A 3D file is a container. What matters is the kind of data inside it. Mesh formats describe a surface as a set of triangles. Solid formats describe a volume with real faces, edges and a feature tree. Those two families behave very differently once you move from a slicer to a CNC machine or an inspection report.

Mesh formats such as STL and OBJ store coordinates and connectivity, plus a normal direction per triangle. There is no unit declaration and no material definition. A sphere becomes flat facets, and the count of those facets decides how smooth the surface looks. If the exporter used a coarse chord tolerance, the model is already wrong before anyone slices it.

Solid formats such as STEP and IGES store real geometry: analytic surfaces, trimmed edges, and in the case of STEP, a feature history. A Ø10 mm hole stays a cylinder, not a ring of 64 triangles. That matters when you need to change the hole to Ø12 mm or measure it on a CMM.

The practical consequence is simple. Meshes are for printing and visualization. Solids are for editing, measuring and machining. Send the wrong family and the other side spends time rebuilding what you already had.

• 1
  Mesh fileTriangles only. No units, no material, no feature history.
• 2
  Solid fileAnalytic surfaces and edges. Editable and measurable.
• 3
  Slice fileG-code or a project file. Machine-specific, not a design asset.

STL is the oldest and still the most common of the 3D printing file formats. It stores one triangle at a time: three vertex coordinates and a normal. Binary STL is compact; ASCII STL is readable but roughly five times larger. Neither version records units, so a file exported in inches opens as millimeters in some slicers and the part prints 25.4 times too small.

The triangle count is set at export, not at print. A typical 100 mm bracket exported at 0.05 mm chord tolerance lands around 200,000 to 500,000 triangles. Push the tolerance to 0.005 mm and the file triples in size with almost no visible gain on a 0.4 mm nozzle. Export settings should match the process, not the ego.

OBJ adds texture coordinates and material groups, which is why it shows up in visualization, dental and color-print work. PLY stores per-vertex color and is common in 3D scanning output. Neither one fixes the core limitation: a mesh has no notion of a hole, a fillet or a thread.

Watertightness is the other trap. A mesh with a missing triangle, a flipped normal or a zero-area sliver will slice into a shell with gaps. Most slicers auto-repair, but the repair is a guess. For a functional part, check the mesh before you print.

• 1
  STLTriangles only. Fast, universal, no units.
• 2
  OBJTriangles plus UVs and material groups.
• 3
  PLYTriangles plus per-vertex color, scan friendly.

STEP is the default exchange format between CAD systems. It carries B-rep geometry, assembly structure, units and metadata. If a part will be machined after printing, or if the print is a fit check for a machined counterpart, send STEP. A machinist can pull dimensions from it, add stock, and program toolpaths without remodeling.

IGES predates STEP and survives in aerospace and older tooling chains. It handles surfaces well but is weaker on solids, assemblies and metadata. Expect more healing work on import. Use it only when the receiving system asks for it.

AMF was written specifically for additive manufacturing. It stores curved triangles and can carry material, color and lattice information in one XML file. Adoption stayed narrow because 3MF arrived with similar goals and stronger software backing. You will still see AMF from 3D scanning and medical modeling tools.

The engineering rule here is about downstream use. If the file only ever feeds a slicer, mesh is fine. If the file will be measured, edited, or used to quote a machined version, use a solid format and keep the mesh as a throwaway export.

• 1
  STEPB-rep solids, assemblies, units. Best for machining handoff.
• 2
  IGESSurface-focused legacy format. Expect repair work.
• 3
  AMFXML additive format with material and lattice data.

3MF is a ZIP container holding XML. It is compact, human-readable when unzipped, and it declares units in the file. A 3MF part cannot silently print at the wrong scale. That single feature removes a whole class of scrap.

It also stores more than geometry. You can put multiple objects, per-object transforms, material assignment, color, and print settings in one file. A build plate with six parts and two materials is one 3MF instead of six STLs plus a spreadsheet.

The file still holds mesh geometry at the core, so it does not replace STEP for CAD editing. But for the print step itself, 3MF is the cleaner container. Most modern slicers, including the ones used in our own shop, read and write it.

If your supplier accepts only STL, sending 3MF is not an option. Ask first. In our experience the conversion path is short: 3MF to STL loses the metadata, not the shape, so nothing about the printed part changes.

• 1
  Declared unitsNo silent inch-to-millimeter scale errors.
• 2
  One file, many partsObjects, transforms and materials together.
• 3
  Still meshNot a replacement for STEP in CAD work.

A printed part carries two tolerances: the file tolerance and the process tolerance. File tolerance is how closely the mesh follows the true surface. Process tolerance is what the printer can hold. If the mesh deviates 0.08 mm and the printer holds ±0.1 mm, you cannot tell them apart. If the mesh deviates 0.4 mm on a curved face, that error shows up in every copy.

Curved surfaces suffer most. A Ø50 mm cylinder exported at 0.1 mm chord tolerance is visibly faceted under raking light. At 0.02 mm it reads as round. The triangle count difference between those two settings is roughly 25 to 1, and file size tracks it.

For functional fits, the print process usually dominates. FDM holds roughly ±0.3 mm on a well-tuned machine; SLA and similar resin processes do better, around ±0.1 mm on small features. A mesh error below 0.05 mm disappears into that budget. A mesh error above 0.2 mm does not.

This is also where hybrid workflows matter. Print the geometry for a fit check, then machine the final part from 6061-T6 or 17-4PH to ±0.005 mm with a finish of Ra 0.8–1.6 μm. The print tells you the shape is right; the machined part holds the tolerance.

• 1
  Keep mesh error under 0.05 mmBelow that, it hides inside normal print tolerance.
• 2
  Watch curved facesFaceting is a mesh setting, not a printer fault.
• 3
  Separate the two tolerancesFile error and process error add, they do not cancel.

Run three checks before the file leaves your desk. First, confirm the units. Open the file in a viewer and measure one known dimension, such as a mounting hole pitch. Second, check watertightness. Look for open edges, flipped normals and duplicate vertices. Third, confirm the wall thickness against the process: 0.8 mm minimum for FDM, 0.4 mm for resin, and more if the part sees load.

Conversion between formats is mostly one-way. STEP to STL is a clean export that bakes in a chosen tolerance. STL to STEP is a rebuild: the mesh gets wrapped into surfaces, and the result is usually a single lumpy solid with no feature history. It is usable for reference, painful for editing.

If you need both a printed prototype and a machined production part, keep the STEP as the master and export STL or 3MF only for the print. That way the design intent survives, and the machined version starts from real geometry rather than a mesh approximation.

When you send a part to us for a machined prototype, STEP is the preferred input. If only an STL exists, we can still quote it, but we will flag thin walls, sharp internal corners and any feature that cannot be cut as modeled. We return a DFM analysis within 12 hours, and prototypes ship in 3–5 days.

• 1
  Units checkMeasure a known dimension in the viewer.
• 2
  Mesh checkOpen edges, flipped normals, sliver triangles.
• 3
  Master fileKeep STEP as the source of truth.
