A vertical mill holds the spindle upright and the workpiece on a table below it. The operator can see the cut, which makes it the default choice for plates, housings and brackets with pockets, slots and drilled holes on one face. On our 3-axis machines the travels reach 750 × 1,150 × 550 mm, enough for most enclosure and manifold work.

A horizontal mill turns the spindle sideways. Chips fall away from the cut instead of piling up in the pocket, so the tool can take heavier depths of cut on flat faces and long edges. This is why horizontal work suits thick blocks, gearbox bodies and parts where a lot of material has to come off one plane before any feature is finished.

Five-axis machining adds two rotary axes to the three linear ones. A trunnion table or a swivel head tilts the tool or the part, so an undercut, a drafted wall or a compound angle can be reached without re-fixturing. On a 16-station simultaneous 5-axis center we cut impeller blades, turbine housings and medical instruments in a single setup.

The trade-off is programming time and machine cost. A 5-axis toolpath needs collision checking and a postprocessor that matches the exact machine kinematics. If a part has three flat faces and a dozen holes, a 3-axis job with two soft jaws will usually be faster and cheaper. If it has a curved surface meeting a drilled hole at an oblique angle, 5-axis is often the only way to hold position between them.

• 1
  3-axisFlat faces, pockets, through holes, one dominant direction of access.
• 2
  4-axisCylindrical parts with features on the circumference; rotary table Ø400 mm.
• 3
  5-axisContoured surfaces, undercuts, compound angles, tight true position between features.

It starts with a drawing review. We check the tolerance stack, the datum scheme and any feature that cannot be reached with a standard tool. A free DFM analysis comes back within 12 hours with notes on wall thickness, corner radii and callouts that will drive cost without adding function.

Then comes programming and workholding. The CAM file sets tool paths, stepover and feed per tooth. Soft jaws, a vacuum plate or a custom fixture hold the part without distorting it. Thin walls move when you clamp them, so the clamping force and the order of cuts matter as much as the cutter itself.

Roughing removes the bulk of the material and leaves a controlled allowance for finishing. On aluminium 6061 we typically run carbide end mills at 3,000–8,000 rpm depending on diameter, with a 0.3–0.5 mm finishing allowance. Finishing then brings the surface to the drawing: Ra 1.6–3.2 μm as machined, Ra 0.8–1.6 μm with a finer stepover, Ra 0.2–0.8 μm after an extra pass on a stable setup.

Inspection closes the loop. We check raw material certificates before the first cut, monitor dimensions in process, and inspect 100% before shipment. Reports come on request. If a dimension drifts, the offset is corrected in the control rather than blamed on the material.

Production can start within 24 hours of a released order, and parts usually ship in 3–5 days. That window assumes the drawing is frozen; a late engineering change resets the fixture and the first-article check.

• 1
  Drawing reviewDatum scheme, tolerance stack, tool access, DFM notes within 12 hours.
• 2
  SetupSoft jaws or custom fixture; clamping force matched to wall thickness.
• 3
  Rough and finishControlled allowance, then a finishing pass at the specified surface finish.

Aluminium is the easy one. Grades 6061, 6061-T6, 7075 and 6082 cut fast, hold a good finish and rarely need coolant. 7075 gives higher strength for aerospace brackets but is less forgiving of poor chip evacuation. 2024 behaves differently again and needs sharper tools to avoid built-up edge.

Stainless steels 303, 304, 316 and 316L work-harden if the tool rubs instead of cutting. The rule is a constant feed with no dwell, a rigid setup and plenty of coolant. 17-4PH (SUS630) machines well in the solution-treated condition and is often chosen for medical and aerospace parts that need both strength and corrosion resistance.

Steel grades 1018, 1045 and 4140 are common for shafts, plates and fixtures. Pre-hardened 4140 at 28–32 HRC still cuts with carbide but pushes tool life down. Titanium TC4 (Ti-6Al-4V) and Inconel are the slow end of the range: low cutting speeds, high heat at the edge, and a tool change budget that belongs in the quote.

Plastics behave on a different axis. POM and PA machine cleanly, ABS and PC can gum up if the feed is too light, and PEEK needs sharp tools and a clean setup because the material cost punishes scrap. Carbon fibre is abrasive and the dust has to be controlled.

The point is that material choice changes the process, not just the price. A 0.05 mm wall in aluminium is routine. The same wall in titanium is a different conversation about deflection and chatter.

• 1
  Aluminium6061, 7075, 6082; fast, dry, good finish, low tool wear.
• 2
  Stainless303, 304, 316L, 17-4PH; constant feed, coolant, no rubbing.
• 3
  Titanium and nickel alloysTC4, Inconel; low speed, high heat, short tool life, higher cost.

Aerospace work tends to be low volume and high documentation. Brackets, housings and structural fittings are often machined from solid billet in 7075 or 17-4PH, with true position between bolt holes held tight so the part lines up on assembly without reaming on the floor. Five-axis setups reduce the number of times the datum moves.

Automotive and EV parts sit at the other end. Engine components, transmission housings, battery tray brackets and motor mounts run in larger batches where cycle time matters. Horizontal mills with pallet changers keep the spindle cutting while a finished part is swapped out. IATF 16949:2016 procedures cover the traceability side.

Medical devices are usually small, stainless or titanium, and inspected feature by feature. Surgical instruments, implant trials and fluid manifolds often need Ra 0.8 μm or finer on contact surfaces. ISO 13485:2016 governs the process documentation, and every part is measured before it ships.

Electronics work is mostly enclosures, heat sinks and connector bodies in aluminium or copper. Thin walls, fine slots and flatness are the usual trouble spots. A 0.8 mm wall in 6061 is routine if the fixture supports it; the same wall unsupported will chatter.

Robotics, industrial machinery and new energy parts share a pattern: moderate volume, mixed materials, and a need for repeatability across runs. That is where a documented setup sheet and a stable fixture pay for themselves.

• 1
  AerospaceSolid billet parts, tight true position, 5-axis to limit re-fixturing.
• 2
  Automotive and EVHousings and brackets in batches; horizontal mills, pallet changing.
• 3
  MedicalSmall stainless and titanium parts, fine finish, full inspection.
