CNC Mobile Mobi: CK53100 Vertical Lathe Performance and Structure

A plain-English look at how a heavy CNC mobile mobi machine carries big, short parts. We cover the column and rail layout, the 10,000 mm swing, the 80 t table load, and the points where this class of machine stops being the right answer.

Ø10,000 mm swing3,000 mm height80 t table loadModular column
Structural characteristics of a CNC mobile mobi vertical lathe
Why vertical

Why a CNC mobile mobi machine turns big parts on their face

A horizontal lathe holds a shaft between centers. Gravity pulls the workpiece down along its own axis, and the bed takes the load in a straight line. A CNC mobile mobi machine works the other way. The part sits flat on a rotating table, so its weight presses straight down into the base instead of bending a spindle. That single change is what makes a 10 m diameter ring practical to machine.

The trade is height. The table on this class of machine is roughly 10,000 mm across and the rail sits about 3,000 mm above it, so the part can be wide but not tall. A cone, a flange, a turbine housing, a bearing ring: these are short in the axial direction and large in diameter. That is the shape this layout was built for. Long shafts belong on a horizontal machine.

The term mobile refers to the carriage and column group that travels on the base ways, not to a machine you can move between sites. On the CK53100 the column slides along the bed to position the head over the work, then clamps. The rail head moves up and down the column for the cut. Two axes of travel, one rotating table, and a very short force path from tool tip to foundation.

Structure

Column, rail and base: where the stiffness comes from

Heavy vertical lathes are built around a closed frame. The base is a single cast or welded box that carries the table bearing at its center and the column ways at its edge. Cutting force travels from the tool into the ram, up the column, down through the base, and into the foundation. Nothing in that path is a cantilever longer than the part itself.

The column on the CK53100 is a box section with hardened and ground ways. A wider column raises the bending stiffness of the whole assembly, which is why builders push column width rather than ram length. A long ram that hangs far out of the column will deflect under load, and no amount of servo gain fixes that.

The table runs on a hydrostatic or large-diameter roller bearing, depending on the builder. Hydrostatic tables hold axial and radial position well at low speed and damp chatter, but they need clean oil and a working pump. Roller tables are simpler and start faster. For heavy interrupted cuts, the hydrostatic option usually wins on surface finish.

Modular design is standard in this size class. The CK53100 is described with a 10 m column as the base type, extendable to 8 m or 12.5 m. The carriage, base and main gearbox are shared across the family, so a shop can size the machine to the largest part it expects without redesigning the whole structure.

Capacity

What the numbers mean in practice

Maximum machining diameter 10,000 mm, maximum machining height 3,000 mm, maximum table load 80 t. Read those three together before anything else. A 10 m ring that is only 400 mm tall is easy for this machine. A 2 m part that is 2,900 mm tall is close to the limit and will need the rail near the top of its travel, where stiffness is lowest.

Table load is not just part weight. Fixtures, chuck jaws, clamps and any counterweight all count. On an 80 t table, a 6 t fixture eats 7.5 percent of the budget before the workpiece is on. For thin rings, the risk is not weight but distortion: clamping a flexible ring onto a table can push it out of round, and the first cut releases that stress.

Cutting forces at this scale are large. A 10 m diameter part turning at 20 rpm has a surface speed near 630 m/min at the rim, so carbide grades that work on small lathes often do not apply. Most shops run lower surface speeds and deeper passes, and accept a longer cycle. That is a process decision, not a machine limit.

The electric tracking rotation device mentioned in the original machine description is for non-circular work: deformed wall thickness, cones and unequal cones. It lets the control keep the tool engaged as the radius changes through one revolution. If your part is a true cylinder, you will not use it.

Testing

How builders prove the machine before it ships

Development testing on a machine this size runs in stages. First an air running test with no workpiece: spindle and table run through their speed range, gearbox shifts, and the control checks axis following error. This finds assembly problems without risking a part.

Then a load running test with a dummy workpiece or a heavy fixture. The main transmission is pushed toward its rated torque and the table bearing is checked for temperature rise. A hydrostatic table that runs hot is usually a sign of oil film trouble, not a bearing failure.

Cross-cutting tests follow. The machine takes cuts in more than one direction relative to the work to check geometry under combined load. The output is a record of roundness, flatness and surface finish across the table. Ask for that record, not just a pass or fail statement.

For a buyer, the useful question is which tests were run on the specific machine, and what the recorded numbers were. A general specification sheet tells you what the design can do. A test record tells you what the machine in front of you actually did.

Fit

When this machine is the wrong answer

The CK53100 is a heavy, slow, high-setup machine. If you are making 200 identical Ø150 mm flanges, it is the wrong tool. A mill-turn center with a Ø400 mm rotary table will run those faster, hold ±0.005 mm more easily, and change over in minutes.

Height is the second hard limit. Anything over roughly 3,000 mm tall needs a different machine class. Some shops try to extend the rail and add a riser block. That works for a one-off, but it moves the cut further from the base and the finish suffers on the lower passes.

Third, this class of machine is not a five-axis tool. It turns and it faces. Holes, slots and pockets on the part face are usually done on a second machine or on a live-tool variant. If your drawing has a lot of off-axis work, add the second setup to your cost model before you commit.

Where it does win: low quantities of large, heavy, round parts. Energy, mining, shipbuilding, cement and heavy gearbox work all sit here. One ring every few weeks, 40 t, 8 m across. Setup time is irrelevant next to the cost of the casting, and the machine pays for itself on geometry alone.

Layout choice

Vertical versus horizontal for large parts

Pick the row that matches your part shape.

Part shapeBetter layoutWhy
Ring, flange, disc up to Ø10,000 mmVerticalWeight goes straight into the base
Cone or bowl, height under 3,000 mmVerticalTable holds the wide end flat
Shaft over 3,000 mm longHorizontalVertical rail travel runs out
Thin flexible ring, 2–5 mm wallVertical with light clampingHorizontal chucking distorts more
Box housing, off-axis featuresHorizontal or 5-axis millTurning alone cannot reach them
Small parts under Ø400 mmHorizontal or mill-turnSetup cost per part is too high

The short version

If the part is round, under 3,000 mm tall and heavy, a CNC mobile mobi vertical lathe like the CK53100 is the right layout. If it is long, light or full of off-axis features, choose a horizontal or five-axis machine instead.

FAQs

Questions buyers ask next

Does mobile mean the machine can be moved between job sites?

No. On this class of machine, mobile describes the carriage and column group that travels on the base ways to position the head. The machine itself is a fixed installation on a prepared foundation.

If you need a machine that moves between sites, that is a different product category with much smaller work envelopes.

How much foundation does a CK53100 need?

A machine with an 80 t table load and a 10 m swing needs a reinforced concrete foundation sized by the builder, usually with isolation pads or grout under the base. The foundation carries both the static weight and the dynamic cutting force.

We ask for the builder foundation drawing before we plan any floor layout. Cutting a foundation after the machine is set is expensive.

Can the machine hold ±0.005 mm on a 8 m diameter part?

Tolerance on a part that size depends on the machine geometry, the temperature of the shop, and how the part is clamped. A tolerance stated on a small machined feature is not the same as a diametral tolerance across 8 m.

A realistic approach is to agree the measuring method and the temperature at inspection time before the job starts. Thermal growth across 8 m of steel is measurable in a normal shop.

What surface finish is realistic on heavy vertical turning?

Ra 1.6–3.2 μm as-machined is normal for rough and semi-finish passes on large work. Finer passes and a stable setup can reach Ra 0.8–1.6 μm on the faces.

Getting below Ra 0.8 μm on a 10 m part usually means a separate finishing operation, not a single setup on the vertical lathe.

Do we need a second machine for holes and pockets?

Usually yes. A plain vertical lathe turns and faces. Off-axis holes, slots and pockets need a live-tool variant or a second setup on a milling machine.

Plan the datum transfer between the two setups. That is where most of the tolerance is lost on large round parts.

How do we check a 10 m part without moving it?

In-place measurement with a laser tracker or a large CMM arm, taken on the machine while the part is still clamped, then again after unclamping. The difference between the two sets of numbers is the clamping distortion.

If that difference is larger than your tolerance, the problem is the fixture, not the machine.
