Every CNC machining parts operation starts with the drawing, not the machine. Before touching a vise, look for three things: the primary datum, the tightest tolerance and any surface finish callout. The datum tells you which face must sit flat on the fixture. The tightest tolerance tells you which feature controls the process. A finish callout of Ra 0.8–1.6 μm means you need a separate finishing pass, not just a slower rough cut.

Check whether the part has a second operation. A block with holes on five faces cannot be finished in one setup on a 3-axis machine. It needs either a 4-axis rotary table or a second op with a fresh datum. If the drawing shows a positional tolerance of ±0.05 mm between two faces, plan to machine both faces in the same setup or use a probe to re-zero after the flip.

Material matters too. Aluminium 6061 cuts clean at 3,000–6,000 rpm with a 10 mm carbide end mill. Stainless 316 work-hardens if the feed is too light, so keep the chip load above 0.05 mm per tooth. Titanium Ti-6Al-4V needs lower surface speed and plenty of coolant. The drawing may not say this, but the material determines the cutting data you type into the control.

Write down the critical dimensions before you start. A short list of five to eight numbers is enough. It keeps your attention on the features that matter and stops you from chasing a cosmetic edge while the bore is 0.03 mm undersize.

• 1
  Primary datumThe face that must sit flat on the fixture.
• 2
  Tightest toleranceUsually the feature that drives the whole process.
• 3
  Surface calloutRa 0.8–1.6 μm needs a finishing pass with light depth of cut.
• 4
  Number of setupsFive-face work on a 3-axis machine means a second operation.

Workholding decides whether the part moves. For a rectangular block, a machine vise with hard jaws is fine up to about 150 mm wide. Above that, use a fixture plate or toe clamps. Thin walls and long overhangs need support blocks underneath. A 200 mm long part held only at one end will deflect under a 12 mm cutter, even at a light depth of cut.

Set the work offset carefully. Touch off X and Y with an edge finder or a 3D probe, then set Z on the top face. If you use a probe, verify the result by moving to the nominal zero and reading the position screen. A 0.1 mm error in the offset becomes a 0.1 mm error on every feature. On a 5-axis machine, also check the rotary table center. Our 5-axis centers use a Ø400 mm rotary table, and a misaligned center shows up as a taper on cylindrical features.

Clamp pressure matters. Over-tightening a vise on a thin aluminum plate bows it upward, and the part springs back after unclamping. For plates under 10 mm thick, use soft jaws machined to the part profile and moderate torque. For stainless and steel, you can clamp harder, but still check the part with a dial indicator after clamping.

Finally, confirm tool lengths. A tool that is 0.5 mm shorter than the offset says will cut air or crash. Measure every tool in the presetter or on the machine, and load the correct offset number. This step takes two minutes and prevents most scrap.

• 1
  Vise or fixtureUse a fixture plate above 150 mm part width.
• 2
  Support thin wallsBack the part with a support block to stop deflection.
• 3
  Verify the offsetProbe the zero point and read the position screen.
• 4
  Check tool lengthsA wrong length offset is the most common crash cause.

Split the cut into three stages. Roughing removes most of the stock with a large tool, usually a 10–16 mm end mill. Leave 0.3–0.5 mm radial stock on walls and 0.1–0.2 mm on the floor. Run the rougher fast but keep the chip load steady. On aluminium 6061, a 12 mm three-flute cutter at 4,000 rpm and 1,200 mm/min feed removes material quickly without chatter.

Semi-finishing cleans up the stair steps left by the rougher. Use a slightly smaller tool and a light radial engagement, around 5–8 percent of the tool diameter. This step protects the finishing tool from uneven load. If you skip it, the finisher will see varying chip load and leave a worse surface.

Finishing is where the tolerance and finish come from. Use a sharp, dedicated finishing tool with a small corner radius. For a bore at ±0.005 mm, take a 0.1–0.2 mm radial pass, then measure and adjust the cutter compensation before the final pass. Do not compensate on the fly without measuring. For a face finish of Ra 0.8–1.6 μm, keep the stepover below 0.5 mm and the surface speed high.

Watch the chips. Long stringy chips on aluminium mean the feed is too low or the speed too high. Blue chips on steel mean the speed is too high for the coolant. Fine powder on stainless means the tool is rubbing instead of cutting, and work hardening is starting. Adjust the feed override before the tool wears out.

• 1
  Roughing stock0.3–0.5 mm radial, 0.1–0.2 mm axial.
• 2
  Semi-finishing5–8 percent radial engagement to even out the load.
• 3
  Finishing pass0.1–0.2 mm radial with cutter compensation.
• 4
  Read the chipsColor and shape tell you if the cutting data is right.

Do not wait until the end to measure. Check the first feature as soon as it is cut. If the first hole is 0.05 mm off, stop and fix the offset before cutting the rest. A quick check with calipers catches gross errors, but a micrometer or bore gauge is needed for anything under ±0.02 mm. On our floor, every part gets a raw material check, in-process monitoring and a final inspection before shipment.

Measure the feature that matters most, not the easiest one. If the drawing calls out a ±0.005 mm bore, that bore is the first thing to verify. Use the same measuring tool for the first article and the final inspection. Switching from calipers to a CMM between checks introduces doubt about which number is correct.

Watch for thermal drift on long runs. A spindle that warms up over two hours can shift Z by 0.01–0.02 mm. On tight-tolerance parts, re-check the first feature after 30 minutes and adjust the offset if needed. On a 5-axis machine, the rotary table can also warm up and shift the center slightly.

Log every measurement. A simple sheet with the feature name, nominal value, actual value and tool number is enough. When a dimension drifts, the log shows whether the tool is wearing or the setup moved. That distinction decides whether you change the offset or stop the machine.

• 1
  Check earlyMeasure the first cut feature, not the last.
• 2
  Use the right gaugeMicrometer or bore gauge below ±0.02 mm.
• 3
  Watch thermal driftRe-check after 30 minutes on tight parts.
• 4
  Keep a logNominal, actual and tool number for every critical feature.
