Osteoid is unmineralized bone matrix. It is about 90% type I collagen by protein mass, with osteocalcin, osteopontin and bone sialoprotein making up most of the rest. Cells do not respond to a scaffold as a solid object. They respond to the local presentation of that matrix: ligand density, fiber spacing, bound water and stiffness.

In vivo, osteoblasts deposit osteoid as a 10–50 μm layer ahead of the mineralization front. That layer is soft, hydrated and loaded with arginine-glycine-aspartate (RGD) motifs that integrins can grab. A 3D printed scaffolds design that ignores this layer will still support cell attachment, but the differentiation signal is weak.

So the engineering target is not "bone-like material". It is a set of local cues that fall inside the range osteoprogenitor cells evolved to read. Pore size, strut stiffness, surface charge and fluid mobility are the four knobs you actually control at the printer.

This article covers what each knob does, where the useful windows sit, and when a printed lattice is the wrong answer entirely. If you need machined fixtures or housings around a scaffold, that is a separate job and we treat it that way.

Pore size controls two things at once: how far a cell must migrate to bridge a gap, and how easily nutrients diffuse to the cells already inside. Below roughly 100 μm, most osteoprogenitors cannot fully enter the pore and the structure behaves as a surface. Between 200 and 600 μm, vascular ingrowth and bone bridging both proceed in animal models.

Above about 800 μm, diffusion is rarely limiting but the strut surface area per unit volume drops. Fewer attachment sites means fewer cells retained at seeding. Porosity and pore size are not the same variable, and a 70% porous scaffold with 900 μm pores behaves very differently from a 70% porous scaffold with 300 μm pores.

Strut diameter matters as much as the pore. Thin struts (150–250 μm) flex under load and transmit strain to attached cells. Thick struts (600 μm and above) act as rigid posts, and cells on them see a stiff substrate regardless of the bulk material. This is why two scaffolds printed from the same resin can produce different differentiation outcomes.

Pore shape is the third variable. Rectangular grid pores concentrate stress at corners. Round or gyroid channels distribute strain more evenly and print with fewer unsupported spans. For load-bearing sites, gyroid or diamond lattices usually print cleaner and fail more predictably.

• 1
  200–600 μm poreTypical window for bone ingrowth in porous scaffolds
• 2
  Below 100 μmCells see a surface, not a volume; ingrowth stalls
• 3
  Thin struts flex150–250 μm struts transmit strain to attached cells
• 4
  Gyroid over gridFewer stress concentrations and fewer support failures

Substrate stiffness steers lineage. On soft gels near 0.1–1 kPa, mesenchymal stem cells tend toward neural markers. Around 8–30 kPa they shift toward muscle. On stiff substrates above roughly 25–40 kPa, osteogenic markers rise. Bone itself sits far higher, in the GPa range, so a printed scaffold rarely matches bone stiffness directly.

The useful trick is decoupling bulk stiffness from local stiffness. A stiff polymer printed as a thin, flexible strut presents cells with a locally compliant surface while the implant as a whole carries load. That mismatch is deliberate, not a defect.

Viscoelasticity adds a second signal. Hydrogels that relax stress within seconds to minutes promote spreading and osteogenic differentiation more than elastic gels of the same initial modulus. Stress relaxation rate is a design parameter, and it is set by crosslink chemistry rather than by the printer.

For printed thermoplastics, viscoelasticity is largely fixed by the polymer. PCL relaxes slowly and behaves close to elastic at body temperature. Composite or coated struts give you a way to add a relaxation layer without changing the load-bearing core.

A printed strut arrives with whatever chemistry the process left behind: unreacted monomer, adsorbed mold release, or a smooth skin from the laser path. None of that presents RGD motifs. Cells will attach, but through weak, non-specific adsorption of serum proteins.

The standard fix is a two-step surface treatment. First, activate the surface, for example with plasma or alkaline hydrolysis. Second, graft a ligand: fibronectin, collagen I, or a short RGD peptide. Graft density matters more than the choice of ligand in many studies, with a plateau once surface coverage is adequate.

For mineralized scaffolds, hydroxyapatite or tricalcium phosphate particles embedded in the strut change both stiffness and surface chemistry at once. Cells bind to the mineral phase through integrin-mediated pathways that differ from collagen binding. That is useful, but it also means the mineral content becomes a release and degradation variable, not just a coating.

Coating uniformity is the practical limit. Dip coating a 400 μm pore lattice can bridge pores if the solution is too viscous. Plasma treatment penetrates better but the effect decays within days unless the part is sealed and used promptly.

Cells survive roughly 100–200 μm from a capillary. Any scaffold thicker than about 400 μm needs a vascular plan, not just pores. Diffusion alone will keep the outer shell alive and leave the core hypoxic within days of implantation.

Printed channels help, but only if they connect. A lattice with 300 μm pores and no through-channel will perfuse poorly at the core. Adding a 500–800 μm channel network every few millimeters gives vessels a path and gives you a route for seeding and for waste removal.

Degradation rate sets a second clock. If the scaffold resists degradation while new bone forms, the implant carries load for longer but leaves a residual phase. If it degrades faster than bone apposition, the defect collapses. Matching the two rates is the hardest part of any resorbable design.

There are cases where a printed lattice is the wrong choice. Large segmental defects with unstable fixation need a load-bearing device first, and the scaffold is secondary. Avascular sites, infected beds and poorly vascularized soft tissue envelopes will not be rescued by pore geometry.
