Titanium has roughly one-third the thermal conductivity of steel. Heat generated at the shear zone cannot escape into the chip or the workpiece fast enough, so the cutting edge absorbs it. Edge temperature climbs, and the tool fails long before the spindle runs out of torque.

The second effect is chemical. Fresh titanium surfaces are reactive. At around 500 °C and above, the metal starts pulling atoms out of the tool coating, and chips begin to weld to the flank. A cutter that survived steel for hours can fail in titanium within minutes.

There is a third factor that surprises people. Titanium keeps about half its strength at 400–500 °C, where most steels have already softened. The chip stays stiff and springy, so it rubs instead of shearing cleanly. That rubbing feeds more heat back into the edge.

Put the three together and the rule falls out: you cannot out-force titanium. You manage the heat. Every parameter choice below is really a heat decision.

Carbide is the baseline for precision titanium CNC machining. Uncoated micrograin grades work well for finishing because there is no coating layer to react with the chip. For roughing, AlTiN or AlCrN coatings hold up better, provided the edge stays sharp, since a dull coated tool accelerates the same chemical wear.

Surface speed is where most setups go wrong. A practical band for Ti-6Al-4V with carbide is 30–60 m/min. Going faster raises edge temperature faster than it raises removal rate, and tool life drops off a cliff rather than a slope. On small-diameter end mills, drop to the low end.

Feed per tooth matters more than spindle speed. Keep it high enough to form a real chip, typically 0.05–0.15 mm per tooth on a 10–12 mm cutter. Too light a chip lets the tool rub, and rubbing is the fastest way to burn an edge.

Coolant is not optional. High-pressure through-spindle coolant at 50–70 bar evacuates chips and pulls heat out of the zone. Flood coolant works on open cuts but struggles in pockets and deep slots, which is exactly where titanium parts tend to have their hardest features.

Thin walls are the classic titanium problem. Below about 1 mm wall thickness, cutting forces push the wall away from the tool, the tool rubs, and the wall springs back. The result is chatter and a wall that measures differently at every point. Ribs and pockets with generous radii behave far better than square internal corners.

Deep holes are workable if you plan the cycle. A depth-to-diameter ratio beyond 5:1 calls for peck drilling or helical milling with through-coolant, plus a reaming pass if the hole carries a tolerance. Gun drilling is worth the setup when you have many holes at 10:1 or deeper.

Surface finish depends on tool path as much as on the cutter. A constant-engagement path keeps radial depth steady, which keeps the chip load steady and the temperature steady. That is the practical reason a five-axis setup often produces a better titanium finish than three axes on the same part.

Very sharp internal corners with no radius are the feature to avoid. They concentrate stress in service and force a small cutter into the cut, so the tool deflects. Add a corner radius, even 0.5 mm, and both the machining and the part improve.

Commercially pure grades TA1 and TA2 (Grade 1 and 2) are soft, formable and easy to cut. They suit chemical hardware, brackets and parts that need corrosion resistance more than strength. Tool life here is closer to stainless than to alloy titanium.

Ti-6Al-4V, also called TC4 or Grade 5, is the workhorse and the grade most drawings specify. It is roughly twice as strong as pure titanium and noticeably harder to machine. Expect more tool changes, slower removal rates and a stiffer setup than the same part in 316 stainless.

Ti-6Al-4V ELI, or Grade 23, is the same alloy with tighter limits on oxygen and iron. Medical implants use it because the lower interstitial content improves fracture toughness and fatigue behavior. Machining behavior is close to Grade 5.

Grade 9, Ti-3Al-2.5V, sits between pure titanium and Grade 5. It is common in tubing and hydraulic lines. It machines more easily than Grade 5 while offering better strength than the pure grades, which makes it a reasonable compromise when a drawing is still open.

We machine the whole family, including TA1, TA2, TC4, Inconel and magnesium alloys, so the grade choice can be settled against real cycle data rather than a handbook table.

A general machining tolerance of ±0.005 mm is achievable on precision titanium parts, but it does not apply to every dimension on the drawing. It holds on features with a rigid support path, a stable tool and a short reach. It does not hold across a long thin wall or at the bottom of a deep slot.

The reason is thermal. Titanium moves as it heats and again as it cools. A feature measured hot will not match the same feature measured after the part sits at room temperature. For tight work, we rough, let the part stabilize, then finish, and inspect after a settling period.

Size matters too. Small parts under about 100 mm behave predictably. Large thin parts over 500 mm demand allowance for both thermal drift and residual stress released by removing material. On those parts the drawing should state which dimensions are critical instead of applying one blanket tolerance.

Surface finish follows the same logic. Ra 1.6–3.2 μm is a normal as-machined result. Ra 0.8–1.6 μm needs a deliberate finishing pass, and Ra 0.2–0.8 μm needs a fine finishing strategy plus, on some geometry, a secondary operation.

We inspect 100% of parts before shipment, with raw material checks, in-process monitoring and a final inspection. Reports are available on request.
