Alloy processing is the shaping of metal that is not a single pure element. Aluminum 6061, stainless 316L, titanium Ti-6Al-4V, and Inconel all fall here. The machine removes material, but the result depends on how the alloy handles heat, chips, and tool pressure.

That is why the same program produces different results on different alloys. A cut that leaves a clean finish in 6061 can burn the edge in 17-4PH at the same feed. The alloy decides tool life, spindle load, and whether the part stays within tolerance after cooling.

GreatLight runs alloy processing across 127 high-precision CNC machines, including 16 simultaneous five-axis centers. Tolerances hold at ±0.005 mm when the process is matched to the material, not forced through one default recipe.

• 1
  Heat is the main variableLow-conductivity alloys push heat into the tool instead of the chip.
• 2
  Chip evacuation sets the limitDeep pockets in titanium need high-pressure coolant or peck cycles.
• 3
  Tolerance is a thermal problemA part measured hot can read 0.02 mm off after cooling.

On a three-axis machine the tool only moves in X, Y, and Z. On a five-axis center the tool or the table also rotates on two more axes. The practical effect is that the tool can reach the part from an angle instead of straight down.

Angled access matters for alloys. Cutting a 30° wall with the side of an end mill spreads load along the flute and reduces vibration. That lets us run higher feed without chatter, which shortens cycle time and improves surface finish at the same time.

One setup also replaces several. A part with features on five faces normally needs three or four repositionings on a three-axis machine. Each repositioning adds a datum error. With five-axis work, the part stays clamped once, so stack-up stays smaller.

• 1
  Short tools, less deflectionAngled entry keeps the tool short and rigid.
• 2
  Fewer datumsOne setup removes repositioning error.
• 3
  Better chip flowTool angle lets chips fall away instead of packing.

Surface speed is the number that matters first. It sets how fast the cutting edge moves through the material and how hot it gets. Aluminum runs fast, often above 300 m/min. Titanium runs slow, around 40 to 60 m/min, because it conducts heat poorly.

Feed per tooth controls chip thickness. Too thin and the edge rubs instead of cutting, which work-hardens stainless and burns titanium. Too thick and tool pressure rises. The window is narrower in alloys than in mild steel.

Depth of cut should stay steady. A stable radial engagement of 5 to 10 percent of tool diameter in hard alloys keeps load predictable and reduces chatter. Sudden full-width cuts are what break small tools.

Coolant choice follows the alloy. High-pressure through-tool coolant helps Inconel and titanium clear chips from deep pockets. Aluminum cuts clean with air blast or mist and does not need flood.

• 1
  AluminumHigh speed, light depth, air blast, watch for built-up edge.
• 2
  Stainless and 17-4PHModerate speed, sharp edges, never dwell in the cut.
• 3
  Titanium and InconelLow speed, high pressure coolant, rigid setup.

Aluminum 6061 and 7075 cut easily and hold tight tolerance. 7075 is stronger but slightly more brittle at edges, so deburring matters. Both are good choices when weight and stiffness matter and corrosion is not severe.

Stainless 303 machines freely because of added sulfur. 316L does not, and it work-hardens if the tool rubs. 17-4PH in the H900 condition is harder still; we usually cut it in the annealed state and then heat treat, which avoids cutting a hard part.

Titanium Ti-6Al-4V is light and strong but conducts heat at roughly a tenth the rate of aluminum. Heat stays in the cutting zone. Tools wear on the flank and the part can move as it cools, so we leave stock and take a finishing pass after stress relief when the geometry allows.

Inconel and other nickel alloys are the hardest group. They hold strength at high temperature, which is exactly why they resist cutting. Cycle times are long, tool cost is high, and the design should avoid deep narrow slots unless the function truly needs them.

• 1
  Magnesium AZ31B / AZ91DCuts fast but needs chip control and fire-safe handling.
• 2
  Copper and brassC36000 machines clean; beryllium copper needs dust control.
• 3
  Tool steelUsually machined annealed, then hardened and ground.

±0.005 mm is achievable on alloy parts, but not on every feature. The limit depends on feature size, wall thickness, and how many setups are needed. A 3 mm thick wall in titanium will move more than a solid boss in the same material.

Surface finish is a separate decision. As-machined surfaces sit around Ra 1.6–3.2 μm. A finishing pass with a smaller stepover reaches Ra 0.8–1.6 μm. Fine finishes down to Ra 0.2–0.8 μm are possible but add time, so specify them only on sealing faces or sliding surfaces.

Every tolerance callout has a cost. Tightening a non-critical hole from ±0.1 mm to ±0.01 mm may add an inspection step and a slower cycle for no functional gain. Engineers get better value by reserving tight tolerance for the features that actually locate or seal.

Inspection matters as much as cutting. We check raw material, monitor in-process, and inspect before shipment. Reports are available on request. A part that is not measured is not controlled.

• 1
  Thin wallsBelow 1 mm in titanium, expect movement after clamping release.
• 2
  Deep holesDepth over 5× diameter needs peck cycles and often a pilot drill.
• 3
  Sharp cornersInternal corners need a radius at least one third of tool diameter.

Choose CNC machining when the part needs tight tolerance, good surface finish, and full density. Casting and 3D printing can get close on shape, but they do not usually hold ±0.005 mm or a sealing surface without secondary work.

Choose it early in a program. Prototypes in the final alloy show real behavior: chip loads, distortion, and assembly fit. A prototype in a substitute material can pass inspection and still fail in the field because the alloy was never the same.

Skip it when the geometry is simple and the volume is high. A die-cast or stamped part will beat machining on unit cost once tooling is amortized. Machining wins on low volume, complex features, and parts that change often.

The same logic applies inside machining. Three-axis is fine for a flat plate with holes on one face. Five-axis earns its cost when features sit on multiple faces, when walls are thin, or when the alloy is hard enough that a rigid setup decides whether the part is made at all.

• 1
  Good fitLow to mid volume, tight tolerance, hard alloy, multi-face geometry.
• 2
  Poor fitHigh volume, simple shape, loose tolerance, cost-driven.
• 3
  Design tipAdd a corner radius and avoid deep narrow slots in nickel alloys.
