Every cut is a controlled fracture. The tool for the processing of devices pushes a wedge of carbide into metal, the metal shears along a plane ahead of the edge, and a chip slides up the rake face. The part pushes back with equal force. That force goes into the fixture, the table and the spindle. If the loop is stiff, the cut is quiet and the dimension repeats. If it is not, you get chatter, taper and a bore that measures differently on every part.

Three numbers describe most of what you need to know about edge geometry. Rake angle sets how easily the chip forms. Relief angle sets how much the flank rubs on the finished surface. Edge radius sets how much the tool ploughs instead of cuts. A sharp edge with 5 μm radius cuts cleanly in aluminium at 0.05 mm depth of cut. Push the same edge into 316 stainless and it rubs, work-hardens the surface and dulls within minutes.

Coating is not decoration. A TiAlN layer on a carbide insert drops heat transfer into the tool body, so the edge survives higher surface speed. In aluminium, uncoated polished carbide usually wins because the chips do not stick. In titanium and Inconel, the coating matters less than edge sharpness and coolant delivery, because the heat leaves with the chip, not the tool.

So when a shop says a feature is hard to hold, they are usually describing a force problem, not a machine problem. The tool for the processing of devices has to be short enough, the holder rigid enough and the depth of cut low enough that the cutting force stays below the point where the part deflects.

• 1
  Rake anglePositive for aluminium and brass, near zero or negative for hardened steel.
• 2
  Edge radiusKeep below 10 μm for finishing stainless, 20–30 μm is fine for roughing.
• 3
  CoatingTiAlN or AlCrN for steel and cast iron, polished uncoated for aluminium.
• 4
  ReachDo not exceed 4× diameter overhang without reducing feed per tooth.

A device housing wall of 1.5 mm aluminium has a stiffness that falls with the cube of its thickness. Halve the wall and it becomes eight times easier to push. The cutting force does not change, so the wall simply moves away from the tool. The result is a wall that measures thick at the top, thin at the bottom and varies along the length of the cut.

The usual fix is not a slower feed. It is support. Fill the pocket with a low-melt wax, leave a sacrificial rib, or machine the wall in two passes with a roughing tool that takes the bulk and a finishing tool that takes 0.15 mm. The finishing pass has to be light enough that the wall springs back to its free position while the edge is still in the cut.

Runout multiplies the problem. If a finishing end mill has 0.02 mm of runout, one flute does most of the work. That flute wears first, the effective diameter changes, and the bore drifts. On a device bore held to ±0.005 mm, we check runout at the holder before every finishing operation. A worn collet is a common cause of a dimension that walks over a 200-part run.

For deep bores, the tool body itself bends. A 10 mm carbide boring bar at 100 mm reach will deflect under a 0.3 mm depth of cut. The answer is a larger bar, a shorter reach, or a boring head with a damped shank. Every one of those changes costs setup time. It is worth deciding which feature actually needs the tight tolerance before spending that time.

• 1
  Support the wallWax, ribs or a two-pass strategy beat slowing the feed.
• 2
  Check runoutUnder 0.005 mm for finishing bores held to ±0.005 mm.
• 3
  Shorten the reachBoring bar overhang under 4× diameter where the tolerance allows.

Gear teeth are not cut by a single point. The tool for the processing of devices in a gear cell is a form cutter or a set of blades arranged in a circle. A paired cutter runs two blades in adjacent tooth spaces and machines both flanks at once. Its module range sits around 0.3 to 20 mm, and the body carries a front angle with no rear relief. That design keeps the blade stiff, which matters because the cut is interrupted.

The larger version of the same idea uses cutter plates from roughly 150 to 600 mm and more teeth per body. Two plates with matching tooth count cut both sides of a tooth space in one pass. Cycle time drops by a factor of two to four against the paired cutter. The trade is setup: plate diameter, tooth count and index timing all have to match the gear being cut.

For small modules under about 6 mm, a facing cutter with four or five blade teeth is common. The blades sit on a concave conical face at roughly 3° 30′, so the cutting edge meets the tooth flank at a shallow angle. That geometry spreads the load and lets the cutter mesh cleanly with the gear teeth it is forming. It is a finishing tool as much as a cutting tool.

Arc-tooth bevel gears use a different family again, often called a Gleason-type cutter. Module range runs about 0.5 to 15 mm and cutter diameters span 12.7 to 457.2 mm. The same body can be ground for roughing or finishing, which is why shops keep a set of bodies and change the blades. Get the blade grind wrong and the tooth contact pattern moves to the toe or the heel of the flank.

• 1
  Paired cutterModule 0.3–20 mm, two flanks per pass, stiff body.
• 2
  Large plate cutterPlates 150–600 mm, two to four times the productivity.
• 3
  Small-module facing cutterModule under 6 mm, 4–5 blade teeth, 3° 30′ cone.
• 4
  Arc-tooth cutterModule 0.5–15 mm, Ø12.7–457.2 mm bodies.

A carbide edge does not fail suddenly. It starts with a wear land on the flank, then a notch at the depth-of-cut line, then chipping. By the time the part measures out of tolerance, the tool has been cutting badly for a while. The cheap way to catch this is to watch the chip colour and the sound. Blue chips on steel mean the edge is running hot. A change in pitch means the edge is dull.

On a production run we log flank wear at fixed intervals. For steel, a 0.2 mm wear land is usually the point to index. For aluminium, the limit is built-up edge rather than wear, and it shows as a rough surface and a size that creeps larger. For 316 stainless, work hardening at the depth-of-cut line is the signal, and the answer is a fresh edge, not a slower speed.

Tool life also depends on the entry. A tool that enters a cut at full radial engagement takes a shock load on every tooth. Ramping in, or using a trochoidal path, spreads that load and can double the life of the same insert. On a 5-axis machine the tool can be tilted into the cut so the contact point moves away from the tip, which is the single biggest life gain on hardened steel.

Reconditioning matters more than most people expect. A reground end mill loses diameter, so the program has to be offset. If the shop does not track that, the first part after a regrind will be undersized. We keep the offset in the tool table and verify with a test cut before the run starts.

• 1
  SteelIndex at 0.2 mm flank wear land.
• 2
  AluminiumWatch for built-up edge, not wear.
• 3
  StainlessChange the edge at the first sign of work hardening.

A new device housing goes through a first-article check. We measure the critical features, compare them to the drawing, and adjust the offsets. If a bore is 0.01 mm out, we do not simply shift the offset and move on. We look at whether the error is consistent along the bore, because a taper means deflection, not a tool size problem.

In-process monitoring runs through the whole job. The operator checks key dimensions at fixed intervals, and the CMM confirms the features that cannot be reached with a micrometer. We inspect 100% of parts before shipment and can supply reports on request. That matters for medical and automotive work, where a traceable measurement is part of the deliverable.

The machine choice follows the feature. A 5-axis center with a Ø400 mm rotary table handles a housing that needs four faces in one setup, which removes the stacked tolerance of four separate operations. A mill-turn center handles a shaft with a turned diameter and a milled flat without a second fixture. The tool for the processing of devices is only as good as the machine and fixture holding it.

We run 127 high-precision CNC machines across three plants, including 16 simultaneous 5-axis centers. Maximum processing size is 4,000 mm, so large frames and long rails fit on the larger travels. Tolerances hold at ±0.005 mm and finishes at Ra 0.2–0.8 μm when the feature allows. Materials run from 6061 and 7075 aluminium to 316L, 17-4PH, Ti-6Al-4V and Inconel.

• 1
  First-article checkMeasure, compare, adjust offsets before the run.
• 2
  In-process checksFixed intervals plus CMM verification.
• 3
  One setup where possible5-axis removes stacked tolerances from multiple fixtures.
