Every model you load into Magics is a mesh of triangles, not a solid. Position commands rewrite the coordinates of those triangles. That is the whole mechanism. When you translate a part by 20 mm in X, every vertex moves 20 mm in X, and the triangle count stays the same.

This matters because mesh edits are not reversible by default. If you scale a part by 1.05 and save, the file now holds the scaled mesh. There is no history that says 'this was originally 1.00'. For mold repair work, always keep the original STL untouched and edit a copy.

The Position toolbar is separate from the file's units. Magics works in millimeters internally. If your source model was built in inches, the import dialog converts it, and every value you type in Position is still millimeters. Typing 25 thinking in inches gives you a part 25 mm across, not 25 in.

One more mechanical detail. Translate, rotate and scale can be applied to a single part or to a group. A group rotates as one body around a shared pivot. If two parts are selected and one is not at the pivot, it swings out of position. Deselect before editing unless you actually want a group move.

• 1
  Edit a copyKeep the as-received STL as a read-only reference for dimensional checks.
• 2
  Work in millimetersPosition values are always mm, regardless of the model's original unit.
• 3
  Single part or groupGroup edits use one pivot; ungroup first if the parts should move independently.

Translate moves the part along one or more axes. Type the offset in X, Y and Z, then apply. Use it to put a known datum at the origin before anything else. A mold insert that should sit with its parting face on Z = 0 goes there in one step, and every later measurement is easier to read.

Rotate turns the part around a chosen axis. The angle is in degrees, and rotation is counterclockwise when looking down the positive axis toward the origin. A 90 degree turn on X stands a flat plate upright. Check the pivot point first, because rotation happens around the axis, not around the part's center unless you set it that way.

Scale resizes the mesh by a factor or by a target dimension. A factor of 1.0 leaves it alone. If you know the part should be 120 mm long and it measures 119.2 mm, scale by 120 / 119.2 = 1.0067. Do this once and verify with a measurement, not by eye. Repeated small scales compound fast.

Mirror flips the part across a plane, usually X, Y or Z. Use it when a repair job needs a left-hand version of a right-hand mold insert. The geometry is identical in size, but the handedness flips. After mirroring, recheck any angled face that relies on draft, and recheck thread-handedness if the mesh has threads modeled.

• 1
  TranslateType X, Y, Z offsets in mm to place a datum at the origin.
• 2
  RotateChoose axis and angle in degrees; confirm the pivot before applying.
• 3
  ScaleUse a target-dimension ratio, then measure to confirm.
• 4
  MirrorFlip across a plane for left-hand parts; recheck draft and threads.

Reposition when the part has to sit in a known place for a downstream step. Slicing, support generation, and mold repair all assume the part sits flat on the platform with its build direction along Z. A scan that comes in tilted 4 degrees will print with a stair-stepped face. Rotate it flat first, then slice.

Leave the mesh alone when the problem is not position. A hole that measures 9.85 mm instead of 10.0 mm is a feature issue, not a position issue. Scaling the whole part by 1.015 to fix one hole pushes every other dimension out by the same factor. For that job, go back to the CAD or cut a new feature.

There is a real cost to mesh edits. Every rotation resamples the surface, and a part rotated several times can pick up small faceting artifacts. On a mold repair where the surface finish matters, rotate once to the final orientation and then stop. Do not stack three 30 degree turns to reach 90 degrees.

For parts that go on to CNC machining after printing or repair, the position in Magics should match the machining setup. If the CAM side will grip the part on the same datum you set at the origin, the stock allowance is predictable. This is the point where Magics basic 3D printing work and machining prep meet.

• 1
  Reposition for setupFlat on the platform, build direction along Z, datum at origin.
• 2
  Do not scale for feature errorsWhole-part scaling moves every dimension, not just the bad one.
• 3
  Rotate onceStacked rotations resample the surface and add faceting.
