A press brake bends sheet by pushing a punch into a die while the sheet rests on two shoulders. The machine that does this with the ram travelling straight down is what most shops call a CNC vertical bending machine. The sheet stays horizontal on the bed. Force comes from above, not from the side, and that single fact shapes everything about the process.

The bend angle is not set by how far the ram travels. It is set by how deep the punch sinks between the die shoulders. Sink deeper and the sheet wraps further around the punch nose, so the included angle closes. Most controllers calculate that depth from the material grade, thickness and target angle, then compensate for springback automatically.

Vertical travel also decides the open height and the throat depth. A deep throat lets a tall flange hang down past the bed without hitting the frame. That is the whole reason vertical machines exist: one axis of the part can be long, and the machine simply gets out of its way.

Tonnage is the third variable. Required force scales with sheet thickness squared, so doubling thickness roughly quadruples the load. A 3 mm mild steel bend may need 40 tonnes per metre, while 6 mm pushes past 150 tonnes per metre. Undersized machines flex, and flex shows up as a crowned bend in the middle of the part.

• 1
  Depth sets angleAngle comes from punch penetration, not ram position alone.
• 2
  Throat depth sets clearanceIt decides how tall a flange can hang below the bed.
• 3
  Tonnage scales with t²Thickness drives force far faster than length does.

The ram carries the punch and moves on linear guides. On a well-built machine the guides hold the punch parallel to the bed within a few thousandths of a millimetre across the full length. Any loss of parallelism shows up as an angle that varies from one end of the part to the other.

The bed supports the die and takes the reaction force. It is the stiffest casting on the machine because deflection here is what crowning has to correct. A bed that flexes under load will bow the die, and the bend in the middle of a long part will open up compared with the ends.

The backgauge positions the sheet along the bend line. Servo-driven fingers move to the programmed dimension and act as a hard stop. Repeatability of the backgauge, not the operator, is what holds bend-to-bend location on a run of parts.

Crowning is a hydraulic or mechanical system that bows the bed upward to match the downward flex under load. Set correctly, it keeps the angle constant across the full bend length. Skip it on thick or long parts and the middle of the bend will be visibly shallower than the edges.

• 1
  Ram parallelismControls angle consistency along the bend line.
• 2
  Bed stiffnessDetermines how much crowning must compensate.
• 3
  Backgauge repeatabilityHolds bend location from part to part.

Vertical bending earns its place on parts with tall flanges, deep boxes, or a shape that would collide with a horizontal machine frame. An enclosure panel with a 200 mm return flange is a clean fit. The flange hangs into the throat, the bend line stays accessible, and the tooling never fights the part.

Long, narrow parts also suit it. A 3,000 mm channel with a shallow profile bends in one pass without repositioning, because the bed length covers the full part. Fewer setups mean fewer chances to lose the bend line.

Thin sheet up to about 3 mm is the sweet spot for air bending. Beyond 6 mm the tonnage climbs quickly, tooling wear accelerates, and the cost advantage over machining or casting narrows. At that point we often run the numbers on a machined alternative instead.

Small, tightly toleranced brackets are usually a poor fit. A part with a 10 mm flange and a ±0.05 mm hole-to-bend dimension is better cut and formed on a smaller machine, or machined from bar. Vertical bending adds setup cost that a simple part cannot absorb.

• 1
  Good fitTall flanges, deep boxes, long channels, large enclosures.
• 2
  Poor fitTiny brackets with tight hole-to-bend tolerances.
• 3
  Watch the tonnageAbove 6 mm the force curve turns steep.

Angle tolerance on a CNC vertical bending machine typically lands within ±0.5° on air-bent parts, and closer with coining or a good crowning setup. Position tolerance depends far more on the flat pattern than on the machine, because the blank carries its own error into the bend.

Springback is the reason air bending needs compensation. Aluminium 6061 springs back more than mild steel at the same thickness. Stainless 304 springs back more again. The controller offsets the punch depth to land on the target angle, but the offset is only as good as the material data behind it.

Bend deduction is the flat-pattern allowance that accounts for material stretched around the bend radius. Get the K-factor wrong and the finished leg lengths drift even though the angle is perfect. For a 90° bend in 2 mm steel with a 2 mm inside radius, the deduction is usually close to one material thickness per bend.

We check formed parts against the drawing with a height gauge and a protractor, and we compare the flat pattern to the CNC model before the first cut. Catching a K-factor error at the blank stage saves the whole run.

• 1
  Angle±0.5° typical, tighter with coining.
• 2
  SpringbackAluminium and stainless need more compensation than steel.
• 3
  K-factorA wrong value shifts leg lengths, not angles.
