Most buyers start by comparing controller brands. That is the wrong end. The loop topology decides what the machine can hold before the controller ever runs a program. A semi-closed loop reads position at the motor shaft. Everything between the shaft and the cutting edge, including ball screw pitch error, backlash and thermal growth, sits outside the feedback path.

A closed loop closes that gap. The scale reads the slide directly, so the control sees what the tool actually does. On a well-built machine this is the difference between ±0.05 mm and ±0.005 mm. The cost is real: scales need careful mounting, cleaning and protection from chips and coolant.

Semi-closed is not obsolete. For brackets, fixtures and housings with ±0.05 mm callouts, it holds tolerance and costs less to maintain. We run both topologies across 127 high-precision CNC machines. The loop is matched to the job, not to a catalog tier.

One caution. A closed loop cannot fix a loose machine. If the thrust bearings are worn or the screw is preloaded wrong, the scale will report the error and the control will chase it, which is worse than no scale at all.

• 1
  Check the feedback pathAsk where the encoder or scale sits. Motor-mounted means semi-closed.
• 2
  Repeatability beats resolutionA machine that returns to the same point is worth more than a fine readout.
• 3
  Thermal drift is the silent errorA 1 m steel screw grows about 12 μm per °C. Warm-up routines exist for a reason.

The servo control unit turns position commands into motor current. Its function set decides how fast the axis can move without losing position, and how the machine behaves when a cut loads the tool. Four functions carry most of the value on a real job.

Rigid tapping runs the spindle as a servo axis so the tap feeds at exactly the thread pitch. Without it you need floating tap holders, and thread depth varies. With it, M6 threads in 6061 hold depth within a few hundredths of a millimeter.

Synchronous feed and electronic gearing keep two axes locked. Thread milling, hobbing and polygon turning all depend on it. Spindle orientation parks the spindle at a fixed angle for tool changes and for boring bars that must enter a specific way.

Feed-forward and notch filters are the less visible pair. Feed-forward reduces following error during acceleration, which shows up as corner rounding on high-feed passes. Notch filters kill the resonance that makes a machine ring at certain speeds. On a 4,000 mm travel machine, that ringing is the difference between a clean face and a visible pattern.

• 1
  Ask for the function listIt is a firmware option, not a physical part. Confirm it is enabled before shipment.
• 2
  Tuning is machine-specificGains set on a small machine will not transfer to a large one.
• 3
  Test on your geometryA test cut with the real toolpath tells you more than a spec sheet.

A vague request gets a vague quote. State the tightest tolerance on the drawing and the surface finish that matters. If a bore is ±0.005 mm and the rest of the part is ±0.1 mm, say so. Vendors will then propose a closed loop for the critical feature instead of pricing the whole part on the tight callout.

Give the material and the batch size. Aluminum 6061 cuts differently from 17-4PH stainless, and a 10-piece run is quoted on a different basis than a 10,000-piece run. At GreatLight there is no minimum order quantity, from one prototype to 10,000+ part runs, so the same drawing can be priced at either end.

State the inspection requirement. We inspect 100% of parts before shipment, with raw material checks, in-process monitoring and final inspection, and reports on request. If your quality system needs a first article report or a material certificate, put it in the request.

Finally, name the finish. Anodizing, electroless nickel and bead blasting all change dimensions slightly. A hardcoat anodize can add 25 to 50 μm per surface. If the tolerance is tight, the finish has to be part of the drawing review.

A clear spec also shortens the loop. We return a quotation and free DFM analysis within 12 hours when the drawing and material are unambiguous.

• 1
  Separate critical from general tolerancesIt changes the machine and the price.
• 2
  Name the surface finish calloutRa 0.8–1.6 μm is a typical machined finish. Ra 0.2–0.8 μm needs extra passes.
• 3
  Flag the certification needISO 9001:2015, IATF 16949:2016, ISO 13485:2016 and ISO 27001:2022 are held in-house.

Axis count is a geometry question, not a status symbol. A part with features on five faces needs either five-axis capability or multiple setups. Multiple setups add fixture error to every transition, and that error often eats the tolerance budget.

We run 16 simultaneous 5-axis machining centers, 12 four-axis mills, 27 three-axis machines and 16 mill-turn centers. Maximum processing size is 4,000 mm, with travel groups at 4,000 × 400 × 150 mm, 750 × 1,150 × 550 mm, 600 × 600 × 600 mm, and compact cells at 500 × 500 × 450 mm and 500 × 310 × 200 mm. A Ø400 mm rotary table covers the mid-size work.

Five-axis is not always the answer. On a simple prismatic part, a three-axis machine with a good fixture is faster and cheaper. Five-axis pays back when setup count drops from four to one, or when the part has undercuts and compound angles a three-axis spindle cannot reach.

Mill-turn matters for parts with both turned and milled features. Keeping them on one machine removes a re-chuck, and re-chucking is where concentricity goes wrong.

• 1
  Count setups firstFewer setups usually beats a higher-spec machine.
• 2
  Check the swing and travelA part that fits the table may still not clear the housing.
• 3
  Watch the fixtureOn thin walls, fixture stiffness sets the finish as much as the spindle does.

The first mistake is comparing peak torque. Peak torque lasts a few seconds and only covers acceleration. Continuous, or rated, torque is what the motor can hold all day. Size on rated torque at your actual duty cycle, then confirm the peak covers the acceleration spike.

The second is trusting encoder resolution as an accuracy figure. A 23-bit encoder resolves about 0.0000001 of a revolution. The machine still holds ±0.005 mm at best, because backlash, screw pitch error and thermal growth dominate. Resolution tells you what the control can see, not what the tool will do.

The third is buying functions you will never call. A shop cutting simple plates does not need five-axis synchronous control or polygon turning. Paying for unused functions adds cost and, more importantly, adds tuning variables that can go wrong.

The fourth is ignoring warm-up. A machine that runs its first part cold will drift for the first 30 to 60 minutes. Spindle and axis growth moves the tool relative to the workpiece. A 20-minute warm-up cycle before the first tight-tolerance part is cheap insurance.

The fifth is accepting a verbal lead time. Get it in the quote, with the inspection scope next to it.

• 1
  Rated torque, not peakPeak covers spikes. Rated covers the cut.
• 2
  Resolution is not accuracyMechanics set the floor.
• 3
  Warm up before tight workThermal growth is predictable and avoidable.
