The process starts with a 3D CAD model, and most of the cost is already locked in at that point. Before programming, we check three things: can the tool reach the feature, can the part be held while it is cut, and can the feature be measured afterward. If any answer is no, the design needs a change, not a tighter tolerance.

Internal corners are the most common problem. An end mill leaves a radius equal to its own radius, so a 6 mm cutter cannot produce a sharp 90° internal corner. Specify the largest corner radius the function allows, and tell us the cutter size you expect. A R3 corner is cheap; a R0.5 corner in a 40 mm deep pocket needs a long, thin tool and slow feed rates.

Wall thickness matters too. For aluminum, walls below 0.8 mm tend to deflect under cutting force. For stainless and titanium, keep walls above 1.5 mm where possible. Thin floors behave the same way: a 0.5 mm floor in a 50 mm pocket will chatter unless we support it from below.

Finally, pick datums that a machinist can actually touch. A datum on a curved surface or an internal bore forces us to build special fixtures. A flat face plus two holes gives us a repeatable zero point and keeps setup time short.

• 1
  Corner radiusMatch the radius to the largest end mill that fits the pocket depth.
• 2
  Wall thicknessAluminum above 0.8 mm, stainless and titanium above 1.5 mm.
• 3
  Tapped holesGive thread depth equal to 1.5× the nominal diameter.
• 4
  Deburring accessLeave room for a tool or a brush to reach every edge.

CAM software converts the solid model into G-code. The programmer chooses stock size, work coordinate system, tool list, stepover, stepdown, spindle speed and feed rate. Two programmers can produce the same part with cycle times that differ by 30%, so this stage deserves as much review as the drawing.

Tool selection drives everything else. A 12 mm end mill removes bulk material fast, but it cannot enter a 10 mm slot. Roughing with the largest tool that fits, then switching to a smaller tool for detail, usually beats one medium tool doing both jobs. We keep the tool list short where possible, because every tool change adds seconds and every extra tool adds a place for error.

Feed and speed come from the material, not from habit. In 6061 aluminum, surface speeds of 300–500 m/min are normal with carbide. In 304 stainless, drop to 100–150 m/min. In Ti-6Al-4V, stay near 40–60 m/min and use plenty of coolant. Running aluminum parameters in titanium burns tools within minutes.

Roughing passes should leave a consistent 0.3–0.5 mm of stock for finishing. Uneven stock makes the finishing cutter deflect, and the wall goes out of tolerance. We check the simulation for gouges and for any rapid move that passes through the part.

• 1
  Largest tool firstClear bulk with the biggest cutter that reaches the pocket.
• 2
  Constant stockLeave 0.3–0.5 mm on all faces before finishing.
• 3
  Simulate every programCheck for gouges, collisions and unreachable areas.
• 4
  Document the setupTool numbers, offsets and zero points belong on the setup sheet.

Workholding is where good programs fail. A part that moves 0.05 mm during cutting will not hold ±0.005 mm regardless of how good the toolpath is. We match the fixture to the part: a standard vise for blocky parts, soft jaws for round or fragile ones, a vacuum table for thin plates, and a 5-axis trunnion for parts with features on many faces.

Clamping force is a trade-off. Too little and the part lifts; too much and a thin wall springs back after unclamping. For a 2 mm aluminum wall, we often clamp on a thick boss and machine the wall last, so the wall is never loaded. For plastic parts, light clamping plus a support underneath usually works better than heavy clamping alone.

Setup count has a direct cost. Every additional setup adds a datum transfer, a probe cycle, and a chance for error. A part that needs four 3-axis setups is often cheaper as one 5-axis setup, even at a higher hourly rate. We compare both routes before quoting.

Zero-point systems pay for themselves on repeat orders. Once a fixture plate is dialed in, the next batch loads in minutes instead of hours. For parts with a 10,000-piece annual volume, that difference is worth more than a small reduction in cycle time.

• 1
  ViseFast for blocky parts, limited on complex geometry.
• 2
  Soft jawsMatch the part profile to spread clamping load.
• 3
  Vacuum tableBest for thin plates where clamps would distort the part.
• 4
  5-axis trunnionOne setup for features on five or more faces.

Every material has a machinability rating, and that rating sets the starting point for speed and feed. Free-machining aluminum 6061 cuts easily and holds tight tolerances. 304 stainless work-hardens if the tool rubs, so the feed must stay high enough to cut rather than polish. Titanium Ti-6Al-4V conducts heat poorly, so most of the heat goes into the tool; coolant and moderate speed keep it alive.

Plastics behave differently again. POM and ABS cut cleanly but melt if the chip cannot escape. PEEK needs sharp tools and generous clearance. Carbon fiber is abrasive and wears carbide quickly, so we plan for more tool changes and use diamond-coated cutters on long runs.

Surface finish follows from the same variables. A Ra 0.8–1.6 μm finish is standard for machined surfaces. Ra 0.2–0.8 μm requires a finishing pass with a small stepover, a sharp tool and a rigid setup. As-machined Ra 1.6–3.2 μm is fine for non-critical faces and costs less.

Heat treatment changes the plan. Pre-hardened steel above 40 HRC needs carbide or ceramic tooling and lighter depths of cut. If the part is hardened after machining, we leave grinding stock and note it on the drawing.

• 1
  Aluminum 6061300–500 m/min surface speed, easy to finish.
• 2
  Stainless 304100–150 m/min, keep feed high to avoid work hardening.
• 3
  Titanium Ti-6Al-4V40–60 m/min, flood coolant, sharp tools.
• 4
  PlasticsHigh rake angle, air blast, watch chip evacuation.

Inspection is not a final step bolted onto the end. It runs through the whole process: incoming material check, first-article inspection, in-process monitoring and final inspection before shipment. For a part with a ±0.005 mm tolerance, the first article tells us whether the setup is capable; in-process checks tell us whether it is drifting.

First-article inspection verifies every dimension on the drawing, not just the tight ones. If a non-critical dimension is off, that often points to a datum or tool offset error that will eventually affect a critical one. We correct the setup before running the batch, not after.

In-process checks use calipers, micrometers, bore gauges and height gauges at defined intervals. For long runs, we monitor tool wear and replace tools on a schedule rather than waiting for a dimension to fail. A worn 6 mm end mill can shift a slot width by 0.03 mm before it breaks.

Final inspection covers 100% of parts before shipment, with reports available on request. CMM reports show actual values against nominal for the features the customer cares about. For regulated industries, we hold documentation to ISO 9001:2015, IATF 16949:2016, ISO 13485:2016 and ISO 27001:2022 requirements.

• 1
  Incoming materialVerify grade, hardness and certificate against the order.
• 2
  First articleMeasure every dimension before releasing the batch.
• 3
  In-processCheck critical features at set intervals and log values.
• 4
  Final100% inspection, report on request, protected uploads.
