Most bad purchases are decided before the buyer ever stands in front of the machine. Ask for the machine serial number, the control model and the year of manufacture first. With those three items you can call the builder or an independent service house and confirm whether the control is still supported. That single phone call filters out more risk than any visual inspection.

Bring a small kit: a 0.002 mm dial indicator with magnetic base, a 50 mm test bar, a digital level, a flashlight, a USB stick and a notebook. You are not there to admire paint. You are there to collect numbers you can compare against a specification sheet later.

Ask the seller to run the machine for at least 30 minutes before you arrive, not when you arrive. A cold lathe hides thermal drift. A spindle that has run for half an hour will show its real behavior on a warm test cut.

Get the maintenance history in writing if it exists. Filter changes, ball screw replacement, spindle rebuild and turret service records tell you how the machine was treated. No records is not automatically a rejection, but it changes how hard you should test.

• 1
  Serial number firstIt confirms year, control generation and original configuration.
• 2
  Parameter backupAsk for a USB or paper copy of the machine parameters before you pay.
• 3
  Written historyService records are more useful than a verbal account.

Start with the bed and the guideways. On a linear guide machine, look for flaking or dark scoring on the rail surfaces and run a finger along the carriage travel. On a box way machine, check the turcite or the way wipers for embedded chips. Worn wipers mean grit has been riding the ways, and that shows up as taper in long turning work.

Set the digital level on the bed in both directions. A lathe that has been sitting on a bad floor for years can twist. Twist of more than 0.02 mm per meter across the bed is worth correcting before you judge any cut, because leveling changes the geometry you are about to measure.

Align the tailstock with a test bar between centers. Sweep the indicator along the bar at three positions. A tailstock that is off by more than 0.02 mm over 300 mm will make shaft work painful and will need shimming or scraping.

Check the spindle nose for fretting or a spun chuck. Blue or black marks around the camlock studs or the A2 spindle taper are signs of a chuck that has been loose under load. That is a spindle repair, not a cleaning job.

Indicate the spindle taper directly, not the chuck jaws. A good used spindle should show 0.005 mm or less of TIR on the taper. If the chuck is mounted, remove it or indicate a known good test bar in the taper. Chuck jaw runout tells you about the chuck, not the spindle.

Run the spindle at 25%, 50% and 100% of its rated maximum for five minutes each. Listen at each step and record the vibration. A bearing that is on its way out will show a rising noise band and a temperature climb at the front bearing housing. Infrared readings above 45 °C at the housing after a 30 minute run deserve a second look.

Check axial and radial play with a bar loaded by hand. Push and pull with about 200 N and read the indicator. More than 0.01 mm of axial movement usually means preload loss or a worn bearing set. Preload can sometimes be reset, but on a sealed spindle cartridge it is a rebuild.

If the machine has a sub-spindle or a bar feeder interface, test the synchronization with a short program. A sub-spindle that drifts during transfer will scrap parts at the cutoff, and that fault is often a parameter or encoder issue rather than a mechanical one.

Backlash is the number that decides whether the lathe can hold a tolerance on a turned diameter. Mount the indicator against the turret or the cross slide, jog the axis in 0.01 mm steps in one direction, then reverse. Read the lost motion. For most general turning work, 0.01 mm or less per axis is acceptable. Above 0.02 mm you are looking at ball screw or thrust bearing work.

Do not judge backlash from a single point. Test at three positions along each axis: near the chuck, mid travel and near the end of travel. Wear is rarely uniform, and the worst point is the number that matters.

Run a repeatability test: program 20 rapid moves to the same position and back, then indicate the final position. A spread of more than 0.005 mm points to a loose encoder coupling, a dirty scale or a thrust bearing that is moving under load.

Listen during rapid moves. A growl or knock at reversal can be a dry linear guide or a loose bearing locknut. Both are fixable, but they change your offer. On a lathe with a C axis or live tooling, also check the C axis indexing repeatability, since that drives cross-drilling and milling accuracy.

Index the turret through every station ten times and indicate a test bar in a known holder. Repeatability should be within 0.005 mm. If one station is off but the others are good, the issue is usually a worn station or a bent toolholder. If all stations drift, the turret coupling or the index motor is the problem.

Check the turret for crash damage. Look at the tool disc face for runout, the coupling teeth for bruising and the housing for weld repairs. A welded turret housing is a strong reason to walk away, because alignment after welding is rarely stable under cutting load.

On the control side, power up from cold and watch for alarms. Ask to see the alarm history and the parameter page. Then ask the important question: can this control still be repaired? Fanuc, Siemens, Mitsubishi and Okuma have different support windows. Older controls may still run, but if a drive board fails and no exchange unit exists, the machine becomes a parts donor.

Check the battery in the control cabinet and the absolute encoder backup. A dead encoder battery during transport can wipe the zero point, and re-homing a lathe without a reference mark is a slow job. Ask the seller to replace it before rigging.

A test cut turns every measurement into a result. Bring a piece of 1045 or 6061 bar stock of known diameter and a simple program that turns, faces, drills and threads. Keep the depth of cut moderate: 1.5 mm per side in steel at a feed of 0.2 mm per revolution is enough to expose a weak machine without risking a crash.

Measure the turned diameter at three points along the length. Taper over 200 mm should stay inside 0.02 mm on a healthy machine. Then measure roundness with a micrometer at 0°, 90° and 180°. A lobed result points to spindle or chuck issues rather than axis calibration.

Cut a thread and check it with a ring gauge or thread wires. Pitch errors on a used lathe usually trace back to the Z axis encoder or the spindle encoder synchronization, and that is a control-level fix rather than a mechanical one.

Record surface finish. On a machine in reasonable condition you should see Ra 1.6–3.2 μm as-machined on steel. If the finish is torn or chatter-marked, check the toolholder, the turret clamp and the spindle bearings in that order before blaming the control.
