A CNC wire bending machine pulls wire from a coil through straightening rolls, then feeds a measured length into a bending head. The head carries a bending die and a counter-die; a servo pushes the wire against the die and the wire takes a permanent set. Between bends, a rotary unit spins the wire around its own axis so the next bend lands in a different plane. That combination of linear feed, rotation, and bend angle is what produces a 3D part from a flat coil.

The controller stores the whole sequence as a program. Each line holds a feed length, a rotation angle, and a bend angle, plus the order they run in. Because every axis is servo-driven, the machine repeats the same move without an operator touching a stop or a handle. That is where the speed comes from on long runs, not from bending faster than a human can.

Two families of machines cover most work. Single-head machines bend one point at a time and handle simple 2D and light 3D forms. Multi-head machines mount several bending tools on a rotating table and can bend in both directions without flipping the part. Multi-head machines cut cycle time on parts with many bends, but they need more setup time and a larger minimum run to pay off.

The wire itself is a variable. Coil wire arrives with residual curvature from drawing, and the straightener has to remove it before the first bend. If the straightener is set loose, the part looks fine on the bench and fails a fixture check. Set it tight enough that a 1 m length of wire lies flat within 1–2 mm over its length.

• 1
  Feed axisServo-driven rollers measure wire length; repeatability drives leg length.
• 2
  Rotation axisSpins wire around its axis so bends land in separate planes.
• 3
  Bend axisPushes wire against a die; angle is programmed, not set by hand.
• 4
  StraightenerRemoves coil curvature before the first bend, or every dimension drifts.

Wire does not stay where you push it. When the bending die retracts, the material springs back toward its original shape, and the finished angle is smaller than the programmed one. The amount depends on material, temper, wire diameter, and the ratio of bend radius to wire diameter. A soft copper wire may spring back 1–3°, a spring-tempered stainless can return 8–12°. The controller compensates with an over-bend value that the operator tunes on the first article.

Bend radius is the other lever. Forming a tight radius around a small die stretches the outer fibers hard, and the wire either cracks or thins at the bend. A common working rule is a minimum inside radius of 1× wire diameter for soft materials and 2–3× for harder tempers. Below that, the bend becomes a coin flip on a 500-piece run.

Tolerance splits into two parts that behave differently. Bend position along the wire is controlled by feed length and typically holds ±0.1 mm on a well-maintained machine. Bend angle depends on springback compensation and usually holds ±1°. If a part needs ±0.5° on a bend angle, wire forming is the wrong process, and the design should move to a stamped or machined feature.

Leg length after bending also creeps. The neutral axis of the wire shifts inward at each bend, so a flat pattern calculated from centerline length comes up short. Add bend allowance to the cut length, or cut the first article long and trim it to the fixture.

• 1
  Over-bendProgrammed angle larger than the target to cancel springback.
• 2
  Minimum radius1× wire Ø for soft wire, 2–3× for spring temper.
• 3
  PositionFeed-controlled, typically ±0.1 mm along the wire.
• 4
  AngleSpringback-controlled, typically ±1°.

Low-carbon steel wire is the easiest to form. It springs back little, bends to a tight radius without cracking, and welds or threads without trouble afterward. Music wire and other high-carbon grades form well but spring back hard, so the over-bend values in the program get large and the setup window narrows.

Stainless grades 302 and 304 work on the same machines with more springback and more tool wear. Grade 316 forms acceptably but costs more and galls against the die if lubrication is poor. For parts that need corrosion resistance plus stiffness, 17-4PH wire forms in the annealed condition and then ages to a much higher strength.

Non-ferrous wire covers a wide range. Copper and brass form to very tight radii and are forgiving on springback, which makes them common in electrical contacts and terminals. Aluminum wire bends easily but work-hardens at the bend, so a part that gets reworked twice can crack. Titanium and nickel alloys form with heavy springback and short die life; expect slower cycle times and more first-article tuning.

Coating matters as much as the core. Galvanized, tinned, and painted wire can flake or craze at a tight bend. If the coating has to survive the bend, keep the inside radius at 2× wire diameter or larger and test a sample before the run.

• 1
  EasiestLow-carbon steel, copper, brass.
• 2
  Moderate302/304 stainless, 6061 aluminum wire, 17-4PH annealed.
• 3
  DifficultMusic wire, 316, titanium, nickel alloys.
• 4
  Coated wireKeep radius ≥2× wire Ø or the coating crazes.

Every bend angle and radius needs a matching die set. A part with six different bends may need three or four tools if some bends share a radius. Tool changes are the main setup cost, so a design that reuses one or two bend radii across the part runs cheaper than one that specifies a new radius at every corner.

Cycle time is the sum of feed, rotate, and bend moves plus any tool indexing. A simple 4-bend hook might run in 3–6 seconds per part. A 12-bend 3D form with two tool changes can take 25–40 seconds. On a 5,000-piece order that difference is the whole cost argument, so it pays to simplify the bend sequence before releasing the drawing.

Wire diameter sets the practical ceiling. Machines in common production use handle roughly Ø0.5–12 mm. Below Ø0.5 mm the wire whips and kinks during fast feed. Above Ø12 mm the bend force and die size push the job toward a different process.

Program storage keeps repeat orders honest. Once the first article is approved, the feed lengths, over-bend values, and tool positions are saved against the part number. A reorder then starts from a known setup instead of a fresh guess, which is why the second run usually holds tolerance tighter than the first.

• 1
  Tool countFewer distinct radii means fewer tool changes and lower setup cost.
• 2
  Cycle time3–6 s for simple hooks, 25–40 s for 12-bend 3D forms.
• 3
  Wire rangeAbout Ø0.5–12 mm on standard production machines.
• 4
  Repeat ordersSaved programs cut first-article tuning on the second run.

Keep the first bend at least 2× wire diameter from the wire end. Closer than that, the die has nothing to grip and the end curls instead of forming a clean corner. The same clearance applies between two bends in the same plane: if they sit too close, the second bend distorts the first.

Plan the sequence so the part never has to pass through itself. A bend made early can block the path of a later bend that crosses the same space. The fix is usually to reorder the program, not to redesign the part, but the designer can help by keeping bend planes from crowding a single zone.

Leave a straight section wherever the part gets welded, threaded, or clamped. A bend right at a joint throws the mating face off angle and makes assembly fight. As a rule, keep 3× wire diameter of straight wire on each side of any joint.

Symmetry is cheap. A part that mirrors its bend sequence can often be formed with the same tools and the same program, halving setup work. Asymmetric 3D forms are not a problem, but they cost more per piece, and the quote should say so.

• 1
  End clearanceFirst bend ≥2× wire Ø from the wire end.
• 2
  Bend spacingKeep bends in one plane at least 2× wire Ø apart.
• 3
  Joint zones3× wire Ø of straight wire around welds and threads.
• 4
  SymmetryMirrored bend sequences reuse tools and programs.

Wire forming and CNC machining solve different problems. Machining removes material from a solid block, so it holds tight tolerances and produces complex solid geometry, but it wastes material and costs more per part as volume rises. Wire forming moves material instead of cutting it, so material waste is near zero and the per-part cost drops sharply with volume.

The overlap is in parts that need both. A wire form with a machined end fitting, a threaded stud, or a flattened mounting tab is common. GreatLight runs 127 high-precision CNC machines, including 16 simultaneous 5-axis machining centers and 16 mill-turn centers, so a wire-formed part can be paired with machined details in the same shop and checked against one drawing.

Choose wire forming when the part is essentially a bent centerline: hooks, clips, cages, frames, springs, handles, and brackets. Choose machining when the part carries a bore, a thread, a flat face, or a tolerance tighter than the process can hold. The two are complements, not competitors.

For a wire part that also needs a machined interface, hold the wire bend tolerance at ±1° on angles and ±0.1 mm on position, then machine the interface from a datum you can measure. Do not stack a ±0.5° bend requirement onto a feature that gets machined anyway; you pay for the tight bend and still have to cut the feature.

• 1
  Wire formingNear-zero material waste, low tooling cost, fast at volume.
• 2
  MachiningHolds ±0.005 mm, cuts bores and threads, higher cost per part.
• 3
  Combined partsForm the centerline, machine the interface, measure from one datum.
• 4
  Shop capacity127 CNC machines, 16 five-axis centers, 16 mill-turn centers.
