transfer into the plate.

Titanium is not a friendly material to cut. It work-hardens, conducts heat poorly and will grab a dull tool. Roughing runs at conservative depths, finishing runs with sharp carbide and high-pressure coolant. On a printed blank, the same rules apply, plus one more: the blank is thin in places and can deflect, so support it from the porous side with a contoured soft jaw rather than a flat vise.

Machining a patient-matched plate is a one-off job by definition. There is no batch to amortize setup across. That is exactly the case where a shop with no minimum order quantity and same-day production start makes the difference between a two-week and a four-week turnaround.

• 1
  Screw hole position±0.1 mm typical, referenced to the bone-contact datum.
• 2
  Hole diameter±0.05 mm so the screw threads engage cleanly.
• 3
  Plate thicknessHeld to ±0.1 mm to keep stiffness predictable.

PEEK cages are printed or molded near-net, then finished to final geometry. The reason engineers pick PEEK over titanium in the spine is modulus: PEEK sits close to cortical bone, so it does not shield the graft from load. It is also radio-transparent, which keeps the fusion site visible on follow-up imaging.

The machining challenge is different from titanium. PEEK is soft, has a low melting point and cuts cleanly only with sharp, polished tooling and generous chip clearance. Heat is the enemy — a dull tool smears the surface instead of cutting it and leaves a finish that will not pass inspection. Feeds run high, depth of cut runs moderate, coolant runs on the generous side.

Locking features are where the tolerance lives. A cage that snaps into an inserter needs a rail or slot held to ±0.05 mm across its width, or the instrument will not release. Screw holes for integrated fixation need a clean thread with no burr, because a burr left in the thread blocks the screw at the moment of insertion.

Dimensional stability after machining matters too. PEEK relaxes slightly after material is removed, so a cage measured hot off the machine can drift a few microns by the time it is inspected. Shops that run medical PEEK usually let parts stabilize before final inspection rather than measuring immediately.

• 1
  Inserter rail width±0.05 mm so the instrument engages and releases.
• 2
  Thread qualityNo burr, no smeared flank; go/no-go gauge check.
• 3
  Surface finishRa 0.8–1.6 μm on load-bearing faces.

Cranial and facial implants are the clearest case for printing, because the geometry is the function. A patient-specific skull patch has to match a defect edge that follows a fracture line. A mandibular reconstruction plate has to clear the nerve canal and still carry bite load. Neither shape is reachable with a milling cutter alone.

These parts are usually printed in titanium with a solid rim and a porous or perforated interior. The rim is machined — flattened, drilled for fixation screws, and given a defined edge break so no sharp corner sits against soft tissue. Pore size in the interior is set by the printing process and is not touched afterward.

The machining work is small in volume and high in consequence. Fixation holes are typically Ø1.5–2.0 mm, positioned to ±0.1 mm, with a 0.2–0.3 mm edge break. A hole that drifts off position puts the screw into a thin section of bone. A burr left inside a hole becomes a site for tissue irritation.

Because the parts are thin and curved, they are hard to hold. Vacuum fixturing or a machined negative-form nest works better than clamps. Clamping force on a 1.5 mm titanium sheet will bend it, and a bent patch will not sit flush against the defect edge during surgery.

• 1
  Fixation holesØ1.5–2.0 mm, position ±0.1 mm.
• 2
  Edge break0.2–0.3 mm on every rim and hole entry.
• 3
  FixturingVacuum or form nest; avoid point clamps on thin walls.

Every printed implant program needs a matching set of metal tools: drill guides, trial sizes, impactors, inserter tips. These parts are not implanted, so the material rules relax. They are still tolerance-critical, because a drill guide that sits 0.2 mm off sends the drill into the wrong place.

Drill guides are usually machined from 316L stainless or 17-4PH (SUS630). Both machine well and hold up to repeated autoclave cycles. The bushing bore is the key feature, often held to ±0.02 mm with a honed or reamed finish, because the drill rides directly in it. A rough bore wears the guide out in a few cases.

Trials are the opposite problem. They need to feel like the real implant in the surgeon's hand, so surface finish and weight matter as much as dimension. Aluminum 6061 or 7075 is common for trials that never enter the body; 316L is used when the trial is also a trial implant.

The value of building the tooling alongside the implant is fit. If both come off the same drawing revision and the same inspection plan, the guide matches the hole pattern and the trial matches the final part. Splitting them across vendors is how mismatch shows up in the OR.

• 1
  Bushing bore±0.02 mm, reamed or honed.
• 2
  Guide material316L or 17-4PH for autoclave durability.
• 3
  Trial materialAluminum 6061/7075 when it stays outside the body.

Powered prosthetic hands, wrists and feet are a different category: the printed parts are structural housings rather than implanted devices, but the fit tolerances are tighter than most industrial work. A finger linkage that runs 0.05 mm loose will rattle. A gearbox housing that runs 0.05 mm tight will bind.

The common build is a printed shell — often carbon-fiber-reinforced nylon or a printed metal frame — with machined inserts, bearing seats and pivot bores. Bearing seats are the tightest feature: a bore for a 6 mm bearing typically runs at ±0.01 mm with a fine finish, or the bearing will spin in the housing instead of on the shaft.

These assemblies also need to survive real use. A prosthetic hand takes thousands of cycles per day. Pivot pins should be hardened steel or 17-4PH, and their mating bores should be reamed rather than drilled, because drilling leaves a lobed hole that wears the pin.

Weight is the other constraint that shapes the design. Every gram at the end of a limb costs the user energy, so housings get thin walls and lightening pockets. Thin walls are exactly what makes machining hard: the part moves under cutting force, and a spring pass is often needed to bring a bore back to size.

• 1
  Bearing seat±0.01 mm with Ra 0.2–0.8 μm.
• 2
  Pivot boreReamed, not drilled, for roundness.
• 3
  Spring passOne light finishing pass to control wall deflection.
