A plane grinder, also called a surface or reciprocating table grinder, takes a flat face down to size with the periphery of an abrasive wheel. The table strokes under the wheel, the wheel head steps across the part, and the head drops a few micrometres per pass. That is the whole machine in three motions. Everything else on the machine exists to make those three motions repeatable.

The old machines did all three by hand or by hydraulics. An operator watched the spark, listened to the wheel, and turned a handwheel for depth. Skilled hands made good parts, but the depth of cut depended on the operator's feel that morning, and the wheel wore a little on every pass. On a batch of 200 plates, size drifted and the last parts needed extra spark-out passes.

CNC did not replace the grinding process. It replaced the decisions the operator used to make between passes: how far to step over, how deep to go, when to dress, and how much to compensate for the wheel that just got smaller. The grinding wheel is still a wheel. The machine just stops guessing about it.

That distinction matters when you read machine specifications. A grinder sold as fully CNC may still stroke its table hydraulically. What is under CNC control is the cross feed axis, the down feed axis, sometimes a rotary dresser axis, and the measurement feedback. Those are the axes that decide your flatness and your size.

• 1
  Table strokeOften hydraulic on mid-range machines; servo on high-end ones.
• 2
  Cross feedCNC axis. Sets step-over and edge blending.
• 3
  Down feedCNC axis. Sets depth per pass and final size.
• 4
  DressingCNC or automatic. Restores wheel form and triggers compensation.

On a manual grinder, down feed is a number the operator sets and then corrects by eye. On a CNC grinder, down feed is a program value with a compensation offset that the control updates after each dress. When a diamond dresser takes 0.02 mm off the wheel radius, the control adds that 0.02 mm back into the next pass. The part does not know the wheel got smaller.

This is what makes unattended grinding possible. The operator loads a batch, sets the target size and the tolerance window, and the control grinds, dresses and compensates through the run. On a 300-piece batch of hardened plates, the difference between manual and CNC feed shows up as size spread: manual work typically drifts with wheel wear, CNC work holds inside the window you set.

Cross feed benefits in the same way. Step-over distance controls how much of the wheel edge contacts the part on each stroke. Too small a step and the wheel rubs, burns and loads up. Too large a step and you leave a visible step between passes. A CNC control repeats the same step-over for the whole batch, so the surface pattern stays uniform from the first plate to the last.

The limits are real, though. CNC feed does not fix a wheel that is too soft for the material or a coolant that cannot clear the grit. It also does not fix a part that springs away from the wheel because the fixture is weak. Feed control is a multiplier on a sound setup, not a substitute for one.

• 1
  Compensation after dressingWheel radius loss is added back into the next down feed.
• 2
  Repeatable step-overSame surface pattern across the batch.
• 3
  Spark-out passesProgrammed at zero feed to clear spring in the part.
• 4
  Not a cure-allWheel grade, coolant and fixturing still set the ceiling.

Dressing is where most grinding problems start. A dull or loaded wheel rubs instead of cutting, and the part burns. A wheel dressed too aggressively loses its form and the corner radius you relied on disappears. CNC grinders handle this by counting. After a set number of passes, the control runs a dress cycle, then applies compensation. The operator does not decide when to dress; the count does.

Form dressing goes further. A CNC-controlled diamond dresser can trace a profile into the wheel, so a single wheel grinds a radius, a chamfer and a flat in one setup. On manual machines that work needed a form wheel or a second operation. On a CNC grinder it is a program line. This is the part of the application of CNC systems that changed what parts are practical to grind, not just how fast they grind.

In-process gauging closes the loop. A probe touches the part between passes and reports actual size, and the control adjusts the offset before the next pass. That is how a grinder holds a tight window on a long batch without an operator measuring every part. The gauge has to be calibrated and kept clean, and the probe contact point has to be clear of swarf. Otherwise the loop reports the wrong number and the control confidently grinds to it.

None of this runs without thermal stability. Grinding puts heat into the part and into the machine. A spindle that grows 10 μm during a run moves the wheel relative to the table. Warm-up cycles and stable coolant temperature matter more on a grinder than on a mill, because the tolerances are smaller.

• 1
  Count-based dressingDress interval set by passes, not by operator judgement.
• 2
  Profile dressingOne wheel grinds radius, chamfer and flat in a single setup.
• 3
  Gauge feedbackProbe size is fed back as an offset for the next pass.
• 4
  Thermal driftWarm-up and coolant temperature control protect the window.

Grinding is the right process when the part is hard, when the flatness or parallelism callout is tight, or when the surface finish has to be fine. Hardened tool steel above roughly 45 HRC is the classic case. A CNC mill will cut it, but slowly and with short tool life. A grinder removes the same material with an abrasive that does not care about hardness.

Thin parts are the second case. A 2 mm plate will spring under a milling cutter and come off the machine bowed. Grinding takes light passes with a wide wheel, and the CNC-controlled spark-out lets the plate relax before the final size is set. Parallelism on a thin plate is usually easier to hold on a grinder than on a mill.

The third case is finish. A ground surface in the Ra 0.2–0.8 μm range is produced by the abrasive grain, not by a cutter mark. If the drawing calls for a sealing face, a slideway, or a lapped-looking surface, grinding gets there in fewer steps than milling plus polishing.

The parts that do not belong on a grinder are soft, three-dimensional, or full of pockets. A 6061 aluminium bracket with pockets and tapped holes is a milling job. Grinding it wastes time and risks loading the wheel. The decision is usually obvious once you look at hardness, geometry and the tolerance callout together.

• 1
  Hardened steelAbove about 45 HRC, grinding beats milling on cost.
• 2
  Thin platesLight passes and spark-out control spring and bow.
• 3
  Sealing and sliding facesFine finishes come straight off the abrasive.
• 4
  Not for pocketsSoft 3D geometry with holes is a milling job.

Grinding quotes come back accurate when the drawing states the flatness and parallelism callouts, not just the thickness. A plate at 20 ±0.01 mm with no flatness callout may be ground on one face and shipped. A plate with a 0.005 mm flatness requirement needs both faces ground and a different setup. Those are different jobs and different prices.

State the hardness and the heat treatment condition. A part ground before hardening and then heat treated will move. A part ground after hardening needs a softer wheel and lighter passes. Tell the shop which sequence you intend, or ask them to choose, but do not leave it unstated.

Say whether the finish is functional or cosmetic. A sealing face at Ra 0.4 μm is a functional requirement and worth the extra passes. A cosmetic face at Ra 0.8 μm may be fine as machined. The finish number drives cycle time more than most people expect, and it is the easiest line on the drawing to over-specify.

Finally, mention the batch size and whether the parts are one-offs or a repeating order. A single prototype plate is set up and ground by hand on a CNC machine. A 5,000-piece run is worth programming and gauging properly. The shop's process choice changes with volume, and a buyer who states volume up front gets a more realistic quote.

• 1
  Flatness and parallelismState them. Thickness alone does not define the job.
• 2
  Hardness and sequenceGrind before or after heat treatment changes the setup.
• 3
  Functional vs cosmetic finishOver-specified finish adds cycle time for no gain.
• 4
  VolumeOne-off and 5,000-piece runs use different processes.

GreatLight runs 127 high-precision CNC machines across three wholly-owned plants, in 7,600 m² of floor space in Dongguan plus a factory in Singapore. Grinding work is not a standalone department here; it sits next to the milling and turning cells so a part can move from soft machining to heat treatment to finish grinding without leaving the supply chain. That matters for parts that need a flat face after hardening.

Tolerance work is quoted at ±0.005 mm where the geometry allows it, with fine finishes in the Ra 0.2–0.8 μm range. Inspection is 100% before shipment, with raw material checks, in-process monitoring and a final inspection, and reports on request. For ground surfaces, the flatness and parallelism numbers are measured and recorded rather than assumed from the machine setting.

Volume is flexible. There is no minimum order quantity, so a single prototype plate and a 10,000-piece run both go through the same quoting path. Quotation and a free DFM analysis come back within 12 hours, production can start within 24 hours, and parts typically ship in 3–5 days. Uploads are handled under NDA on request.

Materials cover the usual grinding candidates: 4140, 4340 and tool steel, 17-4PH and 440C stainless, and hardened alloys. If your part is soft and flat but full of features, we will usually say so and quote it as a milling job instead. That is a better answer than grinding something that does not need it.
