On an OD turning pass, the cutting edge enters the workpiece at a single point. That point sits where the lead angle, the nose radius, and the depth of cut meet. Move any one of them and the direction of the cutting force changes. A 90° lead angle pushes most of the force axially, along the part axis. A 45° lead angle splits the force between axial and radial directions, so the tool pushes the part away from the centerline more.

That split matters on long, slender parts. Radial force bends the workpiece, and a bent workpiece cuts oversize in the middle. On a shaft with a length-to-diameter ratio above 6, a 90° or 95° lead angle is usually the safer starting point because it keeps radial force low. On a short, stiff hub, a 45° lead angle spreads the load and lets you take a deeper pass without chattering.

The nose radius sets the finish. A larger radius, say 0.8 mm, leaves a smoother surface at the same feed because the scallop height between passes drops. A smaller radius, 0.2–0.4 mm, cuts cleaner on light finishing passes and reaches into fillets and shoulders that a big radius cannot. The trade is strength: a 0.2 mm radius chips and breaks under heavy interrupted cuts, while 0.8 mm survives them.

Cutting speed and feed follow the same logic. For aluminum 6061, OD turning commonly runs 200–400 m/min surface speed with 0.15–0.3 mm/rev feed for roughing. For 316L stainless, drop to 120–180 m/min and 0.1–0.25 mm/rev, and keep the tool engaged. Rubbing is what kills the edge, not the speed itself.

A negative rake insert has a strong edge, often double-sided, and costs less per edge over a production run. It needs more spindle power and a rigid setup because it cuts with a blunter wedge. On a 4,000 mm maximum processing size lathe cutting 4140 steel, a negative insert at 0.3 mm/rev is a normal roughing choice. The same insert on a small 500 mm machine will stall or chatter.

A positive rake insert is sharp. It cuts with less force, which helps on thin-wall tubes, on small-diameter stock, and on low-power machines. The limit is depth of cut. Positive inserts generally do not take the same depth as negative ones, so you run more passes. On a light finishing pass, a positive insert can hold Ra 0.8–1.6 μm without a separate wiper.

The decision is not about which is better. It is about which force the part can absorb. A rigid cast iron housing can take a negative insert. A 1.5 mm wall aluminum tube cannot. When in doubt, start positive, measure the deflection, and move to negative only when the setup proves stiff.

Coated grades follow the material, not the shape. CVD coatings for steel and cast iron, PVD for stainless, titanium, and interrupted cuts. Keep aluminum uncoated or use a polished PVD grade to stop built-up edge.

Facing uses the same geometry but the cut runs from the OD toward the center, or center to outside on the last pass. When the finish matters, the final facing cut should run from the center outward. That direction lets the tool exit at the OD, where a small burr is easy to remove, instead of leaving a nub at the center.

Boring is the harder operation. The tool hangs out over a length that grows as the bore deepens, so the boring bar deflects. A bar with a length-to-diameter ratio above 4 will sing. The usual fix is a larger bar, a carbide shank, or a tuned boring head. Reducing depth of cut and increasing speed does not solve a bar that is simply too long.

Inside a bore you cannot see the cut. Chip evacuation is the real limit, not the insert. On a blind hole, a through-coolant bar and a pecking pattern of 0.5–1.0 mm per peck keeps chips from packing. Packed chips rub the insert, raise the temperature, and smear the finish.

Boring also mirrors OD geometry: a 90° lead angle bar pushes axially and keeps radial force low, which suits deep holes. A 45° bar cuts freer but pushes the bar sideways. Deep bore, shallow bore, through hole, blind hole. Each one points to a different bar before it points to a different insert.

Roughing removes material. Finishing controls the surface. Mixing them on one pass usually fails. A typical sequence for steel is 2.0–3.0 mm depth for roughing, then 0.3–0.5 mm for semi-finish, then 0.1–0.2 mm for the finish pass. The finishing pass should be shallow enough that the nose radius, not the depth, defines the surface.

Feed and nose radius set the theoretical roughness. At 0.1 mm/rev with a 0.8 mm nose radius, the scallop height stays near Ra 0.8 μm. Push the feed to 0.3 mm/rev with the same radius and the finish degrades to roughly Ra 3.2 μm. That is fine for a roughing pass but not for a sealing surface.

Chatter is the most common failure at the external circumferential turning point. Symptoms are a regular pattern on the surface and a rising noise. Causes are tool overhang, a loose insert, worn jaws, or a speed that matches a natural frequency of the setup. Fixes are shorter overhang, a heavier bar, a different speed, or a different lead angle.

Coolant depends on the material. Flood coolant for stainless and steel to control heat. For aluminum, high-pressure coolant clears chips and stops built-up edge. For cast iron, dry cutting with air blast is often cleaner because the chips are dry and the graphite dust does not turn into a slurry.

Aluminum 6061 and 7075 cut fast with sharp positive inserts and high rake. 7075 is stronger and more abrasive, so edge wear shows sooner. Keep speeds high, feeds moderate, and clear chips. A built-up edge on aluminum looks like a rough, torn surface, and the cure is a sharper, polished insert, not a slower speed.

Stainless 303 and 304 work-harden. If the tool rubs, the surface hardens and the next pass cuts through a harder skin. The rule is to keep the insert engaged and never dwell. Feeds below 0.08 mm/rev on stainless invite work-hardening, so stay above that on finishing passes.

Titanium Ti-6Al-4V and Inconel generate heat at the edge and conduct it poorly. Speeds drop to 40–80 m/min for titanium and 25–50 m/min for Inconel. Rigid setups, sharp positive inserts, and generous coolant are the standard approach. Any chatter on these alloys cracks the edge quickly.

Plastics and copper behave differently again. POM and PEEK need sharp, polished tools and high speed to shear cleanly. Copper and brass turn freely, but soft copper can grab the tool, so a small nose radius and a positive rake help. The material dictates the geometry more than the machine does.
