Both routes build a part layer by layer. The difference is how the plastic arrives at the machine. Filament is a spool of 1.75 mm or 2.85 mm strand that a heated nozzle melts and lays down. Particles are a bed of powder, typically 20–100 μm grains, that is fused by a laser, a heat source or a binder. That single difference drives everything else: wall thickness, support strategy, surface finish and cost curve.

Filament machines are cheap to run and easy to swap materials on. A spool change takes minutes. Powder machines need a full bed, a controlled atmosphere and a cool-down period, so the setup cost is spread over the build volume. That is why powder processes make sense when you fill the bed, and filament makes sense when you need one part tomorrow.

Neither route is a precision process by default. An FDM part fresh off the plate holds roughly ±0.3 mm on a good day, and powder parts land near ±0.2 mm. If your drawing says ±0.05 mm, printing is the wrong final step. Print the shape, then machine the critical faces.

• 1
  Filament = one nozzle pathSupports must be printed and broken off. Overhangs beyond 45° need help.
• 2
  Particles = self-supporting bedThe surrounding powder holds overhangs, so internal channels and lattices are possible.
• 3
  Anisotropy is realFDM parts are weaker across layer lines. Powder parts are closer to isotropic.

PLA is the starting point for form-and-fit checks. It prints cold, warps little and holds detail. It also creeps under sustained load and softens near 60 °C, so do not use it for a bracket that lives in a car interior or near a motor. Good for a display model, a mold for vacuum casting, a quick fixture that sees no heat.

ABS and ASA take more heat and more impact. They shrink as they cool, which pulls corners off the plate, so you need an enclosed machine and a warm chamber. ASA adds UV resistance over ABS, which matters for outdoor housings. If you print ABS on an open machine, expect warped edges and delamination between layers.

PETG sits between the two. It has better chemical resistance than PLA and better toughness, with less warping than ABS. It strings, so tune retraction. Use it for jigs, fluid-adjacent parts and anything that needs to survive a drop test without shattering.

TPU is the flexible option. Shore hardness runs from about 85A down to 95A on common spools, and softer grades need a direct-drive extruder because the filament buckles in a long Bowden path. Print slow, 15–25 mm/s, and keep the layer height above 0.15 mm so the layers bond. Gaskets, seals, grippers and bumpers are the usual fits.

Nylon brings strength and abrasion resistance. It absorbs moisture fast, so dry it and print from a dry box, otherwise you get pops, voids and poor layer strength. PA12 in powder form is the same family and is far easier to run, which is why SLS and MJF nylon parts dominate functional prototypes.

For higher demands there is PEEK and PEI, plus carbon-filled grades. These need hot ends above 350 °C and a heated chamber. They are worth it only when the part sees high temperature, steam or aggressive chemistry. Otherwise you pay a lot for headroom you never use.

• 1
  PLACheap, stiff, low heat. Display and fit-check parts only.
• 2
  ABS / ASAEnclosure required. ASA for outdoor UV exposure.
• 3
  PETGTougher than PLA, easier than ABS. Good general utility part.
• 4
  TPUFlexible seals and grips. Print slow, direct drive.

Chopped carbon and glass fiber are blended into filament to raise stiffness and lower thermal expansion. A 15–20% carbon fill can lift the modulus noticeably, which helps a fixture resist deflection. The trade-off is impact strength: the same part becomes more brittle and snaps instead of bending. It also wears out a brass nozzle quickly, so use hardened steel.

Metal and ceramic powders go into filament and into binder-jet feedstock. Metal-filled filament prints like plastic and sinters in a furnace, shrinking around 15–20%. You gain metal-like feel and density, but you also inherit furnace distortion and a size limit set by your kiln. For a truly metal part at tight tolerance, casting or CNC is usually the shorter path.

In powder bed processes the powder is the part, not an additive. Particle size distribution and sphericity control flow and packing, which in turn set density and surface finish. Reused powder changes that distribution, so track virgin-to-reused ratios. Skipping that step is a common cause of drifting mechanical properties between builds.

• 1
  Carbon fillStiffer, more brittle, abrasive. Hardened nozzle required.
• 2
  Glass fillCheaper stiffness boost, rougher surface, still abrasive.
• 3
  Metal fillSintering shrink near 15–20%. Design allowance needed.

State the function before the material. A cover that hides a connector needs surface finish and color, not tensile strength. A load-bearing arm needs a stress direction and an operating temperature. When the drawing leads with function, the supplier can propose a material instead of guessing.

Name the critical features and their tolerance separately. Mark the bearing bore, the sealing face and the mating hole. Leave the cosmetic surfaces to the print process and machine only what matters. This is the single biggest cost lever: machining three faces is far cheaper than machining a whole shell.

Call out the environment: indoor, outdoor UV, fuel contact, steam, salt spray. ABS and ASA behave very differently after a summer outdoors. Nylon absorbs water and swells, which closes a clearance you thought was safe. Say it in the notes.

Set the inspection expectation up front. If you need dimensional reports, first-article inspection or material certificates, put it in the RFQ. Asking after the parts ship adds days and cost. For regulated work, confirm the quality system covers your sector before the order, not after.

• 1
  Function firstLoad, temperature and exposure drive the polymer choice.
• 2
  Tolerance by featureMark only the faces that need tight control.
• 3
  Environment in the notesUV, chemicals and moisture change material behavior.
• 4
  Inspection in the RFQReports and certificates asked late delay the shipment.

Tolerance capability comes first. Ask what the shop actually holds on your geometry, not the marketing number on the homepage. A shop that runs both printing and CNC can print the blank and machine the critical faces, which is often the only way to hit ±0.005 mm on a plastic part without a mold.

Lead time should be quoted by step, not as one number. Printing, machining, finishing and inspection each carry their own queue. A quote that says 3–5 days for parts without naming the steps is hard to plan around. Ask what happens if a build fails overnight.

Minimum order quantity matters more than unit price at the prototype stage. A supplier with no MOQ lets you order one part, test it, and change the design without wasting tooling. That flexibility usually beats a lower per-part price on a run of fifty.

Certifications decide whether you can sell the part. ISO 9001 covers general quality management, IATF 16949 covers automotive, ISO 13485 covers medical devices and ISO 27001 covers information security. If your customer audits your supply chain, the certificate has to match the sector.

Confidentiality is a buying criterion too. Uploads and drawings carry your design intent. Ask for an NDA before sending the CAD, and confirm the files are stored on controlled systems rather than a shared drive.

• 1
  Tolerance evidenceAsk for measured results on a similar part, not a spec sheet.
• 2
  Step-by-step lead timePrint, machine, finish and inspect quoted separately.
• 3
  No MOQOne-off prototypes stay affordable and easy to revise.
• 4
  Sector certificationMatch the certificate to automotive, medical or general industry.

The most expensive mistake is treating a printed part as a finished part. Layer lines are stress risers, powder surfaces are porous, and neither process holds a bearing fit without reaming. If the design has a press fit or a seal groove, budget the machining step from the start.

The second is ignoring anisotropy. A printed bracket tested flat on a bench can pass and then fail in service because the load runs across the layer lines. Orient the part so the main load runs along the layers, or add material where the layers separate.

The third is picking material from a sample box. A glossy PLA coupon tells you nothing about a part that will sit in an engine bay. Match the coupon to the real environment: same temperature, same exposure, same load direction.

Finally, do not send a final drawing before the process is fixed. Printing and machining need different allowances, wall thicknesses and corner radii. Agree on the route first, then release the model that suits it.

• 1
  Printed is not finishedAdd machining for fits, bores and sealing faces.
• 2
  Load direction mattersOrient layers so the main stress runs along them.
• 3
  Test in the real environmentTemperature and UV change the answer.
• 4
  Fix the process firstDifferent routes need different design allowances.
