A precision CNC washer cutting machine is a milling center set up for flat stock. The sheet is clamped to a fixture or a vacuum table, and a small end mill runs along the outline taken from the CAD file. There is no punch and no die. Every edge is produced by the same rotating cutter, so the washer geometry lives in the program rather than in a hardened steel tool.

That distinction matters for how you read a drawing. On a die-cut part, the inner hole and the outer edge come from two separate cutting edges, and their relative position depends on die alignment. On a milled part, both come from the same tool path, so concentricity is a programming value. If the drawing calls out a 0.05 mm concentricity between bore and outside diameter, that is a number the shop can hold and measure.

The cutter removes material rather than shearing it. A 2 mm to 3 mm carbide end mill is typical for a Ø20 mm washer with a Ø10 mm bore. The path is usually a helical ramp into the material, then a contour pass around the profile, then a finishing pass with a smaller radial engagement. Climb milling on the finish pass leaves a cleaner edge on most metals.

Chip evacuation decides the surface you get. Soft aluminium and brass can smear if the cutter rubs instead of cutting. The usual fix is a higher feed per tooth and a light depth of cut, plus air blast rather than flood coolant on thin sheet. On stainless, the reverse is often true: too light a feed work-hardens the edge and the next pass cuts through a harder skin.

The headline figure is ±0.005 mm, and shops can hold it on the features that matter. In practice the limit is not the machine but the part. A 0.5 mm thick stainless shim behaves very differently from a 6 mm thick aluminium spacer, and the drawing should reflect that. Thin stock deflects under clamping force and lifts between passes.

For a 0.5 mm to 1.0 mm shim, expect ±0.02 mm to ±0.05 mm on the outside profile unless the shop uses a vacuum fixture and a sacrificial backing plate. For 3 mm to 6 mm plate, ±0.01 mm is realistic on hole position, and ±0.005 mm is achievable on a reamed bore. The tolerance you can hold depends on thickness as much as on the machine.

Flatness is the quiet problem. Milling thin sheet releases internal stress and the part can bow after unclamping. Stress-relieved stock helps. So does leaving a thin web, cutting the profile, then removing the web in a second pass. If the washer sits in a bolted joint, a 0.05 mm bow across a Ø50 mm face is often enough to leak.

Surface finish follows the same logic. A finish pass at Ra 0.8–1.6 μm is normal for a sealing face. Ra 0.2–0.8 μm is available if the seal is critical, but it needs a dedicated finishing pass and a sharp cutter. A rougher Ra 1.6–3.2 μm is fine for a plain mechanical spacer that never sees pressure.

Soft elastomers are the hard case. Rubber, cork and soft polymer compress under the cutter and spring back, so the edge tears rather than shears. Two approaches work. One is to chill the sheet below its glass transition, which makes it brittle enough to cut cleanly. The other is to clamp it between two rigid plates and mill through the stack, which supports the edge on both sides.

Metals are more predictable. Aluminium 6061 and 5052 cut fast with a two-flute cutter and air blast. Stainless 304 and 316 need a slower surface speed and a steady feed to stay below the work-hardening threshold. Copper and brass cut cleanly but grab the cutter, so a positive rake and a generous chip load are used. Titanium and Inconel are possible, but the cutter cost per part rises sharply and the shop will usually quote a longer run time.

Plastics split into two families. POM, PA and PEEK machine well and hold a sharp edge. ABS and PMMA can chip at the exit if the feed is too high, and PMMA is prone to crazing if the wrong coolant is used. Carbon fibre is a third case again: it is abrasive, so carbide wears quickly and the edge delaminates if the cutter pushes the fibres instead of slicing them.

The material list a shop can quote from is wide: aluminium 6061, 2024, 5052, 7075; stainless 303, 304, 316L, 17-4PH; steel 1018, 1045, 4140; copper C110 and C36000 brass; plastics ABS, POM, PEEK, PP, HDPE and carbon fibre. If the drawing names a grade that is not in that list, ask before assuming a substitute.

A die is a fixed shape. Change the outline and you cut a new die. A milling program is not fixed, so a washer with a non-circular bore, a tab, a keyway or a stepped thickness costs editing time rather than tooling money. That is the real benefit of CNC washer cutting on low and mid volume work: the design stays open until the drawing is signed.

Internal cutouts are where the difference shows. A die needs a matching punch for every hole, and small punches are fragile. An end mill simply plunges and walks the profile. A Ø3 mm bore in a 2 mm thick stainless washer is routine on a mill. On a die it needs a small punch that will need replacing.

Profiles that vary through the thickness are also possible. A counterbore, a chamfered edge or a relief step can be cut in the same setup as the profile, which removes a second operation and a second chance to lose concentricity. Multi-axis machines handle a tapered or curved sidewall that a flat punch cannot produce at all.

There is a limit. Deep, narrow slots are hard on any cutter. A slot narrower than about 1.5 times the cutter diameter, and deeper than three times the cutter diameter, will deflect and the wall will taper. If the drawing needs a 0.5 mm wide slot through 5 mm steel, that is wire EDM or laser territory, not milling.

The cost structure is the whole argument. A die carries a fixed tooling charge and a very low unit cost. A milling program carries almost no fixed charge and a higher unit cost. Somewhere between the two lies a crossover, and for a typical Ø30 mm washer the crossover is often in the tens of thousands of identical parts.

Below that crossover, milling is cheaper in total spend even though the per-part price looks higher. It also removes a schedule risk. A die takes weeks to make and prove out. A program takes hours. If the first article reveals a problem, a revised program ships the next day. A revised die does not.

Nesting is a second saving. Cutting software packs outlines onto the sheet so the gap between parts is small. On a 1 mm stainless sheet with a Ø20 mm washer, a well nested layout can raise yield noticeably against a hand-laid layout. The scrap value of the skeleton is recovered, but the sheet that never gets bought is the bigger number.

Prototype and production can also share the same file. The part cut for the fit check is the same geometry that goes into the 10,000 piece run. No tooling change means no dimensional shift between the sample a design team signs off and the parts that arrive at the line.

A leaking joint on a milled gasket is usually a flatness problem, not a diameter problem. The part measures correct across the face and still leaks because it bows after unclamping. If a leak appears on a thin washer, check flatness on a surface plate before questioning the bore size. Re-cutting the diameter will not fix it.

Burrs are the second common complaint. Milling leaves a small burr on the exit side of the cut, and on a sealing face that burr is a leak path. A light chamfer or a deburring pass removes it. Bead blasting, tumbling and brushing are all available as finishing steps, and a drawing that calls out a burr-free edge should say which face is the seal.

Work hardening is the third. Stainless that was cut with too light a feed can test hard at the edge and crack when the washer is pressed into a recess. The fix is at the machine, not at the part: a heavier chip load and a cutter that stays sharp. If a batch of 316 washers cracks on assembly, the cutting parameters are the first thing to review.

Dimensional drift across a batch is rarer than people expect on a modern mill, but it happens when the cutter wears. A shop monitoring in-process dimensions will catch it. A shop that only checks the first and last part may not. Ask what the inspection plan is before the run starts, not after.
