FFF 3D Printing Material ABS: How It Beha
ABS is styrene-based, so it shrinks as it cools and releases fumes while it prints. This page covers what happens inside the nozzle and on the bed, which geometries survive FFF 3D printing material ABS without lifting, and when a machined or cast part is the cheaper answer.
In this article
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
What ABS actually is
ABS stands for acrylonitrile butadiene styrene. Three monomers give three properties: acrylonitrile adds heat and chemical resistance, butadiene adds impact toughness, and styrene keeps the melt flowable and the surface glossy. That combination is why the material shows up in automotive interior trim, appliance housings and power-tool shells.
The trade-off sits in the butadiene phase. It absorbs impact well, but it also carries a double bond that UV light and oxygen attack over time. Yellowing and surface chalking after months outdoors are normal for unstabilized ABS, not a printing defect.
In filament form the polymer is amorphous, so it has no sharp melting point. It softens gradually, which is why a heated chamber helps more than a few extra degrees at the nozzle. A typical spool prints between 240 and 260 °C with the bed at 100 to 110 °C.
- 1DensityAbout 1.04 g/cm³, roughly 25 percent lighter than aluminum
- 2Heat deflectionSoftens near 90–100 °C; keep it away from hot engine bays
- 3Solvent responseDissolves in acetone, bonds with acetone or MEK slurry
Why ABS parts warp and lift
Every deposited bead cools from roughly 250 °C to room temperature. ABS contracts about 0.5 to 0.8 percent, and the contraction is not uniform: the extruder pulls the bead along its length while it is still soft, so the part shrinks more in the XY plane than in Z. A 200 mm long bracket can lose 1.2 mm or more across its length.
Warping starts when the lower layers have already cooled and stiffened while the upper layers still want to contract. The cooled layers resist, stress builds at the corners, and the part peels off the bed. Tall, flat, sharp-cornered geometry is the worst case. Round corners and a smaller footprint help.
Bed adhesion matters less than people assume. If the chamber air is cold, a perfect first layer still lifts by layer 40. Heat the enclosure first, then worry about the surface.
Moisture makes it worse. Wet filament flashes to steam at the nozzle, leaves voids in the bead, and reduces the bond between layers. Dry ABS at 70 to 80 °C for 3 to 4 hours before a long print.
- 1Sharp cornersAdd a 2–3 mm chamfer or fillet to spread the stress
- 2Long thin partsOrient the longest axis in Z or split the part
- 3Large flat facesUse a brim and a raft-free, glue-assisted bed
Print settings that keep ABS flat
Start with the enclosure. ABS wants still, warm air around the part, not a draft. Close the machine, let the chamber soak at 40 to 60 °C, and leave the door shut until the print finishes. Opening the door mid-print is the most common cause of a split along the layer lines.
Bed choice matters for release as much as for grip. A PEI sheet at 100 to 110 °C holds ABS well; a light glue stick layer adds release insurance on large footprints. Garolite and ABS slurry also work but need more cleanup. Glass with hairspray is the old shop standby and still functions.
Keep the cooling fan low. Zero to 30 percent is enough to firm up overhangs; full blast on a 0.2 mm layer will delaminate the part before it finishes. If corners look rounded, raise the fan. If the wall splits, drop it.
Post the first layer carefully. A 0.25 mm first layer at 105 °C with a slow first-layer speed gives the bead time to press into the bed texture. That single layer sets the flatness of everything above it.
Which parts suit FFF 3D printing material ABS
ABS earns its place on functional prototypes that need toughness and a bit of heat resistance, not on parts that must hold ±0.05 mm. An FFF machine with a 0.4 mm nozzle holds roughly ±0.3 mm on a 100 mm dimension when the shrink is compensated correctly, and worse on tall thin walls. If your drawing calls for ±0.005 mm, that is a machining job.
Good candidates share a few traits: wall thickness of 2 mm or more, no unsupported spans longer than about 20 mm, and a footprint that is not a large thin plate. Enclosures, brackets, jigs, ducting and covers usually print clean. Long rails and wide flat panels usually lift.
Threaded features are possible but weak. A printed M6 thread strips under hand torque. Design a pilot hole and cut the thread with a tap, or bond in a metal insert with a soldering iron at 200 to 220 °C.
If the part needs to be watertight or carry load, plan for a machined or vacuum-cast version. Printed ABS is porous along the layer seams and creeps under sustained load, especially above 60 °C.
Acetone smoothing, bonding and painting
Acetone vapor smoothing dissolves the outer bead ridges and leaves a glossy skin. Cold vapor at room temperature works in 10 to 20 minutes; warm vapor is faster but deforms thin walls and rounds sharp edges. Mask any feature that must stay dimensionally tight, because the process removes 0.05 to 0.15 mm of surface.
For bonding, a slurry of ABS offcuts dissolved in acetone makes a gap-filling cement that cures in a few hours. MEK works faster but is harsher on the operator and on the part. Clamp joints while they cure, or they will pull apart as the solvent leaves.
Paint adhesion on raw ABS is fair. Scuff with 400 grit, wipe with isopropyl alcohol, and use a primer made for plastics. Skip the primer and the topcoat will flake at the edges within weeks.
Solvent processes need ventilation and nitrile gloves. Acetone vapor is heavier than air and collects in low spots. Work in a hood or outdoors, never in a closed room.
Step by step: from model to finished ABS part
A sequence that reduces scrap on the first attempt
- 1Dry the filament70–80 °C for 3–4 hours. Store with desiccant between runs.
- 2Scale the modelApply 0.5–0.8 percent shrink compensation on X and Y for tight fits.
- 3Choose orientationPut the longest dimension in Z to cut XY shrink, or split the part.
- 4Preheat the chamberSoak at 40–60 °C for 15–20 minutes before the first layer.
- 5Set the first layer0.25 mm at 105 °C bed, 20 mm/s, 105 percent extrusion width.
- 6Print with low fan0–30 percent cooling; leave the enclosure closed throughout.
- 7Cool slowlyLet the chamber drop to 35 °C before removing the build plate.
- 8Finish if neededVapor-smooth with acetone, or sand and prime before paint.
FFF 3D printing material ABS settings and their effect
Ranges that work on a 0.4 mm nozzle with a heated chamber
| Parameter | Starting range | What it controls |
|---|---|---|
| Nozzle temperature | 240–260 °C | Layer bond strength and surface finish |
| Bed temperature | 100–110 °C | First-layer stick and base flatness |
| Chamber temperature | 40–60 °C | Warp risk on tall or long parts |
| Layer height | 0.15–0.25 mm | Print time versus Z strength |
| Part cooling fan | 0–30 percent | Corner sharpness versus delamination |
| Print speed | 40–60 mm/s | Bead cooling rate and shrink stress |
| Linear shrink allowance | 0.5–0.8 percent | Model scale before the print starts |
When ABS printing is the right call
Match the process to the quantity and tolerance, not to habit
| Requirement | FFF ABS | Better alternative |
|---|---|---|
| 1–20 functional prototypes | Good fit, days of turnaround | Keep it in FFF |
| Tolerance tighter than ±0.1 mm | Not achievable | CNC machining at ±0.005 mm |
| Large thin flat panel | High warp risk | Sheet metal or CNC |
| Smooth painted housing, 50+ units | Slow and labor-intensive | Vacuum casting in a silicone mold |
| Heat above 90 °C | Softens and creeps | PC, PEEK or machined aluminum |
| Snap fits and impact covers | Tough and cheap to iterate | Keep it in FFF |
The short verdict
If the part is a tough enclosure or bracket that only has to fit, print it in ABS and iterate. If it has to hold a tolerance, carry load or sit above 90 °C, machine it or cast it instead.
Questions engineers ask
Can ABS be printed without an enclosure?
Small parts with a footprint under about 60 mm often print fine on an open machine with a 100 °C bed and a brim. Anything taller than 50 mm or longer than 100 mm will usually lift at the corners.
A cardboard box over the printer is a real fix in a pinch. It holds enough warm air to get most parts through.
How much shrink should I compensate for?
Start at 0.6 percent on X and Y and leave Z alone. Measure the first part across a known length, then adjust: if a 150 mm dimension comes out at 149.2 mm, the real shrink is about 0.53 percent.
Corner features shrink more than the middle of a wall. For mating parts, print a test coupon before committing to the full run.
Is printed ABS food safe or skin safe?
No. The layer seams harbor bacteria and the material contains residual styrene monomer. Do not use it for food contact, drinking water or prolonged skin contact.
If the application is medical, the part belongs in a certified material and process, not in desktop FFF.
Can I machine a printed ABS part afterward?
Yes, with light cuts. ABS machines like a soft plastic: high spindle speed, sharp two-flute tooling, and shallow depths of cut around 0.3 mm. Heat builds fast at the tool tip and will smear the surface.
Drilling and tapping printed parts works if you use a pilot hole and keep the hole away from layer seams. Expect the hole to close slightly after drilling.
How does ABS compare with ASA?
ASA swaps the butadiene for a more UV-stable rubber phase, so it resists yellowing outdoors. Print settings are nearly identical, and ASA warps slightly less on large parts.
For indoor parts the two behave the same. For anything that sees sunlight, ASA is the safer choice.
What does GreatLight do with ABS parts after printing?
We print prototypes and low-volume functional parts in ABS, then finish them as needed: vapor smoothing, sanding, priming or painting. Where the design needs tighter tolerance or a production material, we move the same geometry onto CNC machining or vacuum casting.
Uploads stay confidential, and an NDA is available on request.
