In CNC vertical processing the spindle points down and the tool spins on a vertical axis. The workpiece usually sits on a horizontal table that moves in X and Y, while the spindle head or the table carries the Z motion. That single geometry decision drives everything else: chip fall, fixturing, tool access, and how deep a pocket you can reach without a long, flexing tool.

The machine reads a part program, converts it into axis commands, and cuts metal along a path that repeats to the same numbers every cycle. On a three-axis vertical mill the tool axis stays fixed, so any surface not reachable from above must be repositioned by hand or cut on a second setup. Adding a fourth or fifth axis changes that rule.

Gravity helps here. Chips drop away from the cut instead of piling on the workpiece, which matters on aluminum and brass where recutting a chip tears the surface. It also means the operator can watch the cut and clear swarf without stopping the cycle.

The trade-off is reach. A vertical spindle cannot easily machine the underside of a flange or a side wall that faces sideways without a re-fixture, an angle head, or a tilting trunnion. That limit, not the control system, is what usually decides whether a part belongs on a vertical machine.

Axis count is the first specification to check against a drawing. A three-axis machine cuts from one direction only. A four-axis machine adds rotation about one axis, usually A or B, so a part can be indexed to several faces in a single program. A five-axis machine moves the tool or the part on two rotary axes at once, which lets a short rigid tool follow a contoured surface instead of a long one reaching around it.

Travel is the second check. GreatLight runs vertical machines with a 4,000 × 400 × 150 mm envelope for long, slim parts, and 750 × 1,150 × 550 mm or 600 × 600 × 600 mm for general work. Smaller verticals cover 500 × 500 × 450 mm and 500 × 310 × 200 mm. A Ø400 mm rotary table handles round and cylindrical features that would otherwise need a lathe.

Part size is not the only fit question. A 300 mm deep pocket in a 750 mm travel machine still needs a tool long enough to reach the floor. Long tools deflect. A 12 mm carbide end mill at 4× diameter depth is comfortable; at 8× diameter the same tool will chatter and push the wall out of tolerance unless you reduce radial engagement and step down.

A five-axis machine solves some of that by tilting the part toward a shorter tool. It does not solve thin walls, deep slots narrower than the tool shank, or features that need a specific surface finish on a floor the tool cannot reach squarely.

Tolerance and finish are process outputs, not machine nameplate numbers. GreatLight holds ±0.005 mm (±0.0002 in) on qualifying features, with a reported 99.99% qualification rate across production. That figure comes from control of the whole chain: raw material check, in-process monitoring, and 100% inspection before shipment.

Surface finish spans three working bands. As-machined surfaces land at Ra 1.6–3.2 μm. A normal finishing pass reaches Ra 0.8–1.6 μm. Fine finishing at Ra 0.2–0.8 μm needs sharper tooling, smaller stepovers, and often a separate light pass after the part has cooled.

Geometry is what breaks tolerance first. Thin floors and tall ribs move under cutting force, and the amount they move depends on stock left behind, tool pressure, and how much heat the cut puts into the part. A feature that measures well on the machine may relax after unclamping.

Material matters too. Aluminum 6061 and 7075 cut freely and hold tight numbers with sharp carbide. Stainless 316L and 17-4PH work-harden, so a dwell or a rubbed edge will raise cutting force and pull the wall. Titanium TC4 (Ti-6Al-4V) and Inconel need lower surface speed, more coolant, and a shorter tool projection. Nothing about vertical processing changes those physics, but the open setup makes it easier to flood the cut.

Setup count drives cost and error more than spindle speed does. Every re-fixture adds a datum transfer, and each transfer adds stack-up. A part that needs four faces machined from three setups carries more risk than the same part cut on a five-axis machine in one.

The usual vertical workholding is a vise, soft jaws, a fixture plate, or a vacuum chuck for thin plate. Soft jaws machined to the part profile are the standard answer for second operations because they locate on an already-cut surface instead of raw stock.

Clamping force is a real variable. Squeezing a thin frame in a vise bows it, and it springs back after the cut. Low-profile clamps, toe clamps, and sacrificial tabs keep the part flat while the tool passes. On long parts in the 4,000 mm envelope, support the middle as well as the ends or the part will ring and the floor finish will show it.

Probing cuts setup time and setup error. Touching off a datum with a spindle probe instead of an edge finder removes a whole class of offset mistakes, especially on second operations where the previous cut face is the new reference.

Vertical machining covers a wide material list. Aluminum grades 6061, 6061-T6, 2024, 5052, 5083, 6063, 6082, 7075 and ADC12 cut cleanly on a vertical spindle. Stainless 303, 304, 316, 316L, 420, 430, 431, 440C and 17-4PH (SUS630) are routine, as are steels 1018, 1045, 4130, 4140, 4340, A36 and tool steel. Copper and brass grades C101, C103, C110, C27400, C28000 and C36000 machine well with the right speeds.

Titanium TA1, TA2, TC4, Inconel, and magnesium AZ31B and AZ91D are also machined here, though they demand tighter process control. Plastics from ABS and POM through PEEK, PP, HDPE and carbon fibre are common for brackets, housings, and insulators where the tolerance is looser but the geometry is complex.

Batch size is flexible. GreatLight runs with no minimum order quantity, from a single prototype to runs over 10,000 parts. Prototypes and low volume favor vertical machining because the program and fixture can be changed in minutes. High volume sometimes shifts to casting or dedicated fixturing, but vertical machining often stays for the finishing cuts.

Lead time starts with the quote. A quotation and free DFM analysis come back within 12 hours, production can start within 24 hours, and parts typically ship in 3–5 days. The DFM review is where most cost is saved, because a small geometry change can remove a setup or a long tool.
