San Antonio CNC Machine Service: What to Check Before You Order

• 1
  Key takeaways
• 2
  What Actually Decides a Supplier Award
• 3
  Tolerance: Ask for the Number, Not the Adjective
• 4
  Surface Finish: Know Which Operation Produces It
• 5
  Machine Mix and the 4,000 mm Envelope
• 6
  Lead Time: Separate Quoting From Cutting
• 7
  Order Quantity, Certifications and Quoting Discipline
• 8
  Seven Steps to Qualify a Supplier

Every supplier claims accuracy. Few put a figure on it in the first reply. When you evaluate a San Antonio CNC machine service, ask for the tightest tolerance they hold on a production basis, not the tightest they have ever held once on a lab bench. A real answer looks like ±0.005 mm, or ±0.0002 in, and it usually comes with a caveat about part size and material.

Tolerance is not free. Going from ±0.05 mm to ±0.005 mm changes fixturing, tooling, temperature control and inspection time. On a 6061-T6 bracket, that jump may add a second op. On a 17-4PH shaft, it can add a stress-relief step between roughing and finishing. If your print does not need it, do not buy it.

The datum scheme matters more than the number. A part with three datums spread across two setups will drift, no matter how good the machine is. If your drawing forces that, expect the supplier to quote a fixture, and expect the first article to take longer than the run.

Ask one more question: how do they verify it? A stated tolerance without a stated method is a guess. Coordinate measuring machines, optical comparators and height gauges all cover different geometries. For a bore pattern, you want CMM data. For a shaft diameter, a micrometer log is fine.

• 1
  Put the tolerance on the drawingNot in the email. The shop quotes the drawing.
• 2
  Name the featureA single tight feature costs less than a tight envelope.
• 3
  Ask for the methodTolerance plus inspection method equals a real answer.

Surface finish gets quoted as one line and delivered as three. As-machined aluminum typically lands at Ra 1.6–3.2 μm. A good finishing pass gets you to Ra 0.8–1.6 μm. Below that, Ra 0.2–0.8 μm, you are usually buying a second operation: lapping, polishing or a controlled fine pass with a small stepover.

The material sets the ceiling. Aluminum 6061 and 7075 polish well and respond to bead blasting. Stainless 316L work-hardens, so a light finishing pass can smear instead of cut. Titanium TC4 (Ti-6Al-4V) needs sharp tooling and generous coolant or the finish degrades fast. Inconel is slower still and will push both cost and lead time.

Finish also interacts with coatings. Anodizing, hardcoat and electroless nickel all build thickness and can round a sharp edge. If a sealing surface needs Ra 0.8–1.6 μm after plating, say so on the print. Otherwise the plater will follow the drawing and finish to the pre-plate callout.

Laser marking has its own limit: minimum character height 1.5 mm. Smaller text may not be legible after anodizing, especially on dark hardcoat. Move the mark to a machined flat face if traceability matters.

• 1
  State finish after platingOtherwise the pre-plate callout governs.
• 2
  Watch sharp edgesCoatings round them; specify a chamfer.
• 3
  Bead blasting hides tool marksIt does not fix a dimension.

A shop with 127 high-precision CNC machines sounds capable. Capability depends on the mix. Simultaneous 5-axis centers cut complex geometry in one setup. Mill-turn centers finish a shaft with a cross-hole without a second fixture. Three-axis machines handle flat plates and simple pockets at the lowest hourly rate.

Ask how your part maps onto that mix. If your housing has features on five faces, a 5-axis center removes four setups, four fixture errors and four chances to scrap. If your part is a flat plate with a bolt pattern, a 3-axis machine is cheaper and just as accurate. Paying 5-axis rates for 3-axis work is the most common overspend in this category.

Size decides the rest. A 4,000 mm maximum processing size with a 4,000 × 400 × 150 mm travel covers long extrusions and rails. Mid-size work sits in the 750 × 1,150 × 550 mm and 600 × 600 × 600 mm ranges. Small parts run on 500 × 500 × 450 mm or 500 × 310 × 200 mm tables, sometimes with a Ø400 mm rotary table for round features.

If your part is longer than the envelope, the supplier will either turn it down or quote a splice. Ask early. A late answer on size is the most expensive kind.

• 1
  Five faces, one setupThat is the 5-axis case.
• 2
  Shaft with cross-holesMill-turn removes a fixture.
• 3
  Long railCheck the 4,000 mm envelope first.

Lead time quotes are vague because suppliers blend two clocks. Clock one is quoting and DFM analysis, which can run within 12 hours of receiving a drawing. Clock two is cutting, which can start within 24 hours once the drawing and material are frozen. Parts then ship in 3–5 days for straightforward work.

Ask which clock you are on. A supplier who says "two weeks" may mean four days of cutting plus ten days of waiting for your revised STEP file. A supplier who says "quote today, chips tomorrow" is telling you the DFM note is coming back with the quote. Read that note. It usually flags a thin wall, an unreachable corner or a tolerance that will not survive the fixture.

Material drives the second clock more than machining does. 6061 and 303 stainless are usually on the shelf. Inconel, Ti-6Al-4V and beryllium copper often are not. Ask whether the quote assumes stock on hand or a mill order.

Late delivery risk is a real number, not a slogan. A shop tracking historical late-delivery probability below 2% is measuring itself. Ask what they measure and over what window. An unmeasured shop has no idea what its on-time rate is.

• 1
  Freeze the drawingThe cutting clock starts there, not at the RFQ.
• 2
  Ask about stockExotic alloys change the date.
• 3
  Request the DFM noteIt is where problems surface early.

Minimum order quantity is a gate that stops small programs. No minimum order quantity means one prototype and a 10,000+ part run sit on the same purchase order form. For San Antonio teams building a first article, that matters more than the hourly rate. A shop that will not run one piece will not run your prototype.

Certifications must match the industry you sell into. ISO 9001:2015 is the baseline. Automotive work needs IATF 16949:2016, and medical device work needs ISO 13485:2016. If your data leaves your building, ISO 27001:2022 covers information security. Ask for the current certificate and check the scope line, not just the logo.

Inspection is the last gate. 100% inspection before shipment, with raw material check, in-process monitoring and final inspection, is a different promise than sample inspection. Reports are available on request, so ask for the CMM report on the features that matter, not the whole drawing.

Quoting discipline shows up in the reply itself. A useful quote names the material grade, the machine, the finish, the inspection level and the lead time. A quote that lists only a price and a total is a placeholder.

• 1
  One piece is the testIf they refuse it, they are not your prototype shop.
• 2
  Read the certificate scopeA logo without a scope proves nothing.
• 3
  Ask for the CMM reportOn critical features only.
