How to Control a CNC Machine Using an Arduino Uno
An Uno can run a small 3-axis router, engraver, or PCB mill as a G-code interpreter — nothing more. This guide covers the wiring, the GRBL settings that matter, and the point where you should stop and buy a real controller.
Key takeaways
What an Arduino Uno Can and Cannot Do
The Uno runs at 16 MHz with 32 KB of flash and 2 KB of RAM. GRBL fits in that space with room for a small planner buffer, which is why it became the default firmware for hobby CNC. The chip outputs step and direction pulses on three axes. It does not push current through a motor.
That split matters when you plan a build. The Uno decides where the tool goes; a stepper driver such as a DRV8825 or TB6600 decides how the coil gets energized. The power supply feeds the driver, not the Uno. Mix those two roles up and you burn a board.
An Uno setup fits a desktop router for wood and acrylic, a laser engraver frame, a PCB mill, or a small 3-axis test rig. These machines cut at low depth per pass and low cutting force. The frame is usually the weak link, not the controller.
It does not fit a machine that has to hold ±0.005 mm on steel or aluminum at production rates. That work needs closed-loop servo control, thermal compensation, and a rigid casting. You will not get there by adding a better stepper driver to an Uno.
- 1Good fitDesktop router, engraver, PCB mill, teaching rig
- 2Bad fitSteel, tight-tolerance aluminum, 4th/5th axis, production runs
Wiring the Uno to Stepper Drivers
Each axis needs two signals from the Uno: a step pulse and a direction level. GRBL maps these to fixed pins on the ATmega328P. X uses D2 for step and D5 for direction, Y uses D3 and D6, Z uses D4 and D7. Enable is shared on D8.
Run those signal wires as short as you can. A step pulse at 30 kHz has a period near 33 µs, and long unshielded runs pick up noise from the spindle or the stepper cables. Keep signal wires away from motor wires, and never bundle them together.
Set the driver current before you connect the motors. A NEMA 17 rated at 1.5 A per phase should be set to about 1.2 A on the driver, which is roughly 80% of the rating. Too high and the motor cooks; too low and it stalls mid-cut.
Power the logic side from the Uno's USB or a separate 5 V supply. Power the drivers from the main supply, 24 V or 36 V for most desktop builds. Share only ground between the two sides.
- 1Step/direction pinsX: D2/D5, Y: D3/D6, Z: D4/D7, enable D8
- 2Current setting80% of rated phase current, measured with a multimeter
- 3Wire routingSignal wires short and separated from motor cables
- 4GroundingCommon ground only; do not tie driver V+ to the 5 V rail
Flashing GRBL and Setting the Motion Parameters
GRBL is uploaded through the Arduino IDE as a sketch. After the flash, the Uno no longer runs your code; it runs G-code. Open a serial terminal at 115200 baud and send $$ to read the settings list. Every value you change goes back with a dollar sign command.
The two settings that decide whether the machine cuts cleanly are max rate ($110–$112) and acceleration ($120–$122). Start conservative. For a belt-driven desktop router, 800 mm/min on X and Y and 300 mm/min on Z is a safe first guess. Acceleration around 50 mm/s² avoids most lost steps.
Steps per millimeter ($100–$102) must match your mechanics. For a 20-tooth GT2 pulley, one revolution moves 40 mm. A 200-step motor at 1/8 microstepping gives 1,600 steps per revolution, so 40 steps per mm. Get this wrong and every dimension on the part is wrong by the same ratio.
Set the step pulse time ($0) to 10 µs for most modern drivers. Older drivers may need 5 µs or more. If the motor buzzes and does not move, this value is the first thing to raise.
- 1$100–$102Steps per mm; verify against pulley pitch and microstep setting
- 2$110–$112Max rate per axis; start low, raise in 10% steps
- 3$120–$122Acceleration; 50 mm/s² is a reasonable desktop starting point
- 4$0Step pulse time; 10 µs works for most modern drivers
Jogging, Homing, and the First Air Cut
Before any tool touches material, jog each axis by hand through the serial console. Send G91 for relative mode, then G0 X10 F500. The axis should move 10 mm and stop. Measure it with calipers. If it moved 12 mm, your steps per mm is off by 20%.
Homing comes next. Switches on each axis let GRBL find machine zero. Wire them normally closed to the limit pins on D9, D10, and D11. Send $H and watch the pull-off distance ($27). A homing cycle that slams into the switch and skips means the pull-off is too short or the switch is bouncing.
Run the first cut in air. Load your G-code, zero the work offset, and raise Z by 20 mm. Watch the motion. Jerky acceleration, missing steps at direction changes, and audible stalls all show up here before they cost you a part.
Only after the air cut looks smooth do you touch material. Start with a shallow pass, 0.3 mm depth in wood or 0.1 mm in aluminum, and increase from there. If the machine loses position, drop the acceleration before you drop the feed.
- 1Verify travelJog 10 mm and measure with calipers before trusting the setup
- 2HomingNormally closed switches on D9–D11; check pull-off distance
- 3Air cutRaise Z 20 mm, confirm smooth motion, then cut
Step by Step: From Bare Uno to First Part
- 1Mount the Uno and drivers on a boardKeep the Uno away from the drivers so heat does not reach the regulator. Use a perfboard or a shield rather than loose jumper wires; a loose step wire mid-cut ruins the part.
- 2Wire step, direction, and enableX: D2/D5, Y: D3/D6, Z: D4/D7, enable D8. Keep signal wires under 300 mm and route them away from motor cables.
- 3Set driver current and microsteppingSet current to 80% of the motor's rated phase current. Choose 1/8 microstepping as a default; it balances smoothness against the 30 kHz pulse ceiling.
- 4Flash GRBL and connect at 115200 baudUpload the sketch, open the serial monitor, and send $$ to confirm the board responds. If you get no reply, check the baud rate and the COM port.
- 5Enter steps per mm and limitsCompute steps per mm from pulley pitch and microstep. Set $100–$102, then set $130–$132 to the real travel of each axis so the machine cannot crash into its own frame.
- 6Tune max rate and accelerationStart at 800 mm/min and 50 mm/s². Jog each axis at full speed. Raise the rate in 10% steps until steps are lost, then back off 20%.
- 7Home the machine and set work zeroSend $H, confirm all three axes pull off their switches, then set your work offset with G10 or the sender's zero button.
- 8Run an air cut, then cut materialRaise Z 20 mm and run the full program. When the motion is smooth, cut at 0.3 mm depth in wood or 0.1 mm in aluminum and adjust from there.
Arduino Uno vs Dedicated CNC Controller
Use this to decide which path fits the part you need to make.
| Factor | Arduino Uno + GRBL | Dedicated CNC controller |
|---|---|---|
| Axes | 3 axes, no simultaneous 4th | 3 to 5 axes, simultaneous |
| Step rate | About 30 kHz ceiling | 100 kHz and higher |
| Feedback | Open loop, no position check | Closed loop with encoder feedback |
| Typical material | Wood, acrylic, FR-4, light aluminum | Steel, titanium, tight-tolerance aluminum |
| Tolerance | Frame-limited, often ±0.1 mm | ±0.005 mm on a rigid machine |
| Best use | Prototype, teaching, hobby build | Production parts and repeat orders |
| Cost of entry | Low, parts are off the shelf | Higher, but predictable output |
| When it fails | Lost steps show up as scrap | Faults stop the cycle before scrap |
Know Where the Uno Stops
An Arduino Uno is a fine way to learn motion control and a poor way to hold a tolerance. When the part has to fit, machine it.
Frequently Asked Questions
Can an Arduino Uno run a 4-axis CNC?
Not with standard GRBL. The ATmega328P does not have the pin budget or the processing headroom for a reliable 4th axis alongside three moving axes.
If you need rotary work, move to a 32-bit board running a Grbl-based fork, or use a dedicated controller. Trying to squeeze a 4th axis onto an Uno usually shows up as random lost steps on the other three.
Why does my stepper hum but not turn?
The most common cause is a step pulse that is too short for the driver, or a direction pin that is floating. Raise $0 to 10 µs and check that the direction wire is seated.
Second cause: driver current set too low. Measure the reference voltage on the driver and set it to 80% of the motor's rated phase current. A motor that holds position but will not rotate is usually undercurrent, not a firmware problem.
How fast can an Uno-based router cut aluminum?
Slowly, and only in light passes. Expect 0.1–0.3 mm depth per pass with a 3 mm single-flute end mill at 8,000–12,000 rpm, and a feed around 300–500 mm/min.
The limit is the frame and the spindle, not the Uno. A machine that flexes under cutting load will chatter no matter how good the controller is. If the part has a tolerance tighter than ±0.1 mm, this is not the right process.
Do I need limit switches?
They are not strictly required to make the machine move, but you should fit them. Without homing, the machine has no repeatable zero, so every setup starts from wherever the axes happened to be.
Wire them normally closed so a broken wire reads as a triggered switch rather than a silent failure. That single choice prevents most crash damage on a hobby build.
What power supply should I use?
24 V is the safe default for NEMA 17 motors on a desktop router. A 36 V supply gives more torque at speed if the drivers are rated for it.
Size the current at roughly 70% of the total motor current, not the full sum. Motors rarely draw rated current on all axes at once, and an oversized supply just adds heat and cost.
When should I stop building and order machined parts?
When the part has to hold a tolerance, fit an existing assembly, or repeat across more than a handful of units. An Uno router is a good way to learn motion control and a poor way to make a delivery deadline.
For functional prototypes and low-volume runs, machining from billet gives you the tolerance and the material properties in one step. Send the CAD file and we will review it for manufacturability before quoting.
