PA12 is a polyamide built from laurolactam, a 12-carbon ring. PA6 and PA66 use shorter chains and form more hydrogen bonds between them. Those bonds hold water. PA12 packs fewer bonds per unit volume, so it absorbs roughly 0.5 to 1.0 percent moisture at saturation, while PA6 can take 2.5 to 3.0 percent. That single difference drives most of the dimensional behavior engineers care about.

The longer aliphatic chain also lowers the melting point to roughly 178–190 °C and widens the processing window. In laser sintering this matters more than tensile numbers. A wide window means the powder bed can sit just below melt without caking, so the laser can fuse a clean cross-section and leave the surrounding powder reusable.

Mechanically, PA12 lands around 45–50 MPa tensile strength and 15–25 percent elongation at break when printed by SLS. Stiffness is modest. It bends before it cracks, which is why it survives snap fits, living hinges and drop-tested housings that would shatter a brittle resin.

One caution. PA12 is not a high-temperature material. Heat deflection sits near 80–95 °C at 0.45 MPa. Above that it creeps under sustained load. If your part sees engine-bay heat or a reflow oven, this is the wrong polymer.

SLS spreads a thin layer of PA12 powder, typically 60–120 μm, across a heated bed. A CO2 laser traces the cross-section and fuses the grains. The bed drops, a roller spreads the next layer, and the cycle repeats. Unfused powder stays in place and supports the part, so no breakaway supports are needed.

That self-supporting behavior is the real design freedom. You can nest parts in three dimensions, stack them, and build internal channels that would trap support in FDM. Undercuts cost nothing extra. The trade is surface finish: sintered walls come out grainy, usually Ra 8–12 μm, and small features below 0.5 mm may not survive the powder spread.

MJF uses the same powder with an infrared fusing agent instead of a laser. Parts are denser at the edges and slightly stronger in the Z direction. Both processes give you the same material family; the choice usually comes down to machine availability and the finish you can tolerate.

Build orientation still matters. Layers bond less strongly than the bulk, so tensile strength across the Z axis can be 10–20 percent lower than in-plane. Place the axis that sees the highest load in the XY plane when the geometry allows it.

PA12 rewards complexity. Lattice cores, organic brackets, conformal cooling channels and ducting with internal ribs all print as one piece. Wall thickness between 0.8 mm and 3.0 mm is the sweet spot: thin enough to stay light, thick enough that the laser fully melts the core of the wall rather than leaving a porous center.

Dimensional accuracy for SLS PA12 is commonly quoted at ±0.3 percent, with a floor around ±0.3 mm on small features. That is fine for brackets and housings. It is not fine for a bearing bore or a sealing face. Those need a machined interface, and we often print oversize then finish the critical surfaces on a CNC.

Long, flat panels are the weak case. As the bed cools, the part shrinks and a thin plate can curl at the corners. Adding a 1–2 mm rib or a slight crown removes most of it. Same story for very tall thin walls: they tend to lean as the build progresses.

Fine threads, sharp internal corners and surfaces that must slide against each other are all better cut than printed. Printing gives you the shape; machining gives you the fit. Mixing the two is usually cheaper than forcing one process to do both jobs.

Unfilled PA12 is the default. It gives the best elongation and the most predictable isotropy, which is what you want for enclosures, jigs and functional prototypes that get handled.

Glass-filled PA12 raises stiffness and heat deflection, roughly 2,800 MPa flexural modulus against 1,500–1,700 MPa for the unfilled grade. It also gets more abrasive and slightly more brittle. Use it when the part must hold shape under load, not when it must absorb impact.

Dyeing is a bath process and penetrates a few tenths of a millimeter. It gives uniform color but no protection against wear. Vapor smoothing and tumble polishing knock the grain down and make the surface easier to clean. Sealing with an epoxy or urethane coat closes the surface porosity, which matters for parts that see oil or coolant.

For functional interfaces, we machine printed blanks on the same shop floor. Tolerance down to ±0.005 mm and finish to Ra 0.8–1.6 μm are achievable on PA12, though the material cuts more like a soft wax than like aluminum. Climb milling, sharp tooling and light depths of cut keep it from smearing.
